Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 3 | 234042600 | Flat Washer 4 mm, Stainless | 3 |
| 3 | 241142560 | Hex. Flange Screw K40 X 25 | 3 |
| 1 | 291002818 | DECK NOSE | 1 |
| 1 | 291002625 | Rear Plat-Form Carpet | 1 |
| 1 | 291002930 | LH Front Carpet | 1 |
| 1 | 291002931 | ANTI SLIP MAT FR | 1 |
| 1 | 291002932 | LH Center Carpet | 1 |
| 1 | 291002933 | ANTI SLIP MAT CTRL R | 1 |
| 1 | 291002934 | LH Rear Carpet | 1 |
| 1 | 291002935 | RH Rear Carpet | 1 |
| 1 | 296000342 | SEAL | 1 |
| 1 | 293250220 | Seal | 1 |
| 1 | 293250200 | NEOPRENE SEAL | 1 |
| 3 | 293730010 | Black Dart | 3 |
| 1 | 291003017 | Front Module | 1 |
| 1 | 269002162 | Mounting Case Absorber | 1 |
| 5 | 293150123 | Pop Rivet 3/16" | 5 |
| 8 | 243163560 | Plastite Hex. Screw M6.8 X 35 | 8 |
| 8 | 234082600 | Flat Washer 8 mm, Stainless | 8 |
| 1 | 291003686 | LH Access Cover Includes 20 to 29 | 1 |
| 291003687 | RH ACCESS COVER Includes 20 to 29 | ||
| 1 | 211000023 | Hex. Screw 10-14 X 7/8” | 1 |
| 1 | 293300121 | O-Ring | 1 |
| 1 | 219704367 | Was 293200133 Neoprene Seal | 1 |
| 2 | 291003688 | Rubber Bumper | 2 |
| 2 | 233161600 | Hex. Flange Nut M6 | 2 |
| 2 | 269501166 | Nut Housing Ass'y | 2 |
| 2 | 205063060 | Socket Head Screw M6 X 30 | 2 |
| 1 | 291002626 | LH Nonskid | 1 |
| 1 | 291002937 | RH NONSKID | 1 |
| 1 | 292000933 | U-Clamp | 1 |
| 1 | 291002351 | Hook | 1 |
| 1 | 291001386 | Black, Finition Plate | 1 |
| 2 | 234082600 | Flat Washer 8 mm, Stainless | 2 |
| 2 | 232581200 | Hex. Elastic Nut M8 Brass | 2 |
| 1 | 291004622 | Black Rear Handle | 1 |
| 1 | 291002784 | Seat Stud | 1 |
| 1 | 232100600 | Hex. Jam Nut M10 | 1 |
| 1 | 234002600 | Flat Washer 10 mm, Stainless | 1 |
| 1 | 271001732 | Elastic Nut M10 Housing | 1 |
| 1 | 219704378 | Gasket 3000Mm Long | 1 |
| 4 | 207065060 | Hex. Screw M6 X 50 | 4 |
| 4 | 234062600 | Flat Washer M6, Stainless | 4 |
| 2 | 232561200 | Brass Elastic Stop Nut M6 | 2 |
| 2 | 207063560 | Hex. Screw M6 X 35 | 2 |
| 4 | 250200022 | Flat Washer M6.6 X 22 | 4 |
| 1 | 291002947 | LOWER DECK ASS'Y Includes 51 to 53 | 1 |
| 4 | 269501166 | Nut Housing Ass'y | 4 |
| 219903184 | CAUTION ENGINE OIL | ||
| 291003509 | RH FRONT COVER ASS'Y | ||
| 291003512 | LH FRONT COVER ASS'Y | ||
| 2 | 293730006 | Black, Dart | 2 |
| 2 | 293150123 | Pop Rivet 3/16" | 2 |
| 1 | 291003192 | RH Seat Pad, Black | 1 |
| 1 | 291003193 | LH Seat Pad, Black | 1 |
| 291003515 | LH UPPER BODY CAP COVER | ||
| 1 | 291003516 | RH UPPER BODY CAP COVER | 1 |
| 1 | 291002588 | Front Bumber | 1 |
| 3 | 250000399 | Hexagonal Cap Screw M6 X35 | 3 |
| 1 | 291002592 | Rear Bumber | 1 |
| 4 | 250000399 | Hexagonal Cap Screw M6 X35 | 4 |
| 291003050 | Lateral Bumper | ||
| 4 | 291002744 | Bumber Cap | 4 |
| 2 | 513033435 | Grommet | 2 |
| 2 | 414523600 | Elbow Fitting | 2 |
| 1 | 219704356 | Was 275500008 Hose 12 mm | 1 |
| 2 | 293750001 | Tie Wrap 94 mm | 2 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 291002756 | FRONT REWINDER CAP | 1 |
