Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | F3R-U35A6-90-00 | Cushion, Fore 6 UR FOR SC2 | 1 |
| 1 | F3R-U35A6-C0-00 | Cushion, Fore 6 UR FOR NC7 | 1 |
| 1 | F3R-U35A1-C0-00 | Cushion, Fore 1 UR FOR NC7 | 1 |
| 1 | F3R-U35A1-90-00 | Cushion, Fore 1 UR FOR SC2 | 1 |
| 4 | F3F-U3714-20-00 | Bracket,Seat | 4 |
| 4 | F3F-U3714-30-00 | Bracket,Seat | 4 |
| 16 | 90151-10S16-00 | Screw, Countersunk | 16 |
| 32 | 90201-10S00-00 | Washer, Plate | 32 |
| 16 | 90204-10S00-00 | Washer, Spring | 16 |
| 16 | 90185-10S00-00 | Nut, Self-Locking | 16 |
| 16 | 90170-10S00-00 | Nut | 16 |
| 1 | F3R-U35B1-C0-00 | Backrest Front, Port UR FOR SC2 | 1 |
| 1 | F3R-U35B1-F0-00 | Backrest Front, Port UR FOR NC7 | 1 |
| 1 | 90167-08SA8-00 | Screw, Tapping UN | 1 |
| 1 | F1C-U5195-00-00 | Clip, 1 UN | 1 |
| 1 | 90169-08SA5-00 | Tapping Screw UN | 1 |
| 1 | F3R-U3796-C0-00 | Back Rest 3 UR FOR NC7 | 1 |
| 1 | F3R-U3796-90-00 | Back Rest 3 UR FOR SC2 | 1 |
| 1 | 90204-14S00-00 | Washer, Spring UN | 1 |
| 1 | 90209-14SA3-00 | Washer UN | 1 |
| 1 | 90170-14S00-00 | Nut UN | 1 |
| 1 | F3R-U35A5-90-00 | Cushion, Fore 5 UR FOR SC2 | 1 |
| 1 | F3R-U35A5-C0-00 | Cushion, Fore 5 UR FOR NC7 | 1 |
| 1 | F3R-U35A2-C0-00 | Cushion Seat, Front Right UR FOR NC7 | 1 |
| 1 | F3R-U35A2-90-00 | Cushion Seat, Front Right UR FOR SC2 | 1 |
| 1 | F3R-U35B2-C0-00 | Backrest Front, Stbd UR FOR SC2 | 1 |
| 1 | F3R-U35B2-F0-00 | Backrest Front, Stbd UR FOR NC7 | 1 |
| 1 | F3R-U3798-C0-00 | Back Rest, 4 UR FOR NC7 | 1 |
| 1 | F3R-U3798-90-00 | Back Rest, 4 UR FOR SC2 | 1 |
| 2 | F3R-U372F-10-00 | Cushion 5 | 2 |
| 1 | F3R-U371D-C0-00 | Cushion 1 UR FOR SC2 | 1 |
| 1 | F3R-U371D-F0-00 | Cushion 1 UR FOR NC7 | 1 |
| 1 | F1C-U5192-00-00 | .Snap | 1 |
| 1 | F3R-U3791-F0-00 | Back Rest 1 UR FOR NC7 | 1 |
| 1 | F3R-U3791-C0-00 | Back Rest 1 UR FOR SC2 | 1 |
| 1 | F3R-U371E-C0-00 | Cushion 2 UR FOR SC2 | 1 |
| 1 | F3R-U371E-F0-00 | Cushion 2 UR FOR NC7 | 1 |
| 1 | F3R-U3795-F0-00 | Backrest 2 UR FOR NC7 | 1 |
| 1 | F3R-U3795-C0-00 | Backrest 2 UR FOR SC2 | 1 |
| 1 | F3R-U372D-90-00 | Cushion, 3 UR FOR SC2 | 1 |
| 1 | F3R-U372D-C0-00 | Cushion, 3 UR FOR NC7 | 1 |
| 1 | F3R-U3724-C0-00 | Cushion Seat, Rear UR FOR NC7 | 1 |
| 1 | F3R-U3724-90-00 | Cushion Seat, Rear UR FOR SC2 | 1 |
| 1 | F3R-U372E-90-00 | Cushion 4 UR FOR SC2 | 1 |
| 1 | F3R-U372E-C0-00 | Cushion 4 UR FOR NC7 | 1 |
| 1 | F3R-U3766-C0-00 | Backrest 1 UR FOR NC7 | 1 |
| 1 | F3R-U3766-90-00 | Backrest 1 UR FOR SC2 | 1 |
| 1 | F3R-U592C-G0-00 | Pad 1 UR FOR SC2 | 1 |
| 1 | F3R-U592C-N0-00 | Pad 1 UR FOR NC7 | 1 |
| 1 | F3R-U521C-C0-00 | Pad 1 UR FOR NC7 | 1 |
| 1 | F3R-U521C-90-00 | Pad 1 UR FOR SC2 | 1 |
| 1 | F3R-U592C-H0-00 | Pad 1 UR FOR SC2 | 1 |
| 1 | F3R-U592C-P0-00 | Pad 1 UR FOR NC7 | 1 |
| 1 | F3R-U521D-C0-00 | Pad 2 UR FOR NC7 | 1 |
| 1 | F3R-U521D-90-00 | Pad 2 UR FOR SC2 | 1 |
| 1 | 90209-14SA2-00 | Washer UN | 1 |
| 1 | 90169-08SA9-00 | Screw, Truss Head Tapping UN | 1 |
