Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 207132044 | Hex Screw M3 X 20 | 2 |
| 1 | 207661644 | Hex. Flange Screw M6 X 16 | 1 |
| 3 | 207662044 | Hex. Flange Screw M6 X 20 | 3 |
| 1 | 207663544 | Hex. Flange Screw M6 X 35 | 1 |
| 6 | 210262040 | Hex. Flange Screw M6 X 20 | 6 |
| XXX | Not Available As Spare Parts | ||
| 1 | 224061121 | Flat Washer | 1 |
| 2 | 232531423 | Elastic Stop Nut M3 | 2 |
| 1 | 232561434 | Elastic Stop Nut M6 | 1 |
| 3 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 3 |
| 4 | 234032600 | Flat Washer M3, Stainless | 4 |
| 1 | 234061410 | Flat Washer 6 mm | 1 |
| 1 | 250000263 | Torx Screw #8-18 | 1 |
| 4 | 250000335 | Socket Head Screw M6 X 20 | 4 |
| 4 | 250000671 | Torx Screw | 4 |
| 1 | 250000690 | Pan Screw Forming, 7500C | 1 |
| 2 | 250000725 | Screw M4 X 16 | 2 |
| 5 | 250200039 | Flat Washer | 5 |
| 2 | 250200041 | Lock Washer Serrated M6 | 2 |
| 1 | 278002963 | Safety Nut (DESS Switch) | 1 |
| 1 | 278003012 | Starter Relay | 1 |
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 415129898 | Battery YUASA YTX20HL Includes 24 To 24a | 1 |
| 1 | 250000282 | Battery Bolt Kit | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 1 | 293750027 | Tie-Rap 206 mm | 1 |
| 1 | 515176795 | Tie Rap Mount (screwable) | 1 |
| 1 | 390909200 | Avex Rivet | 1 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 4 | 293450275 | Insert | 4 |
| 1 | 510004413 | Rocker Switch | 1 |
| 1 | 510004414 | Switch Protector | 1 |
| 1 | 219704425 | Tubing 6 Mm 3000Mm Long | 1 |
| 1 | 515175662 | Male Terminal Housing, 6 Circuits | 1 |
| 1 | 515175749 | Ground Wire | 1 |
| 1 | 515175846 | Male Terminal Housing, 4 Circuits | 1 |
| 1 | 515176844 | ROCKER SWITCH ASS'Y | 1 |
| 1 | 515176970 | BATTERY SUPPORT | 1 |
| 515177008 | BATTERY STRIP | ||
| 1 | 515177039 | PLATE | 1 |
| 1 | 515177147 | Housing Plate | 1 |
| 1 | 515177188 | Harness Accessories | 1 |
| 1 | 515177189 | SEAT HARNESS | 1 |
| 1 | 515177234 | Compressor Module | 1 |
| 1 | 515177273 | Electrical Motor Ass'y | 1 |
| 1 | 515177289 | Ground Wire | 1 |
| 1 | 515177310 | Emergency Stop Switch Support | 1 |
| 1 | 515177325 | Voltage Regulator | 1 |
| 1 | 515177347 | Plate | 1 |
| 1 | 515177350 | Reverse Harness | 1 |
| 1 | 515177362 | Emergency Stop Switch Includes 69 To 69a | 1 |
| 2 | 515175232 | Male Terminal | 2 |
| 2 | 219704418 | PROTECTOR TUBE 1000MM LONG | 2 |
| 1 | 515177457 | Key | 1 |
| 1 | 515177458 | Switch | 1 |
| 1 | 515177460 | Switch Ass'y | 1 |
| 1 | 515177535 | BATTERY WIRE | 1 |
| 1 | 515177646 | Fan Harness | 1 |
| 1 | 515177677 | Housing | 1 |
| 515177751 | WIRING HARNESS MAIN | ||
| 1 | 515177803 | WIRING HARNESS MAIN | 1 |
| 2 | 515177929 | Rivet | 2 |
| 1 | 515177837 | Visor Harness | 1 |
| 1 | 518325560 | Adhesive Patch | 1 |
| 1 | 572103300 | Cap | 1 |
| 1 | 704904616 | BRP Logo 20mm | 1 |
| 1 | 710000495 | Protector Cap | 1 |
| 1 | 710001248 | DC Outlet | 1 |
| 1 | 515177761 | Speedometer Includes 100 To 100c | 1 |
| 1 | 415129355 | Speedometer Button | 1 |
| 1 | 415129348 | Gauge Ring | 1 |
| 1 | 415129349 | Lens | 1 |
