Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 204613998 | SEAT SUPPORT | 1 |
| 1 | 293150043 | Pop Rivet 3/16" | 1 |
| 1 | 234061600 | Stainless Flat Washer M6 | 1 |
| 2 | 204611531 | RETAINING CLIP | 2 |
| 4 | 204611940 | SEAT LATCH | 4 |
| 8 | 204100039 | SCREW 1/4?-20 X 2? | 8 |
| 204611805 | LATCH | ||
| 14 | 204100219 | SCREW-PAN HD.#10-32 X 1-1/4 SS | 14 |
| 11 | 202000159 | SCREW-STUD TAPP. 3/8 SS | 11 |
| 204614161 | Rear Cushion Ass'y, Port Side Navy Blue, Portside, Includes 10 to 14 | ||
| 204614246 | Rear Cushion Ass'y, Port Side Sage Green, Portside, Includes 10 to 14 | ||
| 1 | 204000083 | SNAP BASE | 1 |
| 1 | 204611609 | SNAP COVER | 1 |
| 1 | 204100054 | SCREW 8 X 3/4? | 1 |
| 1 | 211200019 | FLAT WASHER | 1 |
| 204614347 | Rear Cushion Ass'y, Center Navy Blue, Center, Includes 15 to 17 | ||
| 204614348 | REAR CUSHION ASS'Y, CENTER Sage Green, Center, Includes 15 to 17 | ||
| 3 | 204000083 | SNAP BASE | 3 |
| 3 | 204611609 | SNAP COVER | 3 |
| 204614157 | Rear Cushion Ass'y, Starboard Navy Blue, Starboard, Includes 18 to 22 | ||
| 204614248 | Rear Cushion Ass'y, Starboard Sage Green, Starboard, Includes 18 to 22 | ||
| 1 | 204614169 | REAR SIDE CUSHION, PORT SIDE Navy Blue, Portside, Includes 23 to 27 | 1 |
| 204614394 | Rear Side Cushion, Port Side Sage Green, Portside, Includes 23 to 27 | ||
| 3 | 204100054 | SCREW 8 X 3/4? | 3 |
| 3 | 211200019 | FLAT WASHER | 3 |
| 204614165 | Rear Side Cushion, Starboard Navy Blue, Starboard, Includes 28 to 32 | ||
| 204614395 | Rear Side Cushion, Starboard Sage Green, Starboard, Includes 28 to 32 | ||
| 204614153 | Rear Side Backrest, Port Side Navy Blue, Portside | ||
| 204614250 | Rear Side Backrest, Port Side Sage Green, Portside | ||
| 204614149 | Rear Side Backrest, Starboard Navy Blue, Starboard | ||
| 204614252 | Rear Side Backrest, Starboard Sage Green, Starboard | ||
| 1 | 204613804 | REAR BACKREST Navy Blue | 1 |
| 204614254 | Rear Backrest Sage Green | ||
| 4 | 234082600 | Flat Washer 8 mm, Stainless | 4 |
| 4 | 211200025 | Lock Washer 1/4” | 4 |
| 211100026 | HEX. NUT 1/4 | ||
| 3 | 204130190 | BLACK CAP 1 1/2 | 3 |
| 204130008 | Plastic Cap, White | ||
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
