Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204073106 | Console Ass'y, Starboard Fixed Windshield | ||
| 204072495 | Console Ass'y, Starboard Retractable Windshield | ||
| 1 | 204073047 | DASHBOARD MAT | 1 |
| 204550028 | SLIT CONDUIT, METER | ||
| 10 | 207163060 | Hex. Screw M6 X 30 | 10 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 18 | 234062600 | Flat Washer M6, Stainless | 18 |
| 4 | 207164560 | Hex. Screw M6 X 45 | 4 |
| 4 | 232561600 | Hex. Elastic Stop Nut M6 | 4 |
| 204072494 | CONSOLE ASS'Y, PORT SIDE | ||
| 204073048 | MAT | ||
| 4 | 207163060 | Hex. Screw M6 X 30 | 4 |
| 8 | 234061600 | Stainless Flat Washer M6 | 8 |
| 1 | 204071878 | TRIM, WHITE | 1 |
| 1 | 204072499 | GLOVEBOX TRAY | 1 |
| 4 | 204100049 | PHILLIPS TAPPING SCREW #8 X 1 | 4 |
| 204100057 | FINITION WASHER | ||
| 3 | 232561600 | Hex. Elastic Stop Nut M6 | 3 |
| 3 | 208563060 | OVAL HEAD PHILLIPS COUNTERSUNK SCREW M6 | 3 |
| 3 | 234062600 | Flat Washer M6, Stainless | 3 |
| 204073105 | Console Cap Ass'y, Starboard Fixed Windshield | ||
| 1 | 204072689 | CONSOLE CAP ASS'Y, STARBOARD Retractable Windshield | 1 |
| 204072752 | TRIM, BLACK, 7/16?, METER | ||
| 1 | 211200019 | FLAT WASHER | 1 |
| 1 | 212000005 | NUT-STOP ELASTIC MS-17830 | 1 |
| 204073089 | Console Filler Pad, Starboard | ||
| 204072325 | Interface Bracket | ||
| 2 | 208462060 | PHILLIPS SCREW M6 X 20 | 2 |
| 2 | 234061600 | Stainless Flat Washer M6 | 2 |
| 5 | 232561600 | Hex. Elastic Stop Nut M6 | 5 |
| 204073102 | Console Cap Ass'y, Port Side Fixed Windshield | ||
| 1 | 204072688 | CONSOLE CAP ASS'Y, PORT SIDE Retractable Windshield | 1 |
| 204073088 | Console Filler Pad, Port Side | ||
| 204072447 | ACCESS DOOR | ||
| 209941960 | PHILLIPS SCREW M4.2 X 19 | ||
| 204073154 | Glovebox Door Ass'y, Blue Navy Blue | ||
| 204073182 | Glovebox Door Ass'y, Sage Green Sage Green | ||
| 204072938 | GLOVEBOX LATCH | ||
| 1 | 204072990 | HINGE, BLACK | 1 |
| 8 | 205441660 | Socket Head Screw M4 X 16 | 8 |
| 2 | 204070940 | BUMPER | 2 |
| 219704463 | ADHESIVE LOCTITE 414 28ML | ||
| 1 | 204072500 | DECK CARPET, PORT SIDE | 1 |
| 1 | 204072989 | CONSOLE CARPET, PORT SIDE | 1 |
| 1 | 204072501 | CONSOLE CARPET, PORT SIDE | 1 |
| 204072980 | Console Carpet, Starboard | ||
| 1 | 204070060 | KEEPER | 1 |
| 209641360 | TAPPING PHILLIPS SCREW M4.2 X 13 | ||
| 5 | 204130050 | POP RIVET 3/16 | 5 |
| 1 | 204071498 | RETAINER CABLE | 1 |
| 1 | 293150008 | Pop Rivet 3/16" | 1 |
| 2 | 234052600 | Flat Washer 5 mm, Stainless | 2 |
| 204073156 | Glovebox Upper Cover, Blue Navy Blue | ||
| 204073157 | Glovebox Upper Cover, Sage Green Sage Green | ||
| 1 | 204073197 | HINGE, BLACK | 1 |
| 2 | 232541600 | Elastic Stop Nut M4 | 2 |
| 2 | 234041600 | Flat Washer 4 mm, Stainless | 2 |
| 293150057 | Rivet 1/8” | ||
| 2 | 293150026 | RIVET_POP 1/8 | 2 |
| 204072937 | HATCH SPRING | ||
| 2 | 293150032 | RIVET_POP 1/8 X ,487 | 2 |
| 1 | 204072907 | MAGNETIC CATCH | 1 |
| 6 | 293150036 | RIVET_POP 1/8 X ,750 | 6 |
| 1 | 204072908 | LATCH BRACKET | 1 |
| 1 | 204073168 | LATCH SPACER | 1 |
