Интерактивное демо базы запчастей
Просматривайте запчасти для ATV, мотоциклов, снегоходов, водных моторов и другой техники по марке, году и модели. Каталог доступен для покупки в виде базы данных SQL с изображениями или для аренды.
Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 293720030 | Grommet, 1 Circuit, Blue | ||
| 209461340 | Hex. Screw M6.3 x 13 | ||
| 278000401 | Support Bracket | ||
| 278000586 | IGNITION COIL | ||
| 278000235 | SPACER | ||
| 1 | 278000712 | Battery YUASA YB16CL-B Includes 6 - 9. | 1 |
| 211200018 | FLAT WASHER 6 MM | ||
| 2 | 211000045 | Battery Screw | 2 |
| 2 | 211100022 | Battery Nut M6 | 2 |
| 2 | 293850021 | Rubber Strap | 2 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 278001746 | Lower Battery Pad | ||
| 278001430 | Battery Support | ||
| 278000245 | 3 WIRE SUPPORT | ||
| 1 | 293750009 | Tie-Rap 173 mm | 1 |
| 278000391 | Fuse Block | ||
| 2 | 234161601 | Lock Washer Helical M6 | 2 |
| 293830012 | Rubber Strip | ||
| 5 | 278001008 | Insulated Sheath | 5 |
| 278000514 | Battery Cable (Red) | ||
| 278000300 | Ring Terminal | ||
| 2 | 278000559 | COLLAR SUPPORT | 2 |
| 2 | 278000609 | Spark Plug NGK BR8ES | 2 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 278001009 | Female Terminal | 1 |
| 1 | 209462540 | SCREW-TAPP.HEX.ISO.1479C | 1 |
| 1 | 234061600 | Stainless Flat Washer M6 | 1 |
| 8 | 293150037 | Avdel Rivet 3/16" | 8 |
| 278000098 | GROMMET | ||
| 278000181 | Gasket | ||
| 278000615 | Mounting Plate | ||
| 278000786 | Electric Box Cover | ||
| 278001119 | Electric Box Support | ||
| 278000194 | Temperature Sensor | ||
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
| 1 | 278001268 | Spark Plug Wire | 1 |
| 278000020 | PROTECTION CAP | ||
| 278001085 | Electric Box Base | ||
| 278000682 | Grommet | ||
| 278000123 | RECTIFIER ASS'Y | ||
| 1 | 278001376 | Starter Relay | 1 |
| 3 | 232561600 | Hex. Elastic Stop Nut M6 | 3 |
| 293720025 | GROMMET, 2 CIRCUIT, GRAY | ||
| 1 | 278000228 | FEMALE TERMINAL . | 1 |
| 3 | 232061600 | Hex. Nut M6 | 3 |
| 2 | 210261040 | Hex. Flange Screw M6 X 10 | 2 |
| 278000472 | Engine Harness (Incl. It.19,21,26,47,52,54,57,64,66,67,68) | ||
| 4 | 278000632 | Female Terminal | 4 |
| 278000100 | Electric Wire Cap | ||
| 570026800 | Grommet, 4 Circuit, Red | ||
| 278000193 | GROMMET, 3 CIRCUIT, BLACK | ||
| 278000489 | Temperature Harness Ass'y (Incl. It. 1,52,64,65) | ||
| 2 | 278001008 | Insulated Sheath | 2 |
| 278000237 | SPARK PLUG CAP | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 290964072 | Insulating Sheath | 1 |
| 278001134 | ELECTRONIC MODULE ASS'Y | ||
| 1 | 294000606 | Tie Rap 180 mm | 1 |
| 278000607 | 3 Ways Harness (Fuel / Oil Gauge) | ||
| 3 | 278000230 | Male Terminal | 3 |
| 3 | 278000231 | Insulation Sheath | 3 |
| 1 | 278000738 | Male Lock, 4 Circuits | 1 |
| 1 | 278000739 | Male Connector, 4 Circuits | 1 |
| 278001680 | Ground Cable Battery, no 6, meter) | ||
| 278001681 | Ground Cable Battery, No. 4, Meter | ||
| 278001690 | Cable Battery, no 6, meter) | ||
| 278001691 | Red Cable Battery/Starter (no. 4) (Meter | ||
| 278001682 | Terminal 45°, Small Hole | ||
| 278001683 | TERMINAL 45, SMALL HOLE | ||
| 278001684 | TERMINAL 90, SMALL HOLE | ||
| 278001685 | FLAT TERMINAL, BIG HOLE | ||
| 278001686 | TERMINAL 45, BIG HOLE | ||
| 278001687 | TERMINAL 90, BIG HOLE | ||
| 278001688 | FLAT TERMINAL | ||
| 1 | 219704447 | Was 710000483 Heat Shrink Tubing | 1 |
| 529035730 | Crimp Plier |
