Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204613742 | SLIDE AND SWIVEL SEAT BASE | ||
| 269001903 | SEAT PEDESTAL | ||
| 204100201 | PHILLIPS SCREW 1/4-20 X 1-1/4 | ||
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 8 | 204100134 | TAPPING SCREW 1/4-20 X 3/4 | 8 |
| 8 | 211200025 | Lock Washer 1/4” | 8 |
| 8 | 234082600 | Flat Washer 8 mm, Stainless | 8 |
| 269001591 | Bucket Seat, Alabaster | ||
| 12 | 269001696 | SEAT SUPPORT | 12 |
| 30 | 269001695 | SEAT SUPPORT | 30 |
| 60 | 293150043 | Pop Rivet 3/16" | 60 |
| 293150029 | RIVET_POP 5/32 | ||
| 204100030 | Phillips Screw #8 X 1/2” | ||
| 1 | 204130219 | SPACER MAGNET 1/8'' | 1 |
| 204614513 | MAGNETIC CATCH ASS'Y | ||
| 2 | 204100054 | SCREW 8 X 3/4? | 2 |
| 208442060 | PHILLIPS SCREW M4 X 20 | ||
| 204130264 | Dart 1", White | ||
| 269002036 | REAR CUSHION ASS'Y, PORT | ||
| 269002039 | REAR CENTER CUSHION ASS'Y | ||
| 269002033 | REAR CUSHION ASS'Y, STARBOARD | ||
| 211100026 | HEX. NUT 1/4 | ||
| 8 | 234180602 | Lock Spring Washer 8 mm, Stainless | 8 |
| 204130008 | Plastic Cap, White | ||
| 1 | 269002035 | Lateral Cushion Ass'y, Alabaster, Port | 1 |
| 8 | 269001590 | HINGE, 90 | 8 |
| 204100095 | SLOTTED BOLT 1/4?-20 X 1? | ||
| 269002041 | LATERAL CUSHION ASS'Y, ALABASTER, STARBO | ||
| 1 | 269002044 | REAR LATERAL BACKREST ASS'Y, ALAB PORT | 1 |
| 1 | 269002048 | Rear Backrest Ass'y, Alabaster, Port | 1 |
| 1 | 269002050 | Rear Backrest Ass'y, Alabaster, Starboar | 1 |
| 269002046 | REAR LATERAL BACKREST ASS'Y, ALAB, STARB | ||
| 269002052 | CUSHION ASSY/BOW-PORT | ||
| XXX | Not Available As Spare Parts | ||
| 269002054 | FRONT LATERAL CUSHION ASS'Y, ALAB, STAR | ||
| 269002058 | BACKREST ACCESS DOOR, ALABASTER, PORT | ||
| 204613980 | Hinge | ||
| 28 | 293150011 | Pop Rivet 3/16" | 28 |
| 269002060 | BACKREST ACCESS DOOR, ALABASTER, STARBOA | ||
| 2 | 204614762 | HOLDER | 2 |
| 4 | 204100054 | SCREW 8 X 3/4? | 4 |
| 204614760 | RUBBER HOLDER | ||
| 2 | 204100122 | SCREW-PAN HD. 10-24 UNC X .50 SS | 2 |
| 2 | 204100236 | SCREW-HEX.HD.MACHINE #10 X 1 | 2 |
| 4 | 211200033 | FLAT WASHER | 4 |
| 269002062 | FRONT LATERAL CUSHION, PORT SIDE | ||
| 1 | 269002064 | FRONT LATERAL BACKREST ASS'Y, ALAB., STA | 1 |
| 1 | 269002066 | FRONT CENTER BACKREST, ALABASTER | 1 |
| 269001907 | Sundeck Cushion, Port | ||
| 269001924 | Sundeck Cushion, Starboard |
