Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 279000126 | Shock Absorber GTX IS | 1 |
| 2 | 279000051 | Bushing GTX IS | 2 |
| 1 | 279000055 | SHOCK LOWER HOLDER GTX IS | 1 |
| 1 | 207227060 | HEX. SCREW M12 X 70, SCOTCH GRIP GTX IS | 1 |
| 1 | 250200053 | FLAT WASHER M12 GTX IS | 1 |
| 1 | 279000057 | Shock Upper Holder GTX IS | 1 |
| 6 | 207383060 | Hex. Screw M8 X 30, Scotch Grip GTX IS | 6 |
| 6 | 234080600 | Flat Washer M8, Stainless GTX IS | 6 |
| 279000207 | PUMP GTX IS | ||
| 279000117 | ACTUATOR GTX IS | ||
| 1 | 279000162 | CONNECTOR HOSE GTX IS | 1 |
| 1 | 219704425 | Tubing 6 Mm 3000Mm Long GTX IS | 1 |
| 3 | 293750001 | Tie Wrap 94 mm GTX IS | 3 |
| 1 | 293750008 | Tie Wrap 368 mm GTX IS | 1 |
| 1 | 414115200 | Tie-Rap 180 mm GTX IS | 1 |
| 1 | 293730040 | Mount Dart GTX IS | 1 |
| 1 | 293650079 | Norma Clamp GTX IS | 1 |
| 1 | 279000070 | LH SPRING HOLDER GTX IS | 1 |
| 1 | 279000074 | RH SPRING HOLDER GTX IS | 1 |
| 2 | 279000103 | BUSHING GTX IS | 2 |
| 2 | 279000104 | O-RING GTX IS | 2 |
| 279000105 | COUSSINET *BUSHING GTX IS | ||
| 3 | 205562560 | Socket Head Screw M6 X 25, Scotch Grip GTX IS | 3 |
| 3 | 234061600 | Stainless Flat Washer M6 GTX IS | 3 |
| 1 | 279000128 | PAINTED SPRING GTX IS | 1 |
| 1 | 279000130 | Spring Spacer GTX IS | 1 |
| 1 | 279000131 | PAINTED SPRING GTX IS | 1 |
| 1 | 279000121 | Lower Spring Protector GTX IS | 1 |
| 1 | 279000061 | UPPER SPRING HOLDER GTX IS | 1 |
| 1 | 279000134 | UPPER SPRING PROTECTOR GTX IS | 1 |
| 2 | 279000106 | CLAMP GTX IS | 2 |
| 4 | 207362060 | Hex. Screw M6 X 20, Scotch Grip GTX IS | 4 |
| 4 | 234041600 | Flat Washer 4 mm, Stainless GTX IS | 4 |
| 1 | 270000251 | Position Sensor GTX IS | 1 |
| 1 | 270000544 | O-Ring GTX IS | 1 |
| 1 | 279000098 | POSITION SENSOR BRACKET GTX IS | 1 |
| 1 | 279000099 | SENSOR LEVER GTX IS | 1 |
| 1 | 279000107 | POSITION SENSOR COVER GTX IS | 1 |
| 1 | 279000108 | O-Ring GTX IS | 1 |
| 2 | 207144060 | Hex. Screw M4 X 40 GTX IS | 2 |
| 4 | 234061600 | Stainless Flat Washer M6 GTX IS | 4 |
| 2 | 232541200 | Elastic Stop Nut M4 GTX IS | 2 |
| 1 | 279000139 | THREADED ROD GTX IS | 1 |
| 2 | 234061600 | Stainless Flat Washer M6 GTX IS | 2 |
| 1 | 232561200 | Brass Elastic Stop Nut M6 GTX IS | 1 |
| 279000154 | SPRING ALIGNMENT ADAPTOR GTX IS | ||
| 4 | 205562560 | Socket Head Screw M6 X 25, Scotch Grip GTX IS | 4 |
| 207287560 | HEX. SCREW M8 X 75, SCOTCH GRIP GTX IS | ||
| 1 | 234080600 | Flat Washer M8, Stainless GTX IS | 1 |
| 2 | 279000137 | BUSHING GTX IS | 2 |
| 1 | 279000138 | SPACER GTX IS | 1 |
| 1 | 279000157 | SPRING ALIGNMENT ARM GTX IS | 1 |
| 1 | 207086060 | HEX. SCREW M8 X 60 GTX IS | 1 |
| 2 | 234080600 | Flat Washer M8, Stainless GTX IS | 2 |
| 1 | 279000153 | SPACER GTX IS | 1 |
| 1 | 232581200 | Hex. Elastic Nut M8 Brass GTX IS | 1 |
| 279000008 | CENTRAL BELLOWS GTX IS | ||
| 1 | 279000010 | Retaining Plate GTX IS | 1 |
| 10 | 293150123 | Pop Rivet 3/16" GTX IS | 10 |
| 6 | 250200011 | Flat Washer 8 mm, Stainless GTX IS | 6 |
