Список запчастей

№	Артикул	Название	Кол-во
1	XXX	Not Available As Spare Parts
2	XXX	Not Available As Spare Parts
3	XXX	Not Available As Spare Parts
4	XXX	Not Available As Spare Parts
5	XXX	Not Available As Spare Parts
6	510005181	Seat Cover	1
7	XXX	Not Available As Spare Parts
8	250000129	Torx Screw M6 X 16	2
9	510005309	Backrest Cover	1
10	250000146	Truss Head Torx Screw K50 X 16	3
11	250000197	Torx Truss Screw M8 X 30
13	XXX	Not Available As Spare Parts
14	250200128	Flat Washer 8 mm	2
15	271000558	Spacer	2
16	293100003	Nut Welded, M6	2
18	XXX	Not Available As Spare Parts
19	293150104	Pop Rivet 3/16"	2
20	510005848	RH Handle Ass'y	1
21	XXX	Not Available As Spare Parts
22	293750008	Tie Wrap 368 mm	4
23	515176999	Heated Element	2
24	390402300	Pop Rivet 3/16"	2
25	414115200	Tie-Rap 180 mm	1
26	414644300	Black, Dart	3
27	510004377	Upper Backrest Axle	1
28	510004378	Rubber Shim	2
29	510004379	Washer	2
30	XXX	Not Available As Spare Parts Includes 30b
30b	XXX	Not Available As Spare Parts
31	XXX	Not Available As Spare Parts
32	XXX	Not Available As Spare Parts
33	510004405	Moulding	2
34	510004413	Rocker Switch	1
35	510004414	Switch Protector	1
36	510004423	Foam Support	1
37	XXX	Not Available As Spare Parts
38	510004449	Handle Grip	2
39	XXX	Not Available As Spare Parts
40	510004775	Front Seat Base	1
41	510004777	Front Seat Foam	1
42	510004782	Backrest Foam	1
43	510004791	Rear Seat Foam	1
44	XXX	Not Available As Spare Parts
45	XXX	Not Available As Spare Parts
46	XXX	Not Available As Spare Parts
48	XXX	Not Available As Spare Parts
49	XXX	Not Available As Spare Parts Includes 49 To 49b
49a	XXX	Not Available As Spare Parts
49b	XXX	Not Available As Spare Parts
50	510005009	RH Air Deflector	1
51	510005010	LH Air Deflector	1
52	510005036	Switch Housing	1
54	XXX	Not Available As Spare Parts
55	XXX	Not Available As Spare Parts
56	510005399	Rear Seat Cover	1
57	XXX	Not Available As Spare Parts
59	XXX	Not Available As Spare Parts
60	510005535	Seat Base Ass'y	1
62	510005538	LH Arm, Black	1
62	510005539	RH Arm, Black	1
63	XXX	Not Available As Spare Parts
64	XXX	Not Available As Spare Parts
65	XXX	Not Available As Spare Parts
66	XXX	Not Available As Spare Parts
68	515175283	Housing Support	2
69	XXX	Not Available As Spare Parts
70	515175494	Male Housing, 3 Circuits	1
72	219704426	Was 515175506 Tubing	1
73	250000725	Screw M4 X 16	5
74	510005814	Reinforcement Handle	2
75	510005847	LH Handle Ass'y	1
77	515176033	Male Connector	1
79	515176697	Handle Harness	1
80	XXX	Not Available As Spare Parts
81	XXX	Not Available As Spare Parts
83	515176766	Seat Harness	1
84	XXX	Not Available As Spare Parts
85	XXX	Not Available As Spare Parts
86	XXX	Not Available As Spare Parts
87	516003816	Heated Handle Decal	1
88	516003937	Connector Decal	1
89	XXX	Not Available As Spare Parts
90	XXX	Not Available As Spare Parts
91	XXX	Not Available As Spare Parts
92	708000759	Rubber Stopper	2
93	XXX	Not Available As Spare Parts
