Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| [2N-L4631-10-00 | Unavailable In Price Book | ||
| [2N-L4631-20-00 | Unavailable In Price Book | ||
| 1 | 90340-14118-00 | Plug, Straight Screw | 1 |
| 1 | 214-11198-01-00 | Gasket | 1 |
| 2 | 99530-10014-00 | .Pin, Dowel | 2 |
| 15 | 95023-06040-00 | Bolt, Flange (1Yw) | 15 |
| 2 | 95021-06080-00 | Bolt, Flange | 2 |
| 1 | 93102-44392-00 | Oil Seal, Sd-Type | 1 |
| 2NL-46394-00-00 | Joint | ||
| 2NL-46336-00-00 | Plate 1 | ||
| [97-80206-01-80 | Unavailable In Price Book | ||
| 4 | 92990-06600-00 | Washer, Plate | 4 |
| 90460-80229-00 | Clamp, Hose | ||
| 2NL-46313-00-00 | Cover, Trnsmission | ||
| 2NL-47591-00-00 | Plate | ||
| 3 | 98903-06012-00 | Screw, Bind | 3 |
| 1 | 2N4-15371-00-00 | .Breather | 1 |
| 1 | 93211-23613-00 | O-Ring | 1 |
| 1 | 90445-073F9-00 | Hose (L1200) | 1 |
| 2 | 95023-06020-00 | Bolt, Flange | 2 |
| 90109-084E0-00 | Bolt | ||
| 1 | 90201-08103-00 | Washer, Plate | 1 |
| 1 | 92990-08100-00 | Washer, Spring | 1 |
| 94581-02038-00 | D1d 50Y Chain | ||
| 2NL-46321-00-00 | Shaft, Input | ||
| 93603-14179-00 | Pin, Dowel | ||
| 1 | 93440-14155-00 | Circlip | 1 |
| 2NL-47548-00-00 | Sprocket, Chn Drvn | ||
| 90387-253T4-00 | Collar | ||
| 2NL-46316-00-00 | Gear, Pinion 1 | ||
| 1 | 93410-25017-00 | Circlip | 1 |
| 1 | 90201-257J2-00 | Washer, Plate | 1 |
| 1 | 93306-205U0-00 | Bearing | 1 |
| 1 | 93306-20541-00 | Bearing (B6205) | 1 |
| [2N-L4634-80-00 | Unavailable In Price Book | ||
| 2NL-46326-00-00 | Gear, Wheel 1 | ||
| 2NL-46317-00-00 | Gear, Pinion 2 | ||
| 1 | 99009-26400-00 | Circlip | 1 |
| 1 | 99009-20400-00 | Circlip | 1 |
| 2NL-46239-00-00 | Stopper | ||
| 1 | 93306-00426-00 | Bearing | 1 |
| 2NL-46349-00-00 | Shaft 3 | ||
| 2NL-46327-00-00 | Gear, Wheel 2 | ||
| 2NL-46318-00-00 | Gear, Pinion 3 (22T) | ||
| 2 | 99009-30400-00 | .Circlip | 2 |
| 2 | 90201-251G8-00 | Washer, Plate | 2 |
| 3 | 93306-30560-00 | Bearing | 3 |
| 2NL-46328-00-00 | Gear, Wheel 3 | ||
| 1 | 93306-20716-00 | Bearing | 1 |
| 1 | 93306-00704-00 | .Bearing | 1 |
| 2HT-17811-00-00 | Housing, Tach. Gear | ||
| [2N-L1783-10-00 | Unavailable In Price Book | ||
| [2N-L1784-10-00 | Unavailable In Price Book | ||
| 90201-12M34-00 | .Washer, Plate | ||
| 2HT-15416-00-00 | Cover, Oil Pump | ||
| 1 | 93102-08307-00 | Oil Seal | 1 |
| 1 | 93210-24253-00 | O-Ring | 1 |
| 1 | 98503-06014-00 | Screw, Pan Head | 1 |
| 2 | 90201-08452-00 | Washer, Plate | 2 |
| 59V-15453-01-00 | Gasket, Carb Cover | ||
| 3 | 98506-06025-00 | Screw, Pan Head | 3 |
| 3 | 90201-063F3-00 | Washer, Plate | 3 |
| 1 | 91311-06016-00 | Bolt | 1 |
| 1 | 90201-063F3-00 | Washer, Plate | 1 |
| 1 | 98580-06030-00 | .Screw, Pan Head | 1 |
| 1 | 90430-06014-00 | Gasket | 1 |
| 2 | 95811-08050-00 | Bolt, Flange | 2 |
| 2 | 95811-08070-00 | Bolt, Flange | 2 |
| 2 | 90201-08107-00 | Washer, Plate | 2 |
| 4 | 95601-08200-00 | Nut, U | 4 |
| 2NL-2149E-00-00 | Stopper | ||
| 90101-08675-00 | Bolt | ||
| 2 | 95333-08600-00 | Nut | 2 |
| 90462-08168-00 | Clamp 2Nl | ||
| 1 | 90465-08028-00 | Clamp | 1 |
| 4 | 90387-060U2-00 | Collar | 4 |
