Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204072673 | RH Side Rail Ass'y Starboard, Includes 1 To 5 | ||
| 204072674 | LH Side Rail Ass'y Port Side, Includes 1 To 5 | ||
| 204072856 | Rail Insert, Front | ||
| 1 | 204100194 | SOCKET SCREW, 3/8-16 X 1 | 1 |
| 204072857 | Rail Insert, Rear Starboard | ||
| 204072858 | Rail Insert, Rear Port Side | ||
| 204100195 | Socket Screw, 3/8-16 x 3/4" | ||
| 10 | 204100135 | HEX. SCREW 3/8 X 1-1/2 | 10 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 10 | 234101601 | Helicoidal Lock Washer M10 | 10 |
| 10 | 234002600 | Flat Washer 10 mm, Stainless | 10 |
| 2 | 204130063 | GASKET, FRONT | 2 |
| 2 | 204130064 | GASKET, REAR | 2 |
| 6 | 291000619 | CUP HOLDER | 6 |
| 204000130 | Elevator Bolt | ||
| 234381608 | TOOTHED LOCK WASHER | ||
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 211100026 | HEX. NUT 1/4 | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 1 | 291001057 | FIXED TUBE | 1 |
| 293830045 | RUBBER WASHER | ||
| 3 | 208564060 | PHILLIPS SCREW M6 X 40 | 3 |
| 1 | 204072616 | SKI SHAFT | 1 |
| 1 | 293000004 | SKI SHAFT CAP | 1 |
| 211400004 | ROLLED PIN M3 X 30 | ||
| 1 | 204071839 | FIXATION PLATE | 1 |
| 291001060 | RETAINER WASHER | ||
| 3 | 207162060 | Hex. Forming Screw M6 X 20 | 3 |
| 6 | 234062600 | Flat Washer M6, Stainless | 6 |
| 3 | 232561600 | Hex. Elastic Stop Nut M6 | 3 |
| 1 | 291001205 | SPRING | 1 |
| 293550010 | Synthetic Grease, 400 G | ||
| 1 | 570023800 | Windshield Latch | 1 |
| 4 | 234062600 | Flat Washer M6, Stainless | 4 |
| 2 | 212000005 | NUT-STOP ELASTIC MS-17830 | 2 |
| 2 | 204071935 | SOUNDWALL SEAL | 2 |
| 8 | 293730014 | Black Dart | 8 |
| 2 | 204073065 | SHOCK BRACKET | 2 |
| 6 | 293150043 | Pop Rivet 3/16" | 6 |
| 6 | 234051600 | Flat Washer M5, Stainless | 6 |
| 1 | 204072466 | BOW COVER | 1 |
| 1 | 219704365 | Was 293200017 Neoprene Seal | 1 |
| 1 | 204071937 | FLUSH LATCH | 1 |
| 1 | 204073074 | Shock Bracket | 1 |
| 207341260 | Hex. Screw M4 X 12, Scotch Grip | ||
| 6 | 207162560 | Hex. Screw M6 X 25 | 6 |
| 6 | 207161660 | Hex. Screw M6 X 16 | 6 |
| 12 | 234061600 | Stainless Flat Washer M6 | 12 |
| 2 | 204071918 | CYLINDER GAS SHOCK | 2 |
| 204070127 | HINGE ASS'Y Includes 48 to 50 | ||
| 204070204 | HINGE ROD | ||
| 204070205 | Cotter Pin M2.5 X 12 | ||
| 1 | 204072027 | LATCH PLATE | 1 |
| 202000203 | SCREW-TAPP.TRUSS HD.PH.M4.2X25 | ||
| 204071783 | DRAIN FITTING | ||
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 1 | 219704412 | Polyurethane Hose, 8 Mm 3000Mm Long | 1 |
