Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1VE-Y284E-00-2X | Travel Trunk Comp | ||
| 1VE-2840H-00-00 | . Graphic Set, Travel Trunk | ||
| 54K-2842J-01-00 | . Emblem 3 | ||
| [5G-78212-10-00 | . Pad, Battery | ||
| 54K-2847F-00-00 | Seal 5 | ||
| 54K-2845E-00-00 | Hinge 2 | ||
| 90159-05132-00 | Screw, With Washer | ||
| 1NL-2845L-00-00 | Stopper, Open | ||
| 1NL-2845M-00-00 | Stopper, Open | ||
| 97701-30606-00 | Screw, Tapping (97701-30106) | ||
| 1NL-2849R-00-00 | Bracket, Trunk Stopper | ||
| 54K-2844L-00-00 | Hook | ||
| 54K-2849F-00-00 | Seal 7 | ||
| 54K-2849M-00-00 | Nut, Special | ||
| 97701-40710-00 | Screw, Tapping | ||
| 7 | 90480-10068-00 | .Grommet | 7 |
| 1NL-28476-00-00 | Bracket 3 | ||
| 1NL-28485-00-00 | Plate, Rubber 3 | ||
| 8 | 95306-05800-00 | Nut (Crown) | 8 |
| 54K-85140-00-00 | Rear Reflector Ass''y | ||
| 54K-28488-00-00 | Hook | ||
| 4 | 90201-06059-00 | Washer, Plate | 4 |
| 4 | 98506-05010-00 | Screw, Pan Head | 4 |
| 1 | 90338-07180-00 | Plug | 1 |
| 4 | 90338-06181-00 | Plug | 4 |
| 26H-2843A-00-00 | Damper, Grip | ||
| 2 | 95023-06010-00 | Bolt, Flange | 2 |
| 54K-28497-00-00 | Plate 3 | ||
| 54K-2849J-00-00 | Plate, Rubber 9 | ||
| 6 | 95306-06800-00 | Nut | 6 |
| 2 | 90202-06058-00 | Washer, Plate | 2 |
| 1NL-2845K-00-00 | Plate, Rubber 10 | ||
| 6 | 92906-06100-00 | Washer, Spring | 6 |
| 1NL-2843K-00-00 | Reinforcement 4 | ||
| 2 | 90387-060A3-00 | Collar | 2 |
| 2 | 90202-08125-00 | .Washer, Plate | 2 |
| 54K-28408-00-00 | Grip, Saddlebag | ||
| 6 | 90202-08146-00 | Washer, Plate | 6 |
| 2 | 90201-05721-00 | Washer, Plate | 2 |
| 6 | 98506-05008-00 | Screw, Pan Head | 6 |
| 54K-28493-00-00 | Cover Lock Ass''y 2 | ||
| 54K-2848H-00-00 | Seat | ||
| 1VE-2840F-00-00 | Back Rest Assembly | ||
| 1NL-28444-00-00 | Hinge 1 | ||
| 1NL-2846M-01-00 | Bracket, Hinge | ||
| 1NL-2846N-01-00 | Bracket, Hinge 2 | ||
| 1NL-2847H-00-00 | Plate 5 | ||
| 1NL-2847J-00-00 | Plate, Rubber 7 | ||
| 6 | 95306-05800-00 | Nut (Crown) | 6 |
| 1NL-28477-01-00 | Bracket 4 | ||
| 1NL-2849H-00-00 | Plate 6 | ||
| 1NL-2846J-00-00 | Plate, Rubber 6 | ||
| 2 | 95306-05800-00 | Nut (Crown) | 2 |
| 1NL-2844M-00-00 | Shaft 1 | ||
| 2 | 99080-05600-00 | Circlip | 2 |
| 8 | 90386-06108-00 | Bush | 8 |
| 1NL-28478-00-00 | Rod | ||
| 1NL-28424-00-00 | Joint, Cage | ||
| 1NL-2841A-01-00 | Lever | ||
| 1 | 98506-05016-00 | Screw, Pan Head | 1 |
| 1 | 92906-05100-00 | Washer, Spring | 1 |
| 1 | 92906-05600-00 | Washer, Plate | 1 |
| 1 | 90209-06223-00 | Washer | 1 |
| 1NL-2843M-00-00 | Wire, Adjusting | ||
| 1NL-28489-00-00 | Spring | ||
| 1NL-2848A-00-00 | Spring 2 | ||
| 1 | 90506-12029-00 | Spring, Torsion | 1 |
| 1 | 583-83981-00-00 | .Lever, Decompression | 1 |
| 1 | 583-83913-00-00 | Collar, Decompression Lever | 1 |
| 1 | 95306-05800-00 | Nut (Crown) | 1 |
| 1NL-82912-00-00 | Holder, Lever Upper 1 | ||
| 1NL-82913-00-00 | Holder, Lever Lower 1 | ||
| 1 | 98506-06010-00 | Screw, Pan Head | 1 |
| 1 | 92906-06600-00 | Washer | 1 |
| 1KH-26257-00-00 | Stopper | ||
| 1NL-2842M-00-GA | Cover 1 Orion Silver | ||
| 1NL-2844U-00-00 | Moulding 10 | ||
| 2 | 90110-05079-00 | Bolt, Hexagon Head | 2 |
| 2 | 90202-05088-00 | Washer, Plate | 2 |
| 1NL-2842N-00-00 | Cover 2 | ||
| 4 | 97780-40112-00 | Screw, Tapping | 4 |
| 1NL-2843J-00-00 | Cover 3 | ||
| 2 | 90159-05134-00 | Screw, W/Washer | 2 |
| 1VE-28401-00-00 | Pouch Comp. 1 | ||
| 1VE-28402-00-00 | Pouch, 2 | ||
| 1VE-2840R-00-00 | Rest, Arm L/H | ||
| 1VE-2840T-00-00 | Rest, Arm R/H | ||
| 2 | 98506-05016-00 | Screw, Pan Head | 2 |
| 2 | 92906-05100-00 | Washer, Spring | 2 |
| 4 | 90202-05147-00 | Washer, Plate | 4 |
| 4 | 90201-05721-00 | Washer, Plate | 4 |
