Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4718-414 | Panel, Side w/Decals - Right - White (inc. 2-10) | ||
| 1 | 3718-454 | Panel, Side - w/o Decals - Right - White (inc. 3-7) | 1 |
| 1 | 0617-626 | Foam, Side Panel - Upper Front - Right | 1 |
| 1 | 6606-414 | Foil, Protective | 1 |
| 1 | 0617-628 | Foam, Side Panel - Upper Rear - Right | 1 |
| 1 | 0617-632 | Foam, Side Panel - Lower Front - Right | 1 |
| 1 | 6606-416 | Foil, Protective | 1 |
| 1621-468 | Decal, Side Panel - Upper - Right | ||
| 1 | 1621-470 | Decal, Side Panel - Lower - Right | 1 |
| 1 | 1621-472 | Decal, Side Panel - Forward - Right | 1 |
| 4718-419 | PANEL,SIDE-LH W/DECALS (XF 9000 SP ORN) (inc. 12-18) | ||
| 4718-559 | Panel, Side - w/o Decals - Left - White (inc. 13-15) | ||
| 1 | 0617-669 | Foam, Side Panel - Upper Rear - Left | 1 |
| 1 | 0617-635 | Foam, Side Panel - Lower Rear - Left | 1 |
| 1 | 0617-681 | Foam, Side Panel - Lower Front - Left | 1 |
| 1621-475 | DECAL,SIDE PANEL-UPR LH XF TURBO ORN | ||
| 1 | 1621-471 | Decal, Side Panel - Lower - Left | 1 |
| 1 | 1621-473 | Decal, Side Panel - Forward - Left | 1 |
| 1 | 1623-637 | Clip, U-Nut | 1 |
| 2 | 0607-447 | Cable | 2 |
| 2 | 0605-283 | Clip, Hairpin | 2 |
| 2 | 8060-486 | Rivet | 2 |
| 2 | 8050-127 | Washer | 2 |
| 2 | 1623-052 | Clip, U-Nut | 2 |
| 1 | 6606-925 | Screen, Intake | 1 |
| 1 | 2602-794 | Duct, Intake - Inner | 1 |
| 3 | 1623-030 | Clip, U-Nut | 3 |
| 2602-803 | Duct, Intake - Outer - White | ||
| 1 | 0608-648 | Vent, Heat Duct | 1 |
| 3 | 1623-469 | Nut, Stamped | 3 |
| 1 | 0708-596 | Duct, Heat | 1 |
| 1702-367 | Duct, Air - Clutch | ||
| 1 | 3718-422 | Plate, Skid - w/o Decals - Right - Black (inc. 34-40) | 1 |
| 1 | 0617-640 | Foam, Skid Plate - Upper Rear - Right | 1 |
| 1 | 0617-638 | Foam, Skid Plate - Center Front - Right | 1 |
| 1 | 0617-636 | Foam, Skid Plate - Upper Front - Right | 1 |
| 1 | 2612-850 | Foil, Protective | 1 |
| 1 | 8061-708 | Rivet | 1 |
| 1 | 2612-754 | Deflector, Heat | 1 |
| 8 | 0123-802 | Washer | 8 |
| 1 | 3718-789 | Plate, Skid - Left w/Foam - Black (inc. 42-45) | 1 |
| 1 | 0617-637 | Foam, Skid Plate - Upper Front - Left | 1 |
| 1 | 0617-639 | Foam, Skid Plate - Center Front - Left | 1 |
| 1 | 0617-641 | Foam, Skid Plate - Upper Rear - Left | 1 |
| 1 | 6606-613 | Panel, Reinforcement | 1 |
| 2 | 2623-005 | Clip, Retaining | 2 |
| 2 | 6606-592 | Pin, Retaining | 2 |
| 1623-129 | Screw, Self-Tapping | ||
| 1 | 2612-796 | Plate, Exhaust Outlet | 1 |
| 1 | 2612-799 | Seal, Exhaust Outlet | 1 |
| 6 | 8061-710 | Rivet | 6 |
| 1 | 3718-302 | Fascia, Front - Right - Black (inc. 53) | 1 |
| 1 | 6606-404 | Foil, Protective | 1 |
| 1 | 6606-351 | Fascia, Front - Left - Black | 1 |
| 2 | 0623-784 | Screw, Self-Tapping | 2 |
| 1 | 2623-001 | RETAINER,PUSHNUT - 3/16" STUD Optional | 1 |
| 1 | 1623-999 | Screw, Thumb Optional | 1 |
