Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 45501-16G21-YAY | COVER, SEAT TAIL, R (BLACK) MODEL K6/K7 | 1 |
| 45501-16G21-YBA | COVER, SEAT TAIL, R (BLUE) MODEL K6 | ||
| 45501-16G21-YHG | COVER, SEAT TAIL, R (GRAY) MODEL K6 | ||
| 45501-16G21-YKY | COVER, SEAT TAIL, R (BLUE) MODEL K7; Includes Item(s) 2 - 2 | ||
| 45511-16G02-YAY | COVER, SEAT TAIL, R (BLACK) MODEL K6/K7 | ||
| 45511-16G02-YBA | COVER, SEAT TAIL, R (BLUE) MODEL K6 | ||
| 1 | 45511-16G02-YHG | COVER, SEAT TAIL, R (GRAY) MODEL K6 | 1 |
| 45511-16G02-YKY | COVER, SEAT TAIL, R (BLUE) MODEL K7; Includes Item(s) 3 - 5 | ||
| 1 | 45516-42F00 | TAPE, SEAT TAIL COVER FR | 1 |
| 45517-16G10 | TAPE, SEAT TAIL COVER FR NO.2 | ||
| 1 | 47161-10D00 | TAPE, SEAT TAIL COVER FR NO.3 | 1 |
| 45502-16G21-YAY | COVER, SEAT TAIL, L (BLACK) MODEL K6/K7 | ||
| 45502-16G21-YBA | COVER, SEAT TAIL, L (BLUE) MODEL K6 | ||
| 45502-16G21-YHG | COVER, SEAT TAIL, L (GRAY) MODEL K6 | ||
| 45502-16G21-YKY | COVER, SEAT TAIL, L (BLUE) MODEL K7; Includes Item(s) 7 - 10 | ||
| 45512-16G02-YAY | COVER, SEAT TAIL, L (BLACK) MODEL K6/K7 | ||
| 45512-16G02-YBA | COVER, SEAT TAIL, L (BLUE) MODEL K6 | ||
| 45512-16G02-YHG | COVER, SEAT TAIL, L (GRAY) MODEL K6 | ||
| 45512-16G02-YKY | COVER, SEAT TAIL, L (GRAY) MODEL K7 | ||
| 2 | 09136-06082 | SCREW FR | 2 |
| 2 | 09136-06082 | SCREW CTR | 2 |
| 2 | 09180-06286 | SPACER FR | 2 |
| 2 | 09180-06286 | SPACER CTR | 2 |
| 2 | 09320-10052 | CUSHION FR | 2 |
| 2 | 47115-16G00 | CUSHION,SEAT TAIL COVER CTR CTR | 2 |
| 2 | 09320-20010 | CUSHION (20X32X9) RR | 2 |
| 1 | 03241-15123 | SCREW MODEL K6 | 1 |
| 1 | 03241-1512B | SCREW MODEL K7 | 1 |
| 1 | 09148-05038 | NUT | 1 |
| 1 | 45503-16G00-YAY | COVER, SEAT TAIL, CENTER (BLACK) MODEL K6/K7 | 1 |
| 1 | 45503-16G00-YBA | COVER, SEAT TAIL, CENTER (BLUE) MODEL K6 | 1 |
| 1 | 45503-16G00-YHG | COVER, SEAT TAIL, CENTER (GRAY) MODEL K6 | 1 |
| 45503-16G00-YKY | COVER, SEAT TAIL, CENTER (BLUE) MODEL K7; Includes Item(s) 21 - 24 | ||
| 1 | 68161-16G00-YD8 | .EMBLEM,"SUZUKI" (SILVER) FOR YAY,YBA,YKY | 1 |
| 68161-16G00-17U | EMBLEM, "SUZUKI" FOR YHG | ||
| 1 | 45518-16G00 | CUSHION,SEAT TAIL COVER CTR | 1 |
| 2 | 45517-16G00 | TAPE, SEAT TAIL COVER | 2 |
| 2 | 45516-42F00 | TAPE | 2 |
| 1 | 45514-16G00-YAY | COVER, SEAT TAIL, REAR (BLACK) MODEL K6/K7 | 1 |
| 1 | 45514-16G00-YBA | COVER, SEAT TAIL, REAR (BLUE) MODEL K6 | 1 |
| 45514-16G00-YHG | COVER, SEAT TAIL, REAR (GRAY) MODEL K6 | ||
| 1 | 45514-16G00-YKY | COVER, SEAT TAIL, REAR (BLUE) MODEL K7 | 1 |
| 4 | 09148-06018 | NUT | 4 |
| 9 | 09409-06314-5PK | CLIP | 9 |
| 46211-16G00-YAY | HANDLE, PILLION RIDER (BLACK) MODEL K6/K7 | ||
| 46211-16G00-YBA | HANDLE, PILLION RIDER (BLUE) MODEL K6 | ||
| 46211-16G00-YHG | HANDLE, PILLION RIDER (GRAY) MODEL K6 | ||
| 46211-16G00-YKY | HANDLE, PILLION RIDER (BLUE) MODEL K7 | ||
| 2 | 01551-08403 | BOLT MODEL K6 | 2 |
| 2 | 01551-0840B | BOLT MODEL K7 | 2 |
| 2 | 09160-08501 | WASHER MODEL K6 | 2 |
| 2 | 09160-08158 | WASHER (8.5X24X2.3) MODEL K7 | 2 |
| 2 | 09180-06271 | SPACER | 2 |
| 2 | 09139-06112 | SCREW | 2 |
