Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 40543-384-920 | ADJUSTER, DRIVE CHAIN | 1 |
| 1 | 40543-397-000 | ADJUSTER, DRIVE CHAIN | 1 |
| 1 | 40543-397-890 | ADJUSTER, DRIVE CHAIN | 1 |
| 41201-383-670 | SPROCKET, FINAL DRIVEN (35T) | ||
| 4 | 41241-222-000 | BUSH, RR. WHEEL DAMPER | 4 |
| 42304-107-000 | COLLAR, RR. WHEEL SIDE | ||
| 42610-383-305 | HUB, RR. WHEEL | ||
| 42620-107-010 | COLLAR, RR. AXLE DISTANCE | ||
| 42701-383-701 | RIM, RR. WHEEL (1.60X17) (DAIDO) | ||
| 42711-108-671 | TIRE, RR. (3.00-17) (NITTO) | ||
| 42711-108-672 | TIRE, RR. (3.00-17) (BS) | ||
| 42711-383-671 | TIRE, RR. (3.00-17) (BS) | ||
| 42711-383-672 | TIRE, RR. (3.00-17) (NITTO) | ||
| 42712-033-000 | TUBE, TIRE (2.75-17) | ||
| 42712-102-009 | TUBE, TIRE (2.75-17) (YOKOHAMA) TUBE, TIRE (2.75S17) (INOUE) | ||
| 44712-GC4-671 | TUBE, TIRE (2.75S17) (INOUE) TUBE, TIRE (2.75-17) | ||
| 44712-169-701 | TUBE, TIRE (2.75-17) | ||
| 44712-244-000 | TUBE, TIRE (2.75-17) TUBE, TIRE (3.00-17) (NITTO) | ||
| 44712-303-006 | TUBE, TIRE (3.00-17) (NITTO) | ||
| 0Y400-03310 | TUBE, TIRE (2.75-17) | ||
| 08400-03310 | TUBE, TIRE (2.75-17) | ||
| 42712-102-761 | TUBE, TIRE (2.75-17) (INOUE) | ||
| 42712-303-003 | TUBE, RR. WHEEL (2.75/3.00-17) (BS) | ||
| 44712-303-003 | TUBE, TIRE (2.75/3.00-17) (BS) | ||
| 1 | 42713-102-005 | FLAP, TIRE (17) (INOUE) FLAP, TIRE (17) (NITTO) | 1 |
| 1 | 44713-200-006 | FLAP, TIRE (17) (NITTO) | 1 |
| 44713-200-003 | FLAP, TIRE (1.60-17) (BS) | ||
| 4 | 90128-216-000 | BOLT, DRIVEN SPROCKET FIXING | 4 |
| 1 | 90305-401-680 | NUT, AXLE (14MM) | 1 |
| 1 | 90664-216-000 | CIRCLIP (58MM) | 1 |
| 1 | 91257-230-003 | OIL SEAL (28X42X7) (ARAI) | 1 |
| 1 | 90310-KA3-711 | NUT, HEX. (6MM) | 1 |
| 1 | 94000-06000-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06000 | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06000-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06008-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06200-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94030-06000 | NUT, HEX. (6MM) | 1 |
| 4 | 94031-08000 | NUT, HEX. (8MM) | 4 |
| 1 | 94101-06000 | WASHER, PLAIN (6MM) | 1 |
| 1 | 94101-06080 | WASHER, PLAIN (6MM) | 1 |
| 1 | 94101-06800 | WASHER, PLAIN (6MM) | 1 |
| 2 | 94108-13000 | WASHER A3, TONGUED | 2 |
| 1 | 94111-06000 | WASHER, SPRING (6MM) | 1 |
| 1 | 94201-30250 | PIN, SPLIT (3.0X25) | 1 |
| 1 | 94201-30300 | PIN, COTTER (3X30) | 1 |
| 1 | 94201-30400 | PIN, COTTER (3.0X40) | 1 |
| 1 | 94201-30450 | PIN, SPLIT (3.0X45) | 1 |
| 1 | 96140-62020 | BEARING, RADIAL BALL (6202U) | 1 |
| 1 | 96140-63020 | BEARING, RADIAL BALL (6302U) | 1 |
| 18 | 97310-59159-10 | SPOKE BS (9X159.5) (INSIDE) | 18 |
| 18 | 97518-59158-10 | SPOKE BS (9X159) (OUTSIDE) | 18 |
