Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8GS-47541-00-00 | Housing, Chain | 1 |
| 1 | 93306-20601-00 | Bearing | 1 |
| 1 | 93304-20511-00 | Bearing | 1 |
| 1 | 93102-30012-00 | Oil Seal | 1 |
| 1 | 93102-35010-00 | Oil Seal | 1 |
| 1 | 99009-62500-00 | Circlip | 1 |
| 1 | 99009-52500-00 | Circlip | 1 |
| 1 | 8GS-47558-00-00 | Ring, Housing | 1 |
| 1 | 90101-10357-00 | Bolt | 1 |
| 1 | 95307-10600-00 | Nut | 1 |
| 1 | 93210-25071-00 | O-Ring | 1 |
| 1 | 90387-2508C-00 | Collar | 1 |
| 1 | 97002-08014-00 | Bolt | 1 |
| 1 | 90210-08017-00 | Washer, Seal | 1 |
| 1 | 8GS-1761A-00-00 | Shaft 1 | 1 |
| 1 | 8CW-47591-00-00 | Plate | 1 |
| 4 | 90105-060A6-00 | Bolt, Flange | 4 |
| 1 | 8JE-1761E-00-00 | Shaft 2 | 1 |
| 1 | 8GS-47591-00-00 | Plate | 1 |
| 1 | 93306-00208-00 | Bearing | 1 |
| 1 | 93102-15212-00 | Oil Seal | 1 |
| 1 | 8GS-18541-01-00 | Cam, Shift | 1 |
| 1 | 8GS-18191-00-00 | Lever | 1 |
| 1 | 2H9-18154-00-00 | . .Cover, Dust | 1 |
| 1 | 8GS-18115-00-00 | Rod, Shift | 1 |
| 1 | 90170-08358-00 | Nut | 1 |
| 1 | 95307-08700-00 | Nut | 1 |
| 1 | 3X3-18157-10-00 | Joint 2 | 1 |
| 1 | 90201-06099-00 | Washer, Plate | 1 |
| 1 | 90101-06047-00 | Bolt | 1 |
| 1 | 8GS-47554-01-00 | Washer, Lock | 1 |
| 1 | 8GS-47543-10-00 | Cap, Housing | 1 |
| 1 | 93306-20511-00 | Bearing | 1 |
| 2 | 90179-10679-00 | Nut | 2 |
| 2 | 93606-20044-00 | Pin, Dowel | 2 |
| 1 | 93306-00711-00 | Bearing | 1 |
| 1 | 3Y1-15361-00-00 | Gauge, Level | 1 |
| 1 | 5LP-82540-01-00 | Neutral Switch Assy | 1 |
| 1 | 90430-10148-00 | Gasket | 1 |
| 3 | 95822-08030-00 | Bolt, Flange | 3 |
| 2 | 95822-10045-00 | Bolt, Flange | 2 |
| 1 | 95602-10200-00 | Nut, S/L Flange | 1 |
| 2 | 95822-10090-00 | Bolt, Flange | 2 |
| 95822-06025-00 | Bolt, Flange | ||
| 1 | 8HX-47613-00-00 | Holder | 1 |
| 1 | 8HX-47611-00-00 | Tensioner | 1 |
| 1 | 90249-12216-00 | Pin | 1 |
| 1 | 99009-12400-00 | Circlip | 1 |
| 1 | 8GS-47546-00-00 | Level, Oil | 1 |
| 1 | 90387-30005-00 | Collar | 1 |
| 1 | 8FA-17682-00-00 | Sprocket, Chain Drive (20T) | 1 |
| 1 | 90208-26002-00 | Washer, Conical Spring | 1 |
| 1 | 90387-26007-00 | Collar | 1 |
| 1 | 94890-09068-00 | Chain (68L) | 1 |
| 1 | 8KW-47587-00-00 | Sprocket, Chain Driven | 1 |
| 1 | 93317-33179-00 | Bearing | 1 |
| 1 | 90387-2008G-00 | Collar | 1 |
| 1 | 90201-320S3-00 | Washer, Plate | 1 |
| 1 | 90105-10223-00 | Bolt, Flange | 1 |
| 1 | 90387-25018-00 | Collar | 1 |
| 1 | 90113-06064-00 | Bolt, Set | 1 |
| 1 | 8FB-17692-00-00 | Sprocket, Drive (18T) | 1 |
| 1 | 93317-21578-00 | .Bearing | 1 |
| 2 | 90501-050A0-00 | Spring, Compression | 2 |
| 1 | 8JE-1714A-00-00 | Reverse Pinion Assy | 1 |
| 2 | 93317-21578-00 | . .Bearing | 2 |
| 4 | 90201-16245-00 | Washer, Plate | 4 |
| 1 | 90105-060A6-00 | Bolt, Flange | 1 |
| 1 | 90210-06006-00 | Washer, Seal | 1 |
| 1 | 90105-08153-00 | Bolt, Flange | 1 |
| 1 | 8GS-47571-00-00 | Journal 1 | 1 |
| 1 | 8JE-17243-00-00 | Gear, Reverse Wheel 1 | 1 |
| 1 | 8CW-17492-00-00 | Dog, Transmission Shift | 1 |
| 5 | 90501-066J5-00 | Spring, Compression | 5 |
| 1 | 93440-39175-00 | Circlip | 1 |
| 1 | 8GS-47564-00-00 | Collar | 1 |
| 1 | 8KW-17210-00-00 | 1St Wheel Gear Assy | 1 |
| 1 | 8JE-17110-00-00 | 1St Pinion Gear Assy | 1 |
| 1 | 8GS-18511-00-00 | Fork, Shift 1 | 1 |
| 1 | 8GS-18531-00-00 | Bar, Shift Fork Guide 1 | 1 |
| 1 | 93503-08007-00 | Ball | 1 |
| 1 | 90501-10353-00 | Spring, Compression | 1 |
| 1 | 90105-14003-00 | Bolt, Flange | 1 |
| 1 | 90430-14043-00 | Gasket | 1 |
| 1 | 93210-25642-00 | O-Ring | 1 |
