Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 13200-36E30 | CARBURETOR ASSY MODEL X | ||
| 13200-36E40 | CARBURETOR ASSY MODEL Y; Includes Item(s) 1 - 23 | ||
| 1 | 13681-43D30 | CAP, CARBURETOR | 1 |
| 13260-43D30 | CAP SET, TOP | ||
| 13573-43D30 | SPRING, THROTTLE VALVE | ||
| 1 | 13424-43D30 | COLLAR, THROTTLE VALVE | 1 |
| 1 | 13581-43D30 | HOLDER, CABLE | 1 |
| 1 | 13394-28E00 | .CLIP, NEEDLE | 1 |
| 13551-36E00 | VALVE, THROTTLE | ||
| 1 | 09491-36008 | JET, MAIN (180) MODEL X | 1 |
| 1 | 09491-35009 | JET, MAIN (175) MODEL Y | 1 |
| 1 | 09492-55017 | JET, PILOT (55) MODEL X | 1 |
| 1 | 09492-50023 | .JET, SLOW (50) MODEL Y | 1 |
| 1 | 13696-44E00 | GASKET, FLOAT CHAMBER | 1 |
| 1 | 13370-43D30 | VALVE SET, FLOAT | 1 |
| 13240-28E00 | FLOAT SET | ||
| 1 | 13247-28E00 | .BOLT, DRAIN | 1 |
| 1 | 13246-28E00 | O RING | 1 |
| 4 | 02112-34163 | SCREW | 4 |
| 2 | 13693-36E00 | PLATE | 2 |
| 1 | 13270-43D30 | SCREW SET, STOP | 1 |
| 1 | 13280-43D30 | SCREW SET, AIR | 1 |
| 1 | 13410-43D30 | STARTER VALVE MODEL X | 1 |
| 13410-36E40 | STARTER VALVE MODEL Y | ||
| 4 | 13686-36E00 | .HOSE, (4X7X620) UP/RH L:620(r)580 UP/LH L:620(r)550 RH L:620(r)400 LH L:620(r)360 | 4 |
| 5 | 09401-06101 | CLIP | 5 |
| 1 | 09351-35653-600 | HOSE (3.5X6.5X600) L:600(r)330 | 1 |
| 13383-28E00 | NEEDLE, JET (R1469MS) MODEL X | ||
| 13383-36E20 | NEEDLE, JET (R1469L) MODEL Y | ||
| 1 | 09492-55019 | JET, POWER (55) Includes Item(s) 25 - 30 | 1 |
| 13247-44E00 | SCREW, DRAIN | ||
| 13256-44E00 | O RING | ||
| 1 | 13160-37E00 | SOLENOID ASSY MODEL X | 1 |
| 1 | 13160-37E01 | SOLENOID ASSY MODEL Y | 1 |
| 1 | 13453-37E00 | O RING | 1 |
| 13451-37E00 | CLAMP | ||
| 13452-37E00 | SCREW | ||
| 1 | 09404-06429 | CLAMP, AIR VENT (L:60) MODEL X | 1 |
| 1 | 09404-06432 | CLAMP, AIR VENT (L:60) MODEL Y | 1 |
| 1 | 09404-08206 | CLAMP, CARBURETOR HOSE (L:82) | 1 |
| 13383-28E00 | NEEDLE, JET (R1469MS) OPT,MODEL X | ||
| 13383-28E10 | NEEDLE, JET (R1469NS) OPT,MODEL X | ||
| 13383-28E20 | NEEDLE, JET (R1470MS) OPT,MODEL X | ||
| 13383-28E30 | NEEDLE, JET (R1470NS) OPT,MODEL X | ||
| 13383-28E40 | NEEDLE, JET (R1471MS) OPT,MODEL X | ||
| 13383-28E50 | NEEDLE, JET (R1471NS) OPT,MODEL X | ||
| 13383-37E00 | NEEDLE, JET (R1466MS) OPT,MODEL X | ||
| 13383-37E10 | NEEDLE, JET (R1466NS) OPT,MODEL X | ||
| 13383-43D30 | NEEDLE, JET (R1468NS) OPT,MODEL X | ||
| 13383-43D40 | NEEDLE, JET (R1468MS) OPT,MODEL X | ||
| 13383-43D50 | NEEDLE, JET (R1467NS) OPT,MODEL X | ||
| 13383-43D60 | NEEDLE, JET (R1467MS) OPT,MODEL X | ||
| 13383-36E00 | NEEDLE, JET (R1467LS) OPT,MODEL Y | ||
| 13383-36E10 | NEEDLE, JET (R1468LS) OPT,MODEL Y | ||
| 13383-36E20 | NEEDLE, JET (R1469LS) OPT,MODEL Y | ||
| 13383-36E30 | NEEDLE, JET (R1470LS) OPT,MODEL Y | ||
| 13383-36E40 | NEEDLE, JET (R1471LS) OPT,MODEL Y | ||
| 13383-36E50 | NEEDLE, JET (R1467KS) OPT,MODEL Y | ||
| 13383-36E60 | NEEDLE, JET (R1468KS) OPT,MODEL Y | ||
| 13383-36E70 | NEEDLE, JET (R1469KS) OPT,MODEL Y | ||
| 13383-36E80 | NEEDLE, JET (R1470KS) OPT,MODEL Y | ||
| 13383-36E90 | NEEDLE, JET (R1471KS) OPT,MODEL Y | ||
| 09491-29014 | JET, MAIN (145) OPT | ||
| 09491-29015 | JET, MAIN (148) OPT | ||
| 1 | 09491-30018 | JET, MAIN (150) OPT | 1 |
| 1 | 09491-30019 | JET, MAIN (152) OPT | 1 |
| 1 | 09491-31012 | JET, MAIN (155) OPT | 1 |
| 1 | 09491-31013 | JET, MAIN (158) OPT | 1 |
| 1 | 09491-32010 | JET, MAIN (160) OPT | 1 |
| 1 | 09491-32011 | JET, MAIN (162) OPT | 1 |
| 1 | 09491-33009 | JET, MAIN (165) OPT | 1 |
| 1 | 09491-33010 | JET, MAIN (168) OPT | 1 |
| 1 | 09491-34010 | JET, MAIN (170) OPT | 1 |
| 1 | 09491-34011 | JET, MAIN (172) OPT | 1 |
| 1 | 09491-35009 | JET, MAIN (175) OPT | 1 |
| 1 | 09491-35010 | JET, MAIN (178) OPT | 1 |
| 1 | 09491-36008 | JET, MAIN (180) OPT | 1 |
| 09491-37008 | JET, MAIN (185) OPT | ||
| 09491-38011 | JET, MAIN (190) OPT | ||
| 09491-39001 | JET, MAIN (195) OPT | ||
| 1 | 09491-40013 | JET, MAIN (200) OPT | 1 |
| 1 | 09492-35019 | JET, PILOT (35) OPT | 1 |
| 1 | 09492-40022 | JET, PILOT (40) OPT | 1 |
| 1 | 09492-45032 | JET, PILOT (45) OPT | 1 |
| 1 | 09492-50023 | .JET, SLOW (50) OPT | 1 |
| 1 | 09492-52011 | JET, PILOT (52) OPT | 1 |
| 1 | 09492-55017 | JET, PILOT (55) OPT | 1 |
| 1 | 09492-58001 | JET, PILOT (58) OPT | 1 |
| 09492-60016 | JET, PILOT (60) OPT | ||
| 09492-65008 | JET, PILOT (65) OPT | ||
| 09492-70009 | JET, PILOT (70) OPT | ||
| 09492-50025 | JET, POWER (50) OPT | ||
| 1 | 09492-55019 | JET, POWER (55) OPT | 1 |
| 09492-60018 | JET, POWER (60) OPT |
