Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 15707-634-000 | CLIP, OIL DRAIN | 1 |
| 15761-428-670 | TUBE A, BREATHER | ||
| 15762-428-670 | TUBE B, BREATHER | ||
| 1 | 15772-292-010 | CLIP, BREATHER TUBE | 1 |
| 17201-428-000 | STAY, AIR CLEANER | ||
| 1 | 17211-428-000 | ELEMENT, AIR CLEANER | 1 |
| 17213-428-300 | RUBBER, ELEMENT SEAL | ||
| 17214-428-000 | HOLDER, ELEMENT | ||
| 17217-385-000 | SPRING, ELEMENT | ||
| 1 | 17219-413-000 | SEAL, AIR CLEANER COVER | 1 |
| 17220-428-870ZA | COVER, AIR CLEANER HOUSING *R33* (WOL) (HELIOS RED) | ||
| 17222-428-000 | TUBE, AIR CLEANER CONNECTING | ||
| 17230-428-000 | HOUSING, AIR CLEANER | ||
| 17231-428-300 | HOLDER, SET SPRING | ||
| 17240-428-000 | TUBE, AIR CLEANER IN. | ||
| 1 | 17252-428-000 | BAND A, CONNECTING TUBE | 1 |
| 1 | 90652-GHB-690 | BAND, AIR CLEANER CONNECTING TUBE (52) | 1 |
| 1 | 95018-52250 | BAND, AIR CLEANER CONNECTING TUBE (52) | 1 |
| 17254-428-000 | NUT, AIR CLEANER SETTING | ||
| 17260-428-000 | PROTECTOR, AIR CLEANER | ||
| 2 | 17316-611-000 | CLIP, BREATHER TUBE | 2 |
| 1 | 17359-428-000 | JOINT, BREATHER TUBE | 1 |
| 17361-419-670 | BODY, BREATHER SEPARATOR | ||
| 17362-419-670 | CAP, BREATHER SEPARATOR | ||
| 17363-419-670 | HOLDER, ELEMENT | ||
| 17364-419-000 | ELEMENT, CONDENSATION | ||
| 17365-428-670 | TUBE, BREATHER JOINT | ||
| 1 | 17366-428-670 | TUBE A, DRAIN | 1 |
| 17367-428-000 | RUBBER, BREATHER SEAL | ||
| 17368-428-000 | PLATE, SEPARATE BACK | ||
| 17369-428-670 | TUBE B, DRAIN | ||
| 1 | 17370-382-870 | PLUG, BREATHER TUBE | 1 |
| 32975-428-000 | CLIP, PULSER CABLE | ||
| 32976-428-000 | CLIP, CABLE | ||
| 2 | 83551-300-000 | GROMMET, AIR CLEANER HOUSING | 2 |
| 83600-428-870ZA | COVER, R. SIDE *R33* (WOL) (HELIOS RED) | ||
| 87507-435-670 | LABEL, AIR CLEANER CAUTION | ||
| 90112-434-000 | BOLT A, AIR CLEANER HOUSING SETTING | ||
| 90113-434-000 | BOLT C, AIR CLEANER HOUSING SETTING | ||
| 90114-429-000 | BOLT B, AIR CLEANER HOUSING | ||
| 91305-419-670 | O-RING (47X1.9) | ||
| 91462-393-780 | CLIP, TUBE | ||
| 1 | 91463-393-780 | JOINT, TUBE | 1 |
| 1 | 93500-05025-0G | SCREW, PAN (5X25) | 1 |
| 3 | 93891-04020-08 | SCREW-WASHER (4X20) | 3 |
| 5 | 93901-34520 | SCREW, TAPPING (4X20) | 5 |
| 1 | 95002-01160 | CLIP, TUBE (A16) | 1 |
| 4 | 95002-02130 | CLIP, TUBE (B12.5) | 4 |
| 1 | 95003-23003-10M | TUBE, VINYL (8X12X3000) (8X12X380) | 1 |
| 4 | 95700-06012-00 | BOLT, FLANGE (6X12) | 4 |
| 4 | 95701-06012-00 | BOLT, FLANGE (6X12) | 4 |
