Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 293800015 | Lubrifiant - Deoxit, 250 ml | 1 |
| 1 | 278000646 | Emergency Switch Includes 3 - 6. | 1 |
| 1 | 278000273 | Male Housing, 3 Circuits | 1 |
| 3 | 278000223 | Female Terminal | 3 |
| 3 | 278000218 | Wire Seal | 3 |
| 204470025 | Safety Strap | ||
| 1 | 295500444 | Safety Landyard Ass'y | 1 |
| 1 | 278000508 | Safety Switch Nut | 1 |
| 1 | 204470108 | Fan Ass'y Includes 10 - 13. | 1 |
| 1 | 278000220 | Male Connector, 2 Circuits | 1 |
| 2 | 278000223 | Female Terminal | 2 |
| 2 | 278000218 | Wire Seal | 2 |
| 1 | 204000133 | BROACH | 1 |
| 278000887 | BUZZER ASSEMBY Includes 15 - 17. | ||
| 2 | 278000222 | Male Terminal | 2 |
| 2 | 278000217 | Female Housing, 2 Circuits | 2 |
| 278000707 | Buzzer Nut | ||
| 204470071 | Front Lamp | ||
| 1 | 204470072 | FRONT LAMP SUPPORT | 1 |
| 3 | 211000011 | Screw M4 x 16 | 3 |
| 278000674 | Rear Light Base Ass'y Includes 23 - 27. | ||
| 204471177 | Rear Lamp Base Ass'y | ||
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 211000136 | Screw M4 x 30 | ||
| 204470022 | Rear Lamp Pole Includes 29 - 30. | ||
| 204470053 | Bulb | ||
| 219704457 | Loctite Adhesive 425 20ML | ||
| 278000970 | SPEED SENSOR ASSY Includes 32 - 34. | ||
| 1 | 293710031 | ELECTRIC CONNECTION | 1 |
| 295500108 | Paddle Wheel Kit | ||
| 1 | 278000416 | SEAL WASHER | 1 |
| 216351060 | SCREW-CTSK.OV.HD.PH.DIN.966A-A2 | ||
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 204000130 | Elevator Bolt | ||
| 213400001 | WASHER-LOCK TOOTHED DIN.6797A-A2 | ||
| 211100026 | HEX. NUT 1/4 | ||
| 3 | 278000542 | SWITCH CAP | 3 |
| 278000647 | Switch Nut | ||
| 204470106 | OIL LEVEL SENSOR ASS'Y Includes 43 - 46. | ||
| 204470104 | Grommet | ||
| 204470144 | Fuel/Oil Gauge | ||
| 204470145 | Gasket | ||
| 204470146 | Gauge Nut | ||
| 1 | 204470220 | Bilge Pump | 1 |
| 204470147 | Speedometer Gauge | ||
| 204470148 | Tachometer Gauge | ||
| 1 | 204470038 | WATER SENSOR Includes 54 - 57. | 1 |
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 204470058 | Sensor Support | ||
| 4 | 293250085 | O-Ring | 4 |
| 204470140 | Harness Ass'y | ||
| 204470139 | Electronic Module Ass'y Includes 62 - 69. | ||
| 278000379 | Fuse Holder | ||
| 278001069 | FUSE HOLDER COVER | ||
| 278001070 | Cover Seal | ||
| 2 | 278001197 | Fuse, 10 Amperes | 2 |
| 278001196 | FUSE, 3 AMPERES | ||
| 3 | 278000344 | Fuse, 5 Amperes | 3 |
| 2 | 278000704 | FUSE, 7.5 AMPERES | 2 |
| 12 | 213200007 | Washer 6 mm | 12 |
| 4 | 212000005 | NUT-STOP ELASTIC MS-17830 | 4 |
| XXXX | Not Available As Spare Part - Rivet 5/32 | ||
| 278000622 | RH IGNITION SWITCH | ||
| 278000621 | IGNITION SWITCH | ||
| 278000565 | IGNITION SWITCH CAP, RED | ||
| 278000540 | Fan Switch | ||
| 278000541 | Light Switch |
