Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 0832-050 | BEARING,CONRAD-6304 | 2 |
| 0828-010 | WASHER,THRUST, SECONDARY TRANSMISSION | ||
| 1402-558 | GEAR,DRV-NO.2 (18 TOOTH) (RB: 0822-140) (18T) | ||
| 0822-091 | COUNTERSHAFT ASSY (NFG) (inc. 5-18) | ||
| 2 | 0831-011 | RING, EXTERNAL RETAINING - DSH-25 | 2 |
| 1 | 0822-014 | DOG, REVERSE GEAR | 1 |
| 1 | 0822-045 | INSERT,GEAR | 1 |
| 2 | 0828-008 | WASHER, SECONDARY TRANSMISSION | 2 |
| 1 | 0822-013 | GEAR, REVERSE DRIVEN | 1 |
| 3 | 0832-011 | Bearing | 3 |
| 3 | 0822-005 | BUSHING | 3 |
| 0828-015 | WASHER, LOCK, SECONDARY TRANSMISSION | ||
| 1 | 0828-014 | WASHER, SECONDARY TRANSMISSION | 1 |
| 0822-004 | GEAR,DRIVEN-LOW (40T) (40T) | ||
| 0822-046 | SHIM,DRIVE GEAR SPACER | ||
| 1 | 0822-003 | COUNTERSHAFT | 1 |
| 1 | 0822-007 | GEAR, DOG SLIDING | 1 |
| 0822-006 | GEAR,DRIVEN-HIGH (30T) (30T) | ||
| 0828-011 | WASHER, STEEL 20 x 40 x 1 | ||
| 2 | 0818-072 | FORK,SHIFT R/B 0818-171 | 2 |
| 1 | 0818-006 | SHAFT, SHIFT FORK | 1 |
| 1 | 0822-052 | SEAL, COUNTER SHAFT RH | 1 |
| 1 | 0831-040 | RING, EXTERNAL RETAINING - DSH-17 | 1 |
| 1 | 0822-050 | TRIGGER, SPEEDO SENSOR | 1 |
| 1 | 0828-069 | WASHER, THRUST | 1 |
| 1 | 0831-039 | RING,EXTERNAL RETAINING - DSH-13 | 1 |
| 1 | 0830-129 | GASKET,ODOMETER DRIVE | 1 |
| 2 | 0829-023 | Pin, Dowel | 2 |
| 1 | 0822-049 | HOUSING, SPEEDO SENSOR | 1 |
| 0830-107 | SEAL,FASTENER | ||
| 2 | 8468-645 | Screw, Machine | 2 |
| 1 | 0824-042 | Sensor, Speedometer | 1 |
| 1 | 8468-620 | Screw, Machine | 1 |
| 1 | 0828-038 | WASHER, STEEL, 6 x 14 x .9 | 1 |
| 1 | 0818-002 | Stopper, Cam | 1 |
| 1 | 0818-004 | SUPPORT, CAM STOPPER | 1 |
| 1 | 0818-028 | SPRING, TORSION, CAM ARM | 1 |
| 1 | 0828-035 | WASHER, STEEL 6 x 16 x 2.5 | 1 |
| 1 | 8424-602 | NUT,HEX-FLG M6X1.0 CL8 Z&Y | 1 |
| 1402-556 | STOP,SPRING-SELECTOR | ||
| 2 | 0828-036 | WASHER, STEEL, 12 x 20 x .9 | 2 |
| 2 | 0831-010 | RING, EXTERNAL RETAINING - DSH-12 | 2 |
| 1 | 0818-007 | SHAFT, SUB-GEAR SHIFT | 1 |
| 1 | 1402-557 | GASKET,COVER-SELECTOR | 1 |
| 1502-009 | COVER,SELECTOR,GEARBOX-MACH | ||
| 6 | 8405-620 | SCREW,CAP-HH M6X1.0X20 CL10.9 Z&BL | 6 |
| 1 | 0830-044 | SEAL, SUB-GEAR SHIFT | 1 |
| 1 | 0818-164 | ARM,GEAR SELECT-ASSY | 1 |
| 1 | 0818-089 | DETENT CAM,GEAR SHIFT | 1 |
| 1 | 0826-006 | SCREW,CAP HFH M6 x 1 x 25 | 1 |
| 1 | 0812-006 | PLUG, DRAIN MAGNETIC | 1 |
| 1 | 0830-017 | GASKET, METAL, COMPRESSION | 1 |
| 1 | 1402-102 | BARB, 90 DEGREE | 1 |
| 1 | 0402-333 | Plug, Fill (inc. 55) | 1 |
| 1 | 0423-154 | O-Ring | 1 |
| 1 | 0819-063 | YOKE,PROPELLER SHAFT-ASSY | 1 |
| 1 | 1402-164 | CROSS, UNIVERSAL(20mm)-SET (inc. 58) | 1 |
| 4 | 0423-450 | RING,RETAINING-CROSS | 4 |
| 2 | 0827-013 | NUT,HEX SHOULDER M16X1.5 | 2 |
| 2 | 0828-020 | WASHER, STEEL, 16.3 x 30 x 3 | 2 |
| 1 | 0819-061 | YOKE,DRIVE OUTPUT-FRONT ASSY | 1 |
| 2 | 0830-043 | SEAL,OIL-DRIVEN SHAFT | 2 |
| 1 | 0832-017 | BEARING, DRIVEN SHAFT (RB 0832-107) | 1 |
| 1 | 0828-026 | SHIM, 25 x 34 x 1.00 | 1 |
| 1 | 1402-554 | Shaft, Output - Secondary | 1 |
| 0819-002 | GEAR,(USE 0822-146-H1, 0822-147-H2) | ||
| 1 | 1402-555 | SLEEVE,BEARING | 1 |
| 1 | 0832-016 | BEARING, DRIVEN GEAR | 1 |
| 1 | 0819-011 | RING, DRIVEN BEARING | 1 |
| 1 | 0819-005 | FLANGE, OUTPUT JOINT - REAR, ASSEMBLY | 1 |
| 1 | 0470-689 | DIPSTICK | 1 |
| 2506-388 | TUBE,DIPSTICK-BLACK | ||
| 1 | 0423-465 | GROMMET,RUBBER-12.7X23.8125 | 1 |
| 2506-445 | BRKT,DIPSTICK TUBE - PTD | ||
| 0423-715 | O-RING,12.7 X 1.78 | ||
| 2 | 0423-396 | Screw, Self-Tapping | 2 |
