Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4718-316 | Panel, Side - w/Decals - Right - White (inc. 2-11) | ||
| 3718-766 | Panel, Side - w/o Decals - Right - White (inc. 3-7) (Up to Serial #101030) | ||
| 1 | 3718-454 | Panel, Side - w/o Decals - Right - White (inc. 3-7) (Above Serial #101030) | 1 |
| 1 | 0617-626 | Foam, Side Panel - Upper Front - Right | 1 |
| 1 | 6606-414 | Foil, Protective | 1 |
| 1 | 0617-628 | Foam, Side Panel - Upper Rear - Right | 1 |
| 1 | 0617-632 | Foam, Side Panel - Lower Front - Right | 1 |
| 1 | 6606-416 | Foil, Protective | 1 |
| 1621-660 | Decal, Side Panel - Upper - Right | ||
| 1 | 1621-672 | Decal, Side Panel - Lower Rear - Right | 1 |
| 1621-670 | Decal, Side Panel - Center - Right | ||
| 1621-674 | Decal, Side Panel - Lower Front - Right | ||
| 4718-317 | Panel, Side - w/Decals - Left - White (inc. 13-23) | ||
| 1 | 4718-111 | Panel, Side - w/o Decals - Left - White (inc. 14-19) (Up to Serial #101030) | 1 |
| 1 | 4718-103 | Panel, Side - w/o Decals - Left - White (inc. 14-19) (Above Serial #101030) | 1 |
| 1 | 0617-629 | Foam, Side Panel - Upper Rear - Left | 1 |
| 1 | 0617-635 | Foam, Side Panel - Lower Rear - Left | 1 |
| 1 | 0617-631 | Foam, Side Panel - Center Front - Left | 1 |
| 1 | 0617-681 | Foam, Side Panel - Lower Front - Left | 1 |
| 1 | 2602-704 | Screen, Vent | 1 |
| 8 | 0623-269 | Clip, Retaining | 8 |
| 1621-661 | Decal, Side Panel - Upper - Left | ||
| 1 | 1621-673 | Decal, Side Panel - Lower Rear - Left | 1 |
| 1621-671 | Decal, Side Panel - Center - Left | ||
| 1621-675 | Decal, Side Panel - Lower Front - Left | ||
| 1 | 1623-637 | Clip, U-Nut | 1 |
| 2 | 0607-447 | Cable | 2 |
| 2 | 0605-283 | Clip, Hairpin | 2 |
| 2 | 8060-486 | Rivet | 2 |
| 2 | 8050-127 | Washer | 2 |
| 1 | 1702-369 | Duct, Belt Cooling | 1 |
| 2 | 1623-030 | Clip, U-Nut | 2 |
| 4 | 0623-797 | Screw, Self-Tapping | 4 |
| 1 | 2602-711 | Deflector, Air | 1 |
| 1 | 2602-703 | Retainer, Air Deflector | 1 |
| 1 | 4718-330 | Plate, Skid - w/Decals - Right - White (inc. 35-42) | 1 |
| 4718-332 | Plate, Skid - w/o Decals - Right - White (inc. 36-38) (Up to Serial #101030) | ||
| 4718-534 | Plate, Skid - w/o Decals - Right - White (inc. 36-38) (Above Serial #101030) | ||
| 1 | 0617-640 | Foam, Skid Plate - Upper Rear - Right | 1 |
| 1 | 0617-638 | Foam, Skid Plate - Center Front - Right | 1 |
| 1 | 0617-636 | Foam, Skid Plate - Upper Front - Right | 1 |
| 1 | 1621-678 | Decal, Skid Plate - Front - Right | 1 |
| 1 | 1621-676 | Decal, Skid Plate - Upper - Right | 1 |
| 1 | 1621-680 | Decal, Skid Plate - Lower - Right | 1 |
| 1 | 1621-682 | Decal, Skid Plate - Rear - Right | 1 |
| 18 | 8061-708 | Rivet | 18 |
| 1 | 4718-207 | Plate, Skid - w/Decals - Left - White (inc. 45-55) | 1 |
| 1 | 3718-769 | Plate, Skid - w/o Decals - Left - White (inc. 46-51) (Up to Serial #101030) | 1 |
| 1 | 4718-533 | Plate, Skid - w/o Decals - Left - White (inc. 46-51) (Above Serial #101030) | 1 |
| 1 | 0617-637 | Foam, Skid Plate - Upper Front - Left | 1 |
| 1 | 0617-639 | Foam, Skid Plate - Center Front - Left | 1 |
| 1 | 0617-641 | Foam, Skid Plate - Upper Rear - Left | 1 |
| 3 | 0123-802 | Washer | 3 |
| 1 | 6606-613 | Panel, Reinforcement | 1 |
| 3 | 8061-688 | Rivet | 3 |
| 1 | 1621-679 | Decal, Skid Plate - Front - Left | 1 |
| 1 | 1621-677 | Decal, Skid Plate - Upper - Left | 1 |
| 1621-681 | Decal, Skid Plate - Lower - Left | ||
| 1 | 1621-683 | Decal, Skid Plate - Rear - Left | 1 |
| 2 | 2623-005 | Clip, Retaining | 2 |
| 2 | 6606-592 | Pin, Retaining | 2 |
| 1623-129 | Screw, Self-Tapping | ||
| 1 | 2612-685 | Plate, Exhaust Outlet | 1 |
| 1 | 2612-964 | Seal, Exhaust Outlet | 1 |
| 6 | 8061-508 | Rivet | 6 |
| 1 | 6606-342 | Fascia, Front - Right - Black | 1 |
| 1 | 6606-579 | Fascia, Front - Left - Black | 1 |
| 2 | 0623-784 | Screw, Self-Tapping | 2 |
| 1 | 2623-001 | RETAINER,PUSHNUT - 3/16" STUD Optional | 1 |
| 1 | 1623-999 | Screw, Thumb Optional | 1 |
