Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2681382 | CUSHION, SEAT (Incl. 2-7,12,75) (400 Only) | ||
| 2681330 | COVER,SEAT (650 Only) | ||
| 2681380 | SEAT COVER ASM(400'89) (400 Only) | ||
| 5430425 | HOUSING,TAILLIGHT | ||
| 4030019 | BULB, BRAKELIGHT | ||
| 5430423 | Discontinued | ||
| 7511840 | SCREW | ||
| 5 | 7542122 | NYLOK NUT | 5 |
| 2 | 7558221 | WASHER(10) | 2 |
| 5430575 | GROMMET-GAS TANK | ||
| 2681331 | COVER,TANK,'88(650) (650 Only) | ||
| 2681381 | COVER,TANK,ASM(400'89) (400 Only) | ||
| 2681290 | BUCKLE&STRAP | ||
| 1 | 5810142 | GAS CAP GASKET | 1 |
| 1 | 2511149 | GAS CAP WITH GAUGE | 1 |
| 1 | 7042020 | SPRING, TANK | 1 |
| 5221722 | STRAP,GASTANK,BLK. | ||
| 5420126 | Discontinued | ||
| 2511150 | TANK,GAS | ||
| 1 | 7052037 | FUEL PICKUP WITH FILTER, 105 MI | 1 |
| 1 | 7052023 | FITTING, OUTLET | 1 |
| 2200190 | N/A,USE COMPONENTS | ||
| 5430579 | VENT-TANK | ||
| 2 | 5810063 | PAD-GAS TANK (650 Only) | 2 |
| 34 | 7621457 | RIVET | 34 |
| 7080288 | PLUG | ||
| 6 | 7621402 | POP RIVET (400 Only) | 6 |
| 6 | 7621403 | BLIND RIVET (650 Only) | 6 |
| 2200250 | FOOTREST ASM,LH | ||
| 2200254 | FOOTREST ASM,RH | ||
| 2200303 | FOOTREST,LH,(650) (650 Only) | ||
| 2200304 | FOOTREST,RH,(650) (650 Only) | ||
| 1 | 7621452 | RIVET | 1 |
| 14 | 7621330 | POP RIVET | 14 |
| 4020035 | CLIP,WIRING | ||
| 5210728 | HINGE | ||
| 6 | 7558212 | WASHER,13/64X1/2X18GA,FL-Y (10) | 6 |
| 52 | 7621429 | RIVET | 52 |
| 2 | 5220817 | BELT RETAINER CLIP | 2 |
| 5230118 | SUBSTITUTED BY 5240965 | ||
| 1 | 7080216 | CLUTCH GUARD PIN | 1 |
| 1011664 | SUBSTITUTED BY 1011804 (400 Only) | ||
| 1011665 | TUNNEL ASM,('89-650) (650 Only) | ||
| 1011695 | TUNNEL ASM.(650SKS) (650 SKS Only w/1011694) | ||
| 10 | 7661620 | RIVET | 10 |
| 3 | 7670021 | NUT, SPEED | 3 |
| 7080227 | SNAP-MALE | ||
| 7072153 | DECAL, WARNING | ||
| 5224334 | BUMPER,REAR,BLK. | ||
| 5224349 | BUMPER, (SKS) (650 SKS Only) | ||
| 7072132 | DECAL, TRACK (400 Only) | ||
| 7072637 | DECAL,TRACK,SILVER(650) (650 Only) | ||
| 5220478 | PANEL,TUNNEL,BACK | ||
| 1011718 | CLOSE-OFF ASM,REAR (650 SKS Only) | ||
| 1 | 5410521 | SNOW FLAP | 1 |
| 5 | 7621418 | RIVET(50) | 5 |
| 5222061 | WEARPLATE,TUNNEL | ||
| 7072414 | DECAL (650 SKS Only) | ||
| 2 | 2670070 | REFLECTOR, RED | 2 |
| 2 | 7512103 | BOLT | 2 |
| 6 | 7621222 | RIVET(10) (650 & 650 SKS Only) | 6 |
| 5220634 | PLATE,TUNNEL,LH | ||
| 5220635 | PLATE,TUNNEL,RH | ||
| 5810201 | FOAM, FILLER | ||
| 7072078 | DECAL(47.5'')TUNNEL (400 Only) | ||
| 3 | 7512193 | CARRIAGE BOLT | 3 |
| 5220406 | BRACKET, HINGE | ||
| 1011582 | SUPT., MUFFLER | ||
| 5221932 | BRACKET, GASTANK | ||
| 1011613 | BULKHEAD, (400) (400 Only) | ||
| 1011614 | BULKHEAD,(600/650) (650 Only) | ||
| 4 | 7558301 | FLAT WASHER | 4 |
| 5430930 | Discontinued | ||
| 4 | 7511863 | SCREW | 4 |
| 4 | 7512240 | BOLT | 4 |
| 7072582 | DECAL,36'',R.BUMP (650 Only) | ||
| 7072590 | DECAL,REAR BUMPER (400 Only) | ||
| 2 | 7542451 | NYLOK NUT (650 SKS Only) | 2 |
| 7515493 | BOLT,NYLOC,BLACK (650 SKS Only) | ||
| 1011666 | BRKT,R.SUSP,LH MTG. | ||
| 1011667 | BRKT,R.SUSP,RH MTG. | ||
| 5220542 | BRKT. | ||
| 5220973 | BRKT, TOOL BOX | ||
| 5430707 | SEAT BUN | ||
| 1011808 | TUNNEL,(LIQ.PLAIN) (500) | ||
| 1 | 5431893 | PLUG TRAP | 1 |
| 1 | 7052028 | GROMMET | 1 |
| 7072558 | DECAL,CLUTCH,POLARIS | ||
| 2681329 | CUSHION,SEAT,'88(650) (Incl. 2-7,12,75) (650 Only) |
