Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 715008475 | Black, Frame Kit Model 64po Width | 1 |
| 1 | 715008479 | Chalk, Frame KIt Model 72po Width | 1 |
| 1 | 250000913 | Weld Pin 8mm X 40mm | 1 |
| 1 | 250100059 | Nut M6 | 1 |
| 1 | 705207424 | Front Plate | 1 |
| 2 | 207562034 | Hex. Flange Screw M6 X 20, Scotch Grip | 2 |
| 15 | 250100199 | Insert Half Hex Body M6 x 1.0 | 15 |
| 1 | 705206992 | Bumper Link | 1 |
| 1 | 250000857 | Flange Screw M12 X 60 | 1 |
| 1 | 250000060 | Flange Screw M10 X 16, Scotch Grip | 1 |
| 1 | 715007603 | Front Bumper Kit | 1 |
| 1 | 715006996 | Front Master Plate | 1 |
| 6 | 250100198 | Panel Nut M6 X 1.0 | 6 |
| 6 | 250000722 | Torx Screw M6 X 20 | 6 |
| 2 | 705202455 | Cap | 2 |
| 1 | 705206983 | U-Clamp | 1 |
| 2 | 233201436 | Hex. Flange Elastic Nut M10 | 2 |
| 1 | 705210064 | Deep Black, Reinforcement Cage Model 64po Width | 1 |
| 1 | 705210065 | Magma Red, Reinforcement Cage Model 72po Width | 1 |
| 1 | 705206924 | DPS Support | 1 |
| 2 | 207581244 | Hex. Flange Screw M8 X 12, Scotch Grip | 2 |
| 2 | 233281416 | Hex. Elastic Flange Nut M8 | 2 |
| 1 | 705210278 | Rear Upper Plate | 1 |
| 1 | 705210281 | Rear Central Plate | 1 |
| 1 | 705210275 | Rear Lower Plate | 1 |
| 2 | 705205926 | Black, LH Link Plate Model 64po Width | 2 |
| 2 | 705209144 | Magma Red, Connecting Plate Model 72po Width | 2 |
| 1 | 715008492 | Junction Plate Kit | 1 |
| 4 | 250001195 | Elastic Flange Nut M12 | 4 |
| 2 | 705210066 | Deep Black, Rear Pillar Model 64po Width | 2 |
| 2 | 705210067 | Magma Red, Rear Pillar Model 72po Width | 2 |
| 4 | 705210648 | Sleeve | 4 |
| 1 | 705210001 | Safety Belt Anchorage | 1 |
| 4 | 232521416 | Elastic Stop Nut M12 | 4 |
| 1 | 705207425 | Upper Arm Link | 1 |
| 1 | 705210249 | Retaining Plate | 1 |
| 1 | 706203122 | Support | 1 |
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 1 | 715002889 | Black, Front Intrusion Bar Model 72po Width | 1 |
| 1 | 715003531 | Common Parts Kit Model 72po Width | 1 |
| 1 | 704904566 | Decal "Can-Am" Model 72po Width | 1 |
| 2 | 705205709 | Black, Clamp Model 72po Width | 2 |
| 1 | 705210068 | Deep Black, Front Cross Member Model 64po Width | 1 |
| 1 | 705210069 | Magma Red, Front Cross Member Model 72po Width | 1 |
| 1 | 705210070 | Deep Black, Rear Cross Member Model 64po Width | 1 |
| 1 | 705210071 | Magma Red, Rear Cross Member Model 72po Width | 1 |
| 1 | 715008442 | Black, LH Cage Kit Model 64po Width | 1 |
| 1 | 715008444 | Magma Red, LH Cage Kit Model 72po Width | 1 |
| 1 | 715008456 | Black, RH Cage Kit Model 64po Width | 1 |
| 1 | 715008458 | Magma Red, RH Cage Kit Model 72po Width | 1 |
| 8 | 250001195 | Elastic Flange Nut M12 | 8 |
| 14 | 207523056 | Hex. Flange Screw M12 X 30, Scotch Grip | 14 |
| 6 | 250001195 | Elastic Flange Nut M12 | 6 |
| 4 | 250000857 | Flange Screw M12 X 60 | 4 |
| 4 | 293150102 | Rivet 3/16" | 4 |
| 4 | 250000901 | Torx Truss M8 X 65 | 4 |
| 4 | 250100025 | Elastic Flange Nut M8 | 4 |
