Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1707-809 | Complete Chassis Assembly White | ||
| 1 | 1707-914 | Tunnel Assembly White (inc. 2-14) | 1 |
| 1 | 1707-911 | Tunnel, Front - Assembly White (inc. 3-5) | 1 |
| 2 | 1623-797 | Insert | 2 |
| 1 | 1707-918 | Bracket, Mounting - Suspension - Right - White | 1 |
| 1 | 1707-919 | Bracket, Mounting - Suspension - Left - White | 1 |
| 1 | 8060-686 | Rivet - Zinc | 1 |
| 1 | 1623-241 | Rivet | 1 |
| 6 | 8422-502 | Nut, Lock | 6 |
| 1 | 1707-904 | Bracket, Mounting - Rear Spar - Right - White | 1 |
| 1 | 1707-905 | Bracket, Mounting - Rear Spar - Left - White | 1 |
| 6 | 8476-512 | Screw, Machine | 6 |
| 2 | 1623-257 | Rivet | 2 |
| 1 | 8060-682 | Rivet | 1 |
| 1 | 1707-837 | Tunnel, Rear White | 1 |
| 1 | 8060-484 | Rivet | 1 |
| 1707-834 | End Cap, Tunnel - White | ||
| 2 | 8408-516 | Screw, Cap | 2 |
| 1 | 0630-288 | Regulator, Voltage | 1 |
| 1 | 0645-709 | Clip, Routing | 1 |
| 1 | 1623-984 | Clamp, Routing | 1 |
| 2 | 8476-820 | Screw, Machine | 2 |
| 1 | 1707-800 | Support, Footrest - Right - White | 1 |
| 1 | 1707-801 | Support, Footrest - Left - White | 1 |
| 2 | 8427-802 | Nut, Lock | 2 |
| 0744-064 | Kit, Tool | ||
| 4 | 8468-536 | Screw, Machine | 4 |
| 8 | 1623-637 | Clip, U-Nut | 8 |
| 1 | 1707-802 | Footrest - Right - White | 1 |
| 1 | 1707-803 | Footrest - Left - White | 1 |
| 4 | 8470-516 | Screw, Machine | 4 |
| 1 | 1607-109 | Protector, Chain Case | 1 |
| 9 | 8061-708 | Rivet | 9 |
| 1 | 0607-351 | Protector, Brake Disc | 1 |
| 1 | 1702-278 | Mount, Clutch Guard | 1 |
| 1623-129 | Screw, Self-Tapping | ||
| 2 | 1623-052 | Clip, U-Nut | 2 |
| 1 | 1707-805 | Shield, Brake Disc - Center White | 1 |
| 1 | 1607-118 | Shield, Brake Disc - Front | 1 |
| 2 | 8408-613 | Screw, Cap | 2 |
| 1 | 1707-804 | Shield, Brake Disc - Rear White | 1 |
| 1 | 1623-130 | Rivet | 1 |
| 2 | 1707-899 | Roll, Tunnel - White | 2 |
| 1 | 0630-308 | Protector, Harness - Taillight Extension | 1 |
| 1 | 1707-906 | Gusset, Running Board - Right - White | 1 |
| 1 | 1707-907 | Gusset, Running Board - Left - White | 1 |
| 1 | 1707-908 | Gusset, Tunnel Roll - Right - White | 1 |
| 1 | 1707-909 | Gusset, Tunnel Roll - Left - White | 1 |
| 0621-866 | Decal, Tunnel - "9000" | ||
| 1 | 0630-292 | Protector, Taillight Harness | 1 |
| 2 | 0621-990 | Decal, Reflector - Red | 2 |
| 0621-882 | Decal, Tunnel - Right | ||
| 0621-883 | Decal, Tunnel - Left | ||
| 2 | 8470-512 | Screw, Machine | 2 |
| 1 | 0730-228 | Bracket, Mounting - Taillight - White | 1 |
| 1 | 0609-898 | Taillight, LED | 1 |
| 1 | 6606-394 | Snowflap | 1 |
| 1 | 5611-852 | Decal, Warning - Towing (French) (French) | 1 |
| 1 | 5611-853 | Decal, Warning - Towing (English) (English) | 1 |
| 6 | 8061-706 | Rivet | 6 |
| 1 | 2707-578 | Bumper, Rear - 129" - Black | 1 |
| 2 | 8476-620 | Screw, Machine | 2 |
| 2 | 8427-602 | Nut, Hex | 2 |
| 1 | 6606-600 | Saddlebag | 1 |
| 4 | 8060-630 | Rivet | 4 |
| 4 | 1623-940 | Mount, Saddlebag | 4 |
