Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Drive Pulley Ass'y | ||
| 1 | 417222969 | FIXED FLANGE | 1 |
| 1 | 417222181 | Sliding Flange Ass'y Includes 3 to 6 | 1 |
| 1 | 417222758 | Bushing | 1 |
| 293800118 | ADHESIVE LOCTITE 680 | ||
| 1 | 293370037 | Circlip | 1 |
| 3 | 417222671 | Lever | 3 |
| 3 | 417222947 | Roller | 3 |
| 6 | 417004302 | Stopper Washer | 6 |
| 3 | 417222594 | Pin | 3 |
| 3 | 732958001 | Cotter Pin | 3 |
| 3 | 417223164 | Lever Axle | 3 |
| 1 | 417222312 | Spring Seat | 1 |
| 414689700 | SPRING, YELLOW/ORANGE | ||
| 1 | 417007500 | Spring Cover Ass'y Includes 17 to 19 | 1 |
| 1 | 417009204 | Bushing | 1 |
| 1 | 413703100 | Loctite 609, 10 ml | 1 |
| 3 | 205084044 | Socket Head Screw M8 X 1.25 X 40 | 3 |
| 3 | 250200009 | Lock Washer 8 mm | 3 |
| 417223147 | Governor Cup | ||
| 3 | 417223088 | Ramp 617 | 3 |
| 3 | 250400050 | Spring Pin M10 X 22 | 3 |
| 6 | 250000418 | Hex. Flange Screw M6 X 18, Scotch Grip | 6 |
| 3 | 417223197 | CALIBRATION SCREW | 3 |
| 3 | 417005600 | Washer | 3 |
| 3 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 3 |
| 6 | 732401030 | O-Ring | 6 |
| 6 | 417223652 | Slider Shoe | 6 |
| 1 | 417009205 | Guard | 1 |
| 6 | 250000412 | Hex. Flange Screw M6 X 12, Scotch Grip | 6 |
| 1 | 250200006 | Spring Washer 14 mm | 1 |
| 1 | 417300393 | Drive Pulley Bolt | 1 |
| 1 | 516003708 | DECAL, NOTICE, DRIVE PULLEY BOLT | 1 |
| 1 | 417127179 | Fixe Flange Ass'y Includes 39 to 43 | 1 |
| 2 | 417127016 | Pulley Roller | 2 |
| 2 | 417127128 | Stud | 2 |
| 2 | 250200009 | Lock Washer 8 mm | 2 |
| 2 | 414753500 | Circlip | 2 |
| 1 | 417126955 | Sliding Flange Ass'y Includes 44a to 44b | 1 |
| 1 | 293370049 | Circlip | 1 |
| 1 | 417127190 | Cam Ass'y Includes 45 to 46 | 1 |
| 1 | 417127152 | Release Spring | 1 |
| 4 | 250000283 | Torx Screw M8 X 25, Scotch Grip | 4 |
| 1 | 417127173 | Pulley Adjuster Ass'y | 1 |
| 1 | 208652044 | Phillips Screw M5 X 20 | 1 |
| 1 | 234051410 | Flat Washer M5 | 1 |
| 1 | 232551414 | Elastic Stop Nut M5 | 1 |
| 1 | 417127155 | Washer | 1 |
| 1 | 504152574 | Ball Bearing | 1 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML | ||
| 1 | 417300383 | Drive Belt | 1 |
| 1 | 417300382 | Belt Guard | 1 |
| 1 | 516002670 | WARNING DECAL, SECURITY BELT GUARD | 1 |
| 1 | 417300380 | Reinforcement | 1 |
| 3 | 390909200 | Avex Rivet | 3 |
| 1 | 417300381 | Guide | 1 |
| 1 | 417300356 | Side Protector | 1 |
| 5 | 293150103 | Pop Rivet 3/16" | 5 |
| 1 | 417300360 | FRONT BELT GUARD BRACKET | 1 |
| 2 | 293150104 | Pop Rivet 3/16" | 2 |
| 1 | 417300361 | BELT GUARD BRACKET | 1 |
| 4 | 250000145 | Torx Screw M5 X 14 | 4 |
| 1 | 114045200 | Hair Pin | 1 |
| 1 | 417300396 | BELT GUARD BRACKET | 1 |
| 2 | 241151640 | Hex. Flange Screw K50 X 2.24 X 16 | 2 |
| 1 | 861805577 | QRS XD Roller Kit (2) | 1 |
