Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 5718-644 | Panel, Side w/Decals - Right - Black (See Decals Page For Decals) | ||
| 1 | 5718-306 | Panel, Side - Right - Black (inc. 2-10) | 1 |
| 1 | 3621-487 | Decal, Warning - English | 1 |
| 6 | 1623-939 | Nut, U | 6 |
| 6 | 2623-166 | Screw, Self-Tapping | 6 |
| 1 | 7606-292 | Hook, Mounting - Right | 1 |
| 1 | 7606-293 | Hook, Mounting - Left | 1 |
| 1 | 0617-756 | Foam, Side Panel - Lower Rear - Right | 1 |
| 1 | 7606-552 | Foil, Protective - Rear - Right | 1 |
| 1 | 7606-598 | Foil, Protective - Upper - Right | 1 |
| 1 | 0617-758 | Foam, Side Panel - Mid - Right | 1 |
| 1 | 0617-754 | Foam, Side Panel - Lower Front - Right | 1 |
| 5718-645 | Panel, Side w/Decals - Left - Black (See Decals Page For Decals) | ||
| 1 | 5718-031 | Panel, Side - Left - Black (inc. 3-5 and 12-15) | 1 |
| 1 | 3621-486 | Decal, Warning - French | 1 |
| 1 | 0617-757 | Foam, Side Panel - Lower Rear - Left | 1 |
| 1 | 0617-755 | Foam, Side Panel - Lower Front - Left | 1 |
| 1 | 0617-759 | Foam, Side Panel - Middle - Left | 1 |
| 4 | 2623-211 | Screw, Self-Tapping | 4 |
| 1 | 5718-304 | Plate, Skid - Right - Black (inc. two No. 3, 18-21, 24, and 31-37) | 1 |
| 1 | 0617-776 | Foam, Skid Plate - Front - Right | 1 |
| 1 | 0617-762 | Foam, Skid Plate - Middle - Right | 1 |
| 1 | 3612-328 | Foil, Skid Plate - Right | 1 |
| 16 | 0123-802 | Washer | 16 |
| 1 | 3612-232 | Plate, Exhaust Outlet | 1 |
| 1 | 3612-231 | Seal, Exhaust Outlet | 1 |
| 1 | 3612-196 | Shield, Resonator | 1 |
| 1 | 2712-041 | Deflector, Exhaust Outlet | 1 |
| 4 | 8061-712 | Rivet | 4 |
| 1 | 4718-971 | Plate, Skid - Left - Black (inc. two No. 3 and 28-36) | 1 |
| 1 | 0617-765 | Foam, Skid Plate - Lower - Left | 1 |
| 1 | 0617-763 | Foam, Skid Plate - Middle - Left | 1 |
| 1 | 0617-761 | Foam, Skid Plate - Front - Left | 1 |
| 2 | 7606-265 | Knob, Hold-Down | 2 |
| 2 | 2623-005 | Clip, Retaining | 2 |
| 2 | 7606-296 | Plate, Backing | 2 |
| 2 | 2623-155 | Clip, Retaining | 2 |
| 2 | 2623-171 | Washer | 2 |
| 2 | 1623-933 | Screw, Self-Tapping | 2 |
| 30 | 8061-708 | Rivet | 30 |
| 1 | 6606-940 | Shield, Heat - ECM | 1 |
| 2 | 8408-620 | Screw, Cap | 2 |
| 1 | 0730-276 | ECM (PLEASE INCLUDE VIN WHEN ORDERING) | 1 |
| 2 | 0423-031 | Clip, U-Nut | 2 |
| 1 | 7606-272 | Vent, Upper - Side Panel - Right | 1 |
| 1 | 7606-273 | Vent, Upper - Side Panel - Left | 1 |
| 1 | 7606-152 | Panel, Upper Side - Right - Black | 1 |
| 1 | 7606-153 | Panel, Upper Side - Left - Black | 1 |
| 5718-642 | Panel, Upper Side w/Decals - Right - Black (See Decals Page For Decals) | ||
| 5718-643 | Panel, Upper Side w/Decals - Left - Black (See Decals Page For Decals) | ||
| 1 | 2712-103 | Deflector, Exhaust | 1 |
| 3 | 8061-710 | Rivet | 3 |
