Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4718-014 | Panel, Side - Right - w/Decals - Orange (inc. 2-10) | ||
| 1 | 4718-002 | Panel, Side - Right - w/o Decals - Orange (inc. 3-7) | 1 |
| 1 | 0617-626 | Foam, Side Panel - Upper Front - Right | 1 |
| 1 | 6606-414 | Foil, Protective | 1 |
| 1 | 0617-628 | Foam, Side Panel - Upper Rear - Right | 1 |
| 1 | 0617-632 | Foam, Side Panel - Lower Front - Right | 1 |
| 1 | 0617-634 | Foam, Side Panel - Lower Rear - Right | 1 |
| 1 | 0621-830 | Decal, Side Panel - Upper - Right | 1 |
| 0621-840 | Decal, Side Panel - Lower - Right | ||
| 0621-838 | Decal, Side Panel - Center - Right | ||
| 4718-015 | Panel, Side - Left - w/Decals - Orange (inc. 12-21) | ||
| 1 | 4718-003 | Panel, Side - Left - w/o Decals - Orange (inc. 13-18) | 1 |
| 1 | 0617-629 | Foam, Side Panel - Upper Rear - Left | 1 |
| 1 | 0617-635 | Foam, Side Panel - Lower Rear - Left | 1 |
| 1 | 0617-631 | Foam, Side Panel - Center Front - Left | 1 |
| 1 | 0617-681 | Foam, Side Panel - Lower Front - Left | 1 |
| 1 | 2602-704 | Screen, Vent | 1 |
| 8 | 0623-269 | Clip, Retaining | 8 |
| 1 | 0621-831 | Decal, Side Panel - Upper - Left | 1 |
| 1 | 0621-841 | Decal, Side Panel - Lower - Left | 1 |
| 1 | 0621-839 | Decal, Side Panel - Center - Left | 1 |
| 1 | 1623-637 | Clip, U-Nut | 1 |
| 2 | 0607-447 | Cable | 2 |
| 2 | 0605-283 | Clip, Hairpin | 2 |
| 2 | 8060-486 | Rivet | 2 |
| 2 | 8050-127 | Washer | 2 |
| 1 | 0619-206 | Foil, Protective | 1 |
| 1 | 5706-531 | Screen, Intake | 1 |
| 1 | 1702-369 | Duct, Belt Cooling (inc. 30) | 1 |
| 1 | 6606-694 | Foil, Protective | 1 |
| 2 | 1623-030 | Clip, U-Nut | 2 |
| 4 | 0623-797 | Screw, Self-Tapping | 4 |
| 1 | 4718-008 | Plate, Skid - Right - w/Decals - Orange (inc. 34-44) | 1 |
| 1 | 4718-006 | Plate, Skid - Right - w/o Decals - Orange (inc. 35-41) | 1 |
| 1 | 0617-640 | Foam, Skid Plate - Upper Rear - Right | 1 |
| 1 | 0617-638 | Foam, Skid Plate - Center Front - Right | 1 |
| 1 | 0617-636 | Foam, Skid Plate - Upper Front - Right | 1 |
| 1 | 2612-850 | Foil, Protective | 1 |
| 26 | 8061-708 | Rivet | 26 |
| 1 | 2612-754 | Deflector, Heat | 1 |
| 8 | 0123-802 | Washer | 8 |
| 1 | 0621-842 | Decal, Skid Plate - Upper Right | 1 |
| 1 | 0621-844 | Decal, Skid Plate - Lower Right | 1 |
| 1 | 0621-846 | Decal, Skid Plate - Rear Right | 1 |
| 1 | 4718-009 | Plate, Skid - Left - w/Decals - Orange (inc. 46-53) | 1 |
| 1 | 4718-007 | Plate, Skid - Left - w/o Decals - Orange (inc. 47-50) | 1 |
| 1 | 0617-637 | Foam, Skid Plate - Upper Front - Left | 1 |
| 1 | 0617-639 | Foam, Skid Plate - Center Front - Left | 1 |
| 1 | 0617-641 | Foam, Skid Plate - Upper Rear - Left | 1 |
| 1 | 6606-613 | Panel, Reinforcement | 1 |
| 0621-843 | Decal, Skid Plate - Upper Left | ||
| 1 | 0621-845 | Decal, Skid Plate - Lower Left | 1 |
| 0621-847 | Decal, Skid Plate - Rear Left | ||
| 2 | 1623-748 | Clip, Retaining | 2 |
| 2 | 6606-592 | Pin, Retaining | 2 |
| 1623-129 | Screw, Self-Tapping | ||
| 1 | 2612-796 | Plate, Exhaust Outlet | 1 |
| 1 | 2612-795 | Seal, Exhaust Outlet | 1 |
| 6 | 8061-710 | Rivet | 6 |
| 1 | 6606-342 | Fascia, Front - Right - Black | 1 |
| 1 | 6606-295 | Shield, Heat - EMC | 1 |
| 2 | 8408-620 | Screw, Cap | 2 |
| 2 | 0423-031 | Clip, U-Nut | 2 |
| 2 | 0623-784 | Screw, Self-Tapping | 2 |
| 1 | 3718-303 | Fascia, Front - Left - Black (inc. 66) | 1 |
| 6606-405 | Foil, Protective | ||
| 1 | 2623-001 | RETAINER,PUSHNUT - 3/16" STUD | 1 |
| 1 | 1623-999 | Screw, Thumb | 1 |
| 1 | 2602-711 | Deflector, Air | 1 |
| 1 | 2602-703 | Retainer, Air Deflector | 1 |
