Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 24120-10H00 | SHAFT, COUNTER, NT:13 | ||
| 1 | 24221-10H00 | GEAR, 2ND DRIVE, NT:17 | 1 |
| 1 | 24231-10H00 | GEAR, 3RD & 4TH DRIVE NT:17/21 | 1 |
| 1 | 24251-10H00 | GEAR, 5TH DRIVE, NT:22 | 1 |
| 1 | 09181-24009 | WASHER, 5TH DRIVE 24X29X1.0 | 1 |
| 1 | 09262-17040 | BEARING, CNTR SHAFT, L 17X40X9.5 | 1 |
| 1 | 09262-22018 | BEARING, CNTR SHAFT, R 22X50X14 | 1 |
| 09300-24004 | BUSH, 5TH DRIVE 24X27X9.0 | ||
| 1 | 09380-24007 | CIRCLIP, 5TH DRIVE | 1 |
| 1 | 09380-24007 | CIRCLIP, 2ND DRIVE | 1 |
| 24131-10H00 | SHAFT, DRIVE | ||
| 1 | 24311-10H01 | GEAR, 1ST DRIVEN, NT:28 | 1 |
| 1 | 24321-10H00 | GEAR, 2ND DRIVEN, NT:30 | 1 |
| 1 | 24331-10H00 | GEAR, 3RD DRIVEN, NT:25 | 1 |
| 1 | 24341-10H00 | GEAR, 4TH DRIVEN, NT:26 | 1 |
| 1 | 24351-10H00 | GEAR, 5TH DRIVEN, NT:24 | 1 |
| 1 | 24412-10H00 | DOG, SLIDING | 1 |
| 1 | 09181-17195 | SHIM (17X28X1) 17X28X1.0 | 1 |
| 1 | 09181-20167 | SHIM (20X28X1) 20X28X1.0 | 1 |
| 1 | 09181-20195 | WASHER, 2ND DRIVEN GEAR, L 20X30X1.0 | 1 |
| 1 | 09181-22167 | SHIM (22X30X1) 22X30X1.0 | 1 |
| 1 | 09181-24008 | WASHER, 3RD DRIVEN GEAR 24X30X1.0 | 1 |
| 1 | 09181-24008 | WASHER, 4TH DRIVEN GEAR 24X30X1.0 | 1 |
| 1 | 09262-20147 | BEARING, DRIVE SHAFT, L 20X52X15 | 1 |
| 1 | 09289-28012 | SEAL, DRIVE SHAFT OIL 28X38X7.5 | 1 |
| 1 | 09300-20037 | BUSH, 1ST DRIVEN GEAR 20X24X10 | 1 |
| 09300-22020 | BUSH, 2ND DRIVEN GEAR 22X25X12 | ||
| 1 | 09300-24003 | BUSH, 3RD & 4TH DRIVEN 24X27X18 | 1 |
| 1 | 09380-24007 | CIRCLIP, 4TH DRIVEN GEAR | 1 |
| 1 | 09262-17023 | BEARING, DRIVE SHAFT, R 17X40X12 | 1 |
| 1 | 24741-20A00 | RETAINER, CL HSG BRG | 1 |
| 1 | 09126-06011 | SCREW, DRIVE SHAFT (6X12) | 1 |
| 1 | 24741-21A00 | RETAINER, CNTR SHAFT | 1 |
| 1 | 09125-06110 | SCREW, CNTR SHAFT (6X12) | 1 |
| 1 | 26260-10H00 | GEAR, KICK STARTER IDLE | 1 |
| 1 | 27511-14111 | SPROCKET, ENGINE, NT:12 | 1 |
| 1 | 27511-14121 | SPROCKET, ENGINE, NT:13 OPT | 1 |
| 1 | 27531-43D00 | SPACER, ENGINE SPROCKET | 1 |
| 1 | 27600-43D01-112 | CHAIN ASSY, DRIVE MODEL K7 DID520DMA2-SDH | 1 |
| 27600-10H00-112 | CHAIN ASSY, DRIVE MODEL K8/K9 DID520DMA2-SDH-G&B | ||
| 1 | 27620-43D01 | JOINT SET, CHAIN MODEL K7 OPT | 1 |
| 27620-10H00 | JOINT SET, CHAIN MODEL K8/K9 OPT | ||
| 1 | 27641-10H00 | PLATE, FRONT CHAIN GUIDE | 1 |
| 2 | 09280-20006 | O RING, SPROCKET SPACER D:1.9,ID:19.8 | 2 |
| 1 | 09380-20007 | CIRCLIP, ENGINE SPROCKET | 1 |
