Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 10 | 415130468 | DeepBlack,TunnelChassis Module 154 Short Includes 10 to 10aw | 1 |
| 10 | 415130469 | Catalyst Gray,Tunnel Chassis Module 154 Includes 10 to 10aw | 1 |
| 10d | 518332578 | RH Footrest Reinforcement | 1 |
| 10e | 518332577 | LH Footrest Reinforcement | 1 |
| 10f | 518326647 | Reinforcement Plate | 2 |
| 10h | 518328467 | LH Suspension Bracket | 1 |
| 10j | 518328468 | RH Suspension Bracket | 1 |
| 10k | 518331253 | Stirrup Reinforcement | 1 |
| 10m | 518332924 | Deep Black, LH Chassis Reinforcement | 1 |
| 10q | 518328451 | RH Roller | 1 |
| 10r | 518328452 | LH Roller | 1 |
| 10u | 518329646 | RH Tunnel Liner | 1 |
| 10v | 518329647 | LH Tunnel Liner | 1 |
| 10w | 518329088 | LH Reinforcement Plate | 1 |
| 10x | 518329089 | RH Reinforcement Plate | 1 |
| 10y | 518332553 | Radiator Tunnel 146 | 1 |
| 10z | 250100199 | Insert Half Hex Body M6 x 1.0 | 3 |
| 10ac | 518331704 | Rear Cap Ass'y | 1 |
| 10ad | 293150203 | Rivet Avibulb 3/16 | 5 |
| 10ae | 518328460 | RH Footrest | 1 |
| 10af | 293730047 | Black, Dart 8 mm | 3 |
| 10ag | 293730060 | Black, Dart 10 mm | 2 |
| 10ah | 293730052 | Black, Plug | 1 |
| 10aj | 518331556 | LH Foot Protector | 1 |
| 10aq | 293150203 | Rivet Avibulb 3/16 | 1 |
| 10ar | 293150183 | Rivet | 6 |
| 10at | 293150096 | Hemlock Rivet, 6.5 mm | 4 |
| 10au | 293150119 | Hemlock Rivet, 6.5 mm | 1 |
| 10av | 293150174 | Hemlock Rivet, 6.4 mm | 4 |
| 10aw | 293150147 | Hemlock Rivet | 2 |
| 20 | 293730052 | Black, Plug | 1 |
| 30 | 234081410 | Flat Washer 8 mm | 2 |
| 31 | 250000779 | Torx Screw M6 X 1.0 X 18, Scotch Grip | 12 |
| 32 | 224061201 | Flat Washer | 12 |
| 70 | 250000942 | Hex Screw M8 X 30 | 2 |
| 80 | 234081410 | Flat Washer 8 mm | 2 |
| 90 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 100 | 518332692 | Engine Chassis Module Ass'y Includes 100 to 100m | 1 |
| 100a | 518332687 | RH Member Ass'y Includes 100a to 100a1 | 1 |
| 100a1 | 505072690 | Leg Bushing | 1 |
| 100b | 518332688 | LH Member Ass'y Includes 100b to 100b1 | 1 |
| 100b1 | 505072690 | Leg Bushing | 1 |
| 100c | 293150148 | Rivet Magna-Grip 6,4 X 50,8 | 3 |
| 100d | 293150149 | Collar Huck Magna-Grip 6.4 | 3 |
| 100e | 518332716 | Bottom Plate | 1 |
| 100f | 293150203 | Rivet Avibulb 3/16 | 14 |
| 100g | 293450268 | Insert M5 X 0.8 | 1 |
| 100h | 518330100 | Front Member | 1 |
| 100j | 250000945 | Hex. Flange Screw M6 X 25 | 4 |
| 100k | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 100m | 293150203 | Rivet Avibulb 3/16 | 2 |
| 110 | 293150147 | Hemlock Rivet | 3 |
| 120 | 293150174 | Hemlock Rivet, 6.4 mm | 2 |
| 125 | 293150120 | Hemlock Rivet 6.5 mm | 2 |
| 130 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 140 | 207662046 | Hex. Flange Screw M6 X 20 | 2 |
| 150 | 233261416 | Elastic Flange Nut M6 X 1.0 | 2 |
| 170 | 293450267 | Insert M5 - 0.8 | 1 |
| 180 | 207661646 | Hex. Flange Screw M6 X 16 | 4 |
| 230 | 207562056 | Hex. Flange Screw M6 X 20 | 1 |
| 300 | 518333692 | LH Side Member Ass'y Includes 300 to 300a | 1 |
| 300a | 512060295 | Rubber Mount | 1 |
| 310 | 250001060 | Screw-Pan HD.Torx M8X30 | 4 |
| 400 | 518332096 | Suspension Chassis Module Ass'y | 1 |
| 410 | 250001051 | Screw-Forming Hex.HD.FL. M6 X 16 | 2 |
| 425 | 207562056 | Hex. Flange Screw M6 X 20 | 1 |
| 430 | 233261416 | Elastic Flange Nut M6 X 1.0 | 1 |
| 440 | 207661636 | Hex. Flange Screw M6 X 16 | 6 |
| 790 | 293450278 | Insert | 2 |
| 800 | 518329480 | Member Fixation Plate | 2 |
| 900 | 518333266 | Deep Black,LH Rear Diagonal Cross Member Includes 900 to 900a | |
| 900a | 518333264 | LH Rear Diagonal Cross Member | |
| 910 | 518333267 | Deep Black,RH Rear Diagonal Cross Member Includes 910 to 910a | |
| 910a | 518333265 | RH Rear Diagonal Cross Member | |
| 920 | 250000887 | Pan Head Torx Screw M8 X 12 | 4 |
| 1100 | 518329974 | Upper Colomn Support | 2 |
| 1110 | 207561646 | Hex. Flange Screw M6 X 16, Scotch Grip | 1 |
| 1120 | 233261416 | Elastic Flange Nut M6 X 1.0 | 3 |
| 1130 | 207662556 | Hex. Flange Screw M6 X 25 | 1 |
| 1140 | 207662046 | Hex. Flange Screw M6 X 20 | 2 |
| 1300 | 518331205 | Rear Short Bumper 154 Includes 1300 to 1300a | 1 |
| 1300a | 520001612 | Cap | 2 |
| 3040 | 293730079 | Dart | 2 |
