Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4 | 210261680 | Hex. Flange Screw M6 X 16 | 4 |
| 1 | 207665044 | Hex. Flange Screw M6 X 50 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 1 | 234461608 | External Serrated Lock Washer 6 mm | 1 |
| 1 | 710000073 | Insulator Pad | 1 |
| 2 | 210252040 | Hex. Forming Screw | 2 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 414580600 | Elbow Male Connector | 1 |
| 1 | 293720029 | Grommet | 1 |
| XXX | Not Available As Spare Parts | ||
| 1 | 293710059 | Y-Fitting | 1 |
| 1 | 707001018 | THROTTLE CABLE | 1 |
| 1 | 707000434 | Cable Guide | 1 |
| 1 | 707000595 | Throttle Handle | 1 |
| 3 | 205052588 | Socket Head Screw M5 X 25 | 3 |
| 1 | 707000573 | Speed Limiter Europe | 1 |
| 250000332 | TORX SCREW M4 X 8 Europe | ||
| 4 | 707000426 | Anti-Vibration Mount | 4 |
| 1 | 707000802 | ENGINE BRACKET | 1 |
| 1 | 707000803 | ENGINE BRACKET | 1 |
| 2 | 230602546 | Hex. Flange Screw M10 X 125 | 2 |
| 2 | 233201416 | Hex. Flange Elastic Nut M10 | 2 |
| 4 | 207682044 | Hex. Flange Screw M8 X 20 | 4 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 2 | 207602544 | Hex. Flange Screw M10 X 25 | 2 |
| 1 | 707000883 | UPPER ENGINE BRACKET, BLACK | 1 |
| 1 | 707000949 | Rubber Isolator | 1 |
| 1 | 207581046 | Flange Screw M8 x 10, Scotch Grip | 1 |
| 1 | 232581414 | Hex. Elastic Stop Nut M8 | 1 |
| 1 | 707001043 | Flexible Adaptor | 1 |
| 2 | 293650091 | Norma Clamp | 2 |
| 707000777 | AIR INLET | ||
| 1 | 707000778 | WATER DEFLECTOR | 1 |
| 2 | 234052600 | Flat Washer 5 mm, Stainless | 2 |
| 1 | 707000780 | WATER DEFLECTOR | 1 |
| 2 | 293150089 | Tuflok Plastic Rivet | 2 |
| 1 | 207662544 | Hex. Flange Screw M6 X 25 | 1 |
| 1 | 234062600 | Flat Washer M6, Stainless | 1 |
| 1 | 250000048 | Panel Nut M6 X 1.0 | 1 |
| 1 | 707000789 | Adaptor | 1 |
| 2 | 514052859 | Norma Gear Clamp | 2 |
| 707000459 | AIR OUTLET ASS'Y | ||
| 1 | 210261680 | Hex. Flange Screw M6 X 16 | 1 |
| 2 | 390402200 | Pop Rivet 3/16" Europe | 2 |
| 2 | 205951046 | Socket Head Screw M5 X 10 Europe | 2 |
| 1 | 707000692 | ANTITHEFT PLATE Europe | 1 |
| 1 | 707000691 | Lever | 1 |
| 1 | 207663044 | Hex. Flange Screw M6 X 30 | 1 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 707000545 | LH BALL JOINT | ||
| 1 | 232066414 | LH HEX. NUT M6 | 1 |
| 707000579 | THREADED ROD | ||
| 1 | 707000661 | THREADED ROD Europe | 1 |
| 707000664 | FIXING PLATE Europe | ||
| 3 | 250100143 | Extruded Panel Nut M4 X 0.7 Europe | 3 |
| 1 | 205402596 | SOCKET HEAD SCREW M10 X 25 Europe | 1 |
| 1 | 707000666 | Padlock with Key Europe | 1 |
| 1 | 707000667 | Cover Lock Europe | 1 |
| 3 | 250000242 | Truss Torx Screw M4 X 16 Europe | 3 |
| 1 | 219704400 | Was 409901800 Tubing (13 mm) Europe | 1 |
| 2 | 232081414 | Hex. Nut M8 | 2 |
| 1 | 707000668 | ADJUSTMENT BLOCK Europe | 1 |
| 1 | 232061600 | Hex. Nut M6 Europe | 1 |
| 707000575 | PIVOT | ||
| 2 | 707000576 | BUSHING | 2 |
| 1 | 293350039 | BALL BEARING | 1 |
| 1 | 707000577 | Spring | 1 |
| 1 | 707000783 | Lever Arm | 1 |
| 705500022 | LEVER BUTTON | ||
| 1 | 707000546 | RH Ball Joint | 1 |
| 2 | 506151252 | Washer | 2 |
| 1 | 707000410 | Cover OPS | 1 |
| 2 | 210261280 | Hex. Flange Screw M6 X 12 | 2 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 707001173 | Drain Pluig | ||
| 707001175 | Clamp |
