Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 732610072 | Push Nut | 2 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 207603044 | Hex. Flange Screw M10 X 30 | 2 |
| 2 | 233201414 | Hex. Flange Elastic Nut M10 | 2 |
| 1 | 705003196 | Front Bumper | 1 |
| 1 | 705001981 | RH Footboard Ass'y | 1 |
| 1 | 705002488 | LH Footboard | 1 |
| 1 | 705001518 | Engine Cover | 1 |
| 5 | 210261280 | Hex. Flange Screw M6 X 12 | 5 |
| 2 | 705002666 | Engine Cover Support | 2 |
| 4 | 705000428 | Footrest | 4 |
| 12 | 207662584 | Hex. Flange Screw M6 X 25 | 12 |
| 12 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 12 |
| 1 | 715000776 | Front Fender Kit, Viper Red Includes 15 to 25, Viper Red | 1 |
| 1 | 715000773 | Front Fender Kit, Yellow Includes 15 to 25, Yellow | 1 |
| 715000778 | Front Fender Kit, Black Includes 15 to 25, Black | ||
| 1 | 704901089 | Warning Decal, Load English Version | 1 |
| 1 | 704901753 | Warning Decal, Under 16 Years Old English Version | 1 |
| 704901749 | Warning Decal, Death And Injuries English Version, North America & Int. | ||
| 704901090 | Warning Decal, Load French Version | ||
| 1 | 704901858 | Warning Decal, Under 16 Years Old French Version | 1 |
| 704901750 | WARNING DECAL, DEATH AND INJURIES French Version, North America & Int. | ||
| 1 | 705002492 | Reflective Sheet | 1 |
| 704901751 | WARNING DECAL, DEATH AND INJURIES English Version, Europe | ||
| 704901752 | WARNING DECAL, DEATH AND INJURIES French Version, Europe | ||
| 1 | 293000103 | PLASTIC CAP STD | 1 |
| 12 | 250000261 | Torx Screw M6 X 16 | 12 |
| 2 | 705001999 | FRONT CAP | 2 |
| 1 | 705001910 | Black LH Cap | 1 |
| 715000798 | REAR FENDER KIT, RED Includes 31 to 41, Viper Red | ||
| 1 | 715000800 | REAR FENDER KIT, RED Includes 31 to 44, Viper Red, Europe | 1 |
| 715000793 | REAR FENDER KIT, YELLOW Includes 31 to 41, Yellow | ||
| 715000795 | REAR FENDER KIT, YELLOW Includes 31 to 44, Yellow, Europe | ||
| 715000802 | Rear Fender Kit, Black Includes 31 to 41, Black | ||
| 704901762 | WARNING DECAL, PASSENGER English Version | ||
| 1 | 704901120 | Warning Decal Tire Pressure English Version | 1 |
| 704901763 | WARNING DECAL, PASSENGER, FRENCH French Version | ||
| 704901121 | WARNING DECAL TIRE PRESSURE French Version | ||
| 1 | 705000809 | Reflective Sheet | 1 |
| 1 | 705002189 | REFLECTIVE SHEET | 1 |
| 1 | 705002085 | REFLECTIVE SHEET | 1 |
| 705003087 | REFLECTIVE SHEET | ||
| 1 | 704901444 | WARNING DECAL, PUBLIC ROADS USE English Version, Europe | 1 |
| 704901158 | Warning Decal, Public Roads Use French Version, Europe | ||
| 704901177 | WARNING DECAL, MULTILINGUAL Multilingual, Europe | ||
| 2 | 705002219 | RUBBER PAD | 2 |
| 1 | 705002191 | REFLECTIVE SHEET | 1 |
