Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 703500991 | Shaft Ass'y Kit Built<BR/> Before Feb 2019, Includes 10 to 10g | 1 |
| 1 | 703500990 | Shaft Ass'y Kit Built Feb 2019<BR/> and Up, Includes 10 to 10g | 1 |
| 1 | 715900118 | Rubber Boot | 1 |
| 2 | 703500846 | Universal Joint Ass'y Includes 10b<BR/> to 10c | 2 |
| 1 | 715900295 | Grease Fitting | 1 |
| 1 | 715900500 | Yoke | 1 |
| 1 | 715900436 | Joint | 1 |
| 1 | 715900106 | Spline Yoke | 1 |
| 1 | 705501123 | Protector | 1 |
| 1 | 703500987 | Shaft Ass'y Kit Built Before<BR/> Feb 2019, Includes 11 to 11f | 1 |
| 1 | 703501084 | Shaft Ass'y Kit Built Feb 2019<BR/> and Up, Includes 11 to 11f | 1 |
| 2 | 715900326 | Universal Joint Includes 11b<BR/> to 11c | 2 |
| 1 | 715900438 | Yoke Built Before<BR/> Feb 2019 | 1 |
| 1 | 715900500 | Yoke Built Feb 2019<BR/> and Up | 1 |
| 1 | 715900500 | Yoke Built Before<BR/> Feb 2019 | 1 |
| 1 | 715900499 | Yoke Built Feb 2019<BR/> and Up | 1 |
| 1 | 705501123 | Protector Not Shown | 1 |
| 705502230 | Final Drive Unit Built Before<BR/> Feb 2019 | ||
| 1 | 705502968 | Final Drive Unit Built Feb 2019<BR/> and Up | 1 |
| 16 | 250300643 | Wheel Stud Tightening<BR/> Torque: See Bulletin ATV 2020-4 | 16 |
| 1 | 250200102 | Flat Washer M12 | 1 |
| 1 | 250001039 | Hex Flange Screw M12 X 16 | 1 |
| 1 | 250200005 | Conical Spring Washer M12 | 1 |
| 2 | 250100047 | Hex. Castellated Nut M18 | 2 |
| 2 | 250400071 | Cotter Pin | 2 |
| 2 | 705502711 | RH CV Joint Includes 230<BR/> to 230d | 2 |
| 705501776 | JOINT_CV EXT | ||
| 705501780 | PLUNGING JOINT | ||
| 1 | 705501781 | Circlip Not Shown | 1 |
| 2 | 705501864 | Boot Kit Includes 230d<BR/> to 230d2 | 2 |
| 1 | 715900241 | Oetiker Clamp, 82.1 mm | 1 |
| 1 | 715900242 | Oetiker Clamp, 27.3 mm | 1 |
| 2 | 705502710 | LH CV Joint Includes 240<BR/> to 240d | 2 |
| 2 | 705501864 | Boot Kit Includes<BR/> 240d to 240d2 | 2 |
| 3 | 250001041 | Hex. Flange Screw M10 X 135 | 3 |
| 3 | 233201436 | Hex. Flange Elastic Nut M10 | 3 |
| 4 | 293350118 | Cone Bearing | 4 |
| 4 | 293370019 | Circlip | 4 |
| 2 | 250200171 | Conical Spring Washer M18 | 2 |
| 293830193 | Polyurethane Hose | ||
| 1 | 705502370 | Rear Drive Unit Ass'y | 1 |
| 250000378 | HEX FLANGED SCREW M12 X 16, SCOTCH GRIP | ||
| 1 | 250000615 | Screw-Hex.Flange M10 X 16 Not Shown | 1 |
| 1 | 250200014 | Flat Washer M10 Not Shown | 1 |
| 2 | 705502741 | Hex. Flange Screw M10x145 Not Shown | 2 |
| 6 | 250000508 | Hex. Flange Screw M10 x 135 | 6 |
| 3 | 231003587 | Socket Screw HD.din.912 | 3 |
| 10 | 233201436 | Hex. Flange Elastic Nut M10 | 10 |
| 1 | 232500416 | Elastic Stop Nut M10 Not Shown | 1 |
