Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 710004382 | Ground Cable | 1 |
| 1 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 1 |
| 1 | 234161601 | Lock Washer Helical M6 | 1 |
| 1 | 250000717 | Torx Head Screw M6 X 16 | 1 |
| 4 | 224061121 | Flat Washer | 4 |
| 1 | 232361493 | Domed Nut M6 | 1 |
| 1 | 710004377 | Positive Cable | 1 |
| 1 | 232561414 | Elastic Stop Nut M6 | 1 |
| 1 | 710002569 | Cap | 1 |
| 1 | 710006170 | No ABS Cable | 1 |
| 1 | 710005840 | Indicator Light Cable | 1 |
| 1 | 270000141 | Clip | 1 |
| 1 | 390402300 | Pop Rivet 3/16" | 1 |
| 1 | 391301600 | Washer | 1 |
| 1 | 710000992 | Clip | 1 |
| 1 | 710004118 | Connector Bracket | 1 |
| 1 | 210262040 | Hex. Flange Screw M6 X 20 | 1 |
| 1 | 234461608 | External Serrated Lock Washer 6 mm | 1 |
| 1 | 710001364 | Starter Relay | 1 |
| 2 | 234161601 | Lock Washer Helical M6 | 2 |
| 2 | 232561414 | Elastic Stop Nut M6 | 2 |
| 1 | 207662054 | Hex. Flange Screw M6 X 20 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 2 | 710003239 | Flasher Unit | 2 |
| 1 | 710006211 | LH Multi Fonction Control | 1 |
| 1 | 710003847 | Ignition Switch | 1 |
| 1 | 710006216 | Speedometer | 1 |
| 1 | 710001183 | Trim Ring Ass'y | 1 |
| 1 | 704904615 | BRP Logo13 mm | 1 |
| 1 | 715900265 | Button | 1 |
| 1 | 710002183 | Grey, Electronic Key | 1 |
| 1 | 710000817 | Black, Electronic Key | 1 |
| 12 | 572106600 | Handle | 12 |
| 12 | 250000718 | Hex. Screw K40 X 45 | 12 |
| 12 | 517168600 | Spring | 12 |
| 2 | 710006177 | Low Beam | 2 |
| 1 | 715900141 | Bulb 12V 55W | 1 |
| 1 | 710002291 | RH High Front Housing | 1 |
| 1 | 710002292 | LH High Front Housing | 1 |
| 6 | 250000723 | Phillips Screw K40 X 16 | 6 |
| 2 | 710002525 | High Beam Ass'y | 2 |
| 1 | 415129249 | Halogen Bulb | 1 |
| 2 | 710002964 | Flasher | 2 |
| 2 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip | 2 |
| 1 | 710005766 | Pilot Light Trailer Flasher | 1 |
| 1 | 710005767 | Pilot Light Tail Lamp | 1 |
| 1 | 710003909 | Pilot Lamp | 1 |
| 2 | 710001726 | Day Light | 2 |
| 1 | 710006113 | Horn Support | 1 |
| 1 | 710004791 | Horn | 1 |
| 1 | 207667044 | Hex. Flange Screw M6 X 70 | 1 |
| 1 | 708001129 | Bushing | 1 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 2 | 207661644 | Hex. Flange Screw M6 X 16 | 2 |
| 1 | 710005842 | Voltage Regulator | 1 |
| 1 | 207563034 | Hex. Flange Screw M6 X 30, Scotch Grip | 1 |
| 1 | 710004904 | Connector Plug | 1 |
| 1 | 410301203 | Battery YUASA YTX20L | 1 |
| 1 | 250000282 | Battery Bolt Kit | 1 |
| 1 | 710005528 | Battery Support | 1 |
| 2 | 210262050 | Hexagonal Head Screw | 2 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 1 | 710002404 | Fixation Plate | 1 |
| 1 | 705003666 | Rubber Grommet | 1 |
| 3 | 207662054 | Hex. Flange Screw M6 X 20 | 3 |
| 1 | 710001248 | DC Outlet | 1 |
| 1 | 715004008 | Top Plate | 1 |
| 1 | 710004990 | Multifonction Housing Ass'y | 1 |
| 1 | 710005908 | Screw M10 X1.25 X 20 BHCS S.Grip | 1 |
| 1 | 503192496 | Washer | 1 |
| 1 | 710004567 | Cable | 1 |
| 1 | 710005932 | Rear Light Harness | 1 |
| 1 | 710005846 | Trailer Harness | 1 |
| 40233 | Screw M5 X 35 | ||
| 3 | 233251414 | Hex. Flange Elastic Nut M5 | 3 |
| 705204572 | Plug Fastening Plate | ||
| 2 | 232500416 | Elastic Stop Nut M10 | 2 |
| 1 | 250000253 | Hex. Flange Screw M6 X 1.0 X 30 | 1 |
| 1 | 710004193 | Sheath | 1 |
