Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705004898 | LH Cover Tank | 1 |
| 1 | 705002920 | LH FOAM | 1 |
| 1 | 705002546 | RH GAS TANK COVER | 1 |
| 1 | 705002921 | RH DEFLECTOR FOAM | 1 |
| 5 | 219704364 | Neoprene Seal (1PAC=3M) | 5 |
| 7 | 293150089 | Tuflok Plastic Rivet | 7 |
| 1 | 705004647 | LH Rear Panel, Metallic Magnesium Magnesium-Black Model | 1 |
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 705004651 | LH REAR PANEL, ALLOY ORANGE RS-S Alloy Orange-Black Model | ||
| 1 | 705002508 | LH Heat Reflective Sheet | 1 |
| 1 | 705001542 | LH REAR GRILL | 1 |
| 4 | 517302785 | Edge Clip | 4 |
| 1 | 705004648 | RH Rear Panel, Metallic Magnesium Magnesium-Black Model | 1 |
| 705004652 | RH REAR PANEL, ALLOY ORANGE RS-S Alloy Orange-Black Model | ||
| XXX | Not Available As Spare Parts | ||
| 705002509 | BLACK RH REAR PANEL FOAM | ||
| 1 | 705001544 | RH REAR GRILL | 1 |
| 6 | 250100113 | Panel Nut, M6 X 1.0 | 6 |
| 2 | 250000350 | Torx Truss Screw M6 X 20 | 2 |
| 2 | 705003207 | Plastic Washer | 2 |
| 4 | 293150089 | Tuflok Plastic Rivet | 4 |
| 1 | 705001550 | Passenger Handle | 1 |
| 2 | 207584034 | Hex. Flange Screw, Scotch Grip | 2 |
| 1 | 705004656 | REAR TIP, METALLIC MAGNESIUM RS Magnesium-Black Model | 1 |
| 705004657 | Steel Black Rear Tip RS-S Magnesium-Black Model | ||
| 1 | 705004658 | Rear Tip, Metallic Black RS-S Alloy Orange-Black Model | 1 |
| 705001551 | UNDER TAIL COVER | ||
| 7 | 250100113 | Panel Nut, M6 X 1.0 | 7 |
| 7 | 250000350 | Torx Truss Screw M6 X 20 | 7 |
| 1 | 705002503 | LH Rear Fender Support | 1 |
| 705002501 | RH REAR FENDER SUPPORT | ||
| 705003031 | CENTRAL REAR FENDER SUPPORT | ||
| 1 | 705004659 | REAR FENDER, METALLIC MAGNESIUM RS Magnesium-Black North America Model | 1 |
| 1 | 705004660 | Steel Black Rear Fender RS-S Magnesium-Black North America Model | 1 |
| 1 | 705004661 | Rear Fender, Matte Black RS-S Alloy Orange-Black North America Model | 1 |
| 1 | 705004664 | REAR FENDER, METALLIC MAGNESIUM RS Magnesium-Black Europe Model | 1 |
| 705004666 | FENDER REAR B-266 RS-S Magnesium-Black Europe Model | ||
| 1 | 705004668 | REAR FENDER, MATTE BLACK RS-S Alloy Orange-Black Europe Model | 1 |
| 4 | 250000303 | Torx Truss Screw M6 X 20 | 4 |
| 4 | 705003207 | Plastic Washer | 4 |
| 4 | 233261494 | Hex. Flange Elastic Nut M6 | 4 |
| 4 | 250000350 | Torx Truss Screw M6 X 20 | 4 |
| 3 | 250000350 | Torx Truss Screw M6 X 20 | 3 |
| 6 | 233261494 | Hex. Flange Elastic Nut M6 | 6 |
| 1 | 705002980 | LH REINFORCEMENT PLATE | 1 |
| 1 | 705002981 | RH Reinforcement Plate | 1 |
| 705002367 | LICENCE PLATE SUPPORT Europe | ||
| 4 | 250000348 | Torx Truss Screw M6 X 16 Europe | 4 |
| 2 | 232561494 | Elastic Stop Nut M6 Europe | 2 |
| 2 | 232361493 | Domed Nut M6 Europe | 2 |
| 1 | 705002092 | Lower Belt Guard | 1 |
| 1 | 705001555 | Upper Belt Guard | 1 |
| 2 | 250000349 | Torx Truss Screw M6 X 10 | 2 |
| 2 | 232361493 | Domed Nut M6 | 2 |
| 1 | 705004179 | LH FRONT FOOT SUPPORT RS | 1 |
| 705004673 | LH FRONT FOOT SUPPORT RS-S | ||
| 705004180 | LH FRONT FOOTREST RS | ||
| 1 | 705004671 | LH FRONT FOOTREST RS-S | 1 |
| 1 | 705002359 | Rubber Pad RS | 1 |
| 2 | 250000099 | Allen Plastite Screw #12 RS | 2 |
| 1 | 705001701 | Spring RS | 1 |
| 1 | 705001702 | Retainer Pin RS | 1 |
| 1 | 705601030 | Circlip RS | 1 |
| 1 | 705004182 | RH Foot Support RS | 1 |
| 1 | 705004674 | RH Foot Support RS-S | 1 |
| 705004183 | RH FRONT FOOTREST RS | ||
| 1 | 705004672 | RH FRONT FOOTREST RS-S | 1 |
| 1 | 705003362 | Spring RS | 1 |
| 5 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 5 |
| 1 | 705004185 | LH Rear Foot Support RS | 1 |
| 1 | 705004678 | LH Rear Foot Support RS-S | 1 |
| 1 | 705004186 | LH REAR FOOTREST RS | 1 |
| 1 | 705004680 | LH REAR FOOTREST RS-S | 1 |
| 1 | 705001704 | Spring RS | 1 |
| 1 | 705001705 | Ball RS | 1 |
| 1 | 705001706 | Indexation Plate RS | 1 |
| 1 | 705004188 | RH Rear Foot Support RS | 1 |
| 1 | 705004679 | RH Rear Foot Support RS-S | 1 |
| 1 | 705004189 | RH REAR FOOTREST RS | 1 |
| 1 | 705004681 | RH REAR FOOTREST RS-S | 1 |
| 8 | 207581644 | Hex. Flange Screw M8 X 16, Scotch Grip | 8 |
| 705001572 | RED REAR LATERAL REFLECTOR North America | ||
| 705001573 | YELLOW REAR LATERAL REFLECTOR Europe | ||
| 4 | 293740028 | Dual Lock Velcro Washer 3/4" | 4 |
| 2 | 250000303 | Torx Truss Screw M6 X 20 | 2 |
| 2 | 233261494 | Hex. Flange Elastic Nut M6 North America | 2 |
| 3 | 234062670 | Stainless Steel Flat Washer | 3 |
