Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705001391 | Bumper Cover RS | 1 |
| 1 | 705004568 | Bumper Cover, Magnesium Color RS-S Magnesium-Black Model | 1 |
| 705004569 | BUMPER COVER, ALLOY ORANGE RS-S Alloy Orange-Black Model | ||
| 2 | 250100113 | Panel Nut, M6 X 1.0 | 2 |
| 4 | 250000446 | Torx Screw M6 X 20, Scotch Grip | 4 |
| 2 | 293150089 | Tuflok Plastic Rivet | 2 |
| 1 | 705004571 | Front Fascia, Metallic Magnesium RS Magnesium-Black Model | 1 |
| 1 | 705004572 | Steel Black Front Fascia RS-S Magnesium-Black Model | 1 |
| 1 | 705004573 | Front Fascia, Metallic Black RS-S Alloy Orange-Black Model | 1 |
| 705004574 | HOOD, METALLIC MAGNESIUM RS Magnesium-Black Model | ||
| 1 | 705004575 | Hood, Steel Black RS-S Magnesium-Black Model | 1 |
| 1 | 705004583 | Hood, Metallic Black RS-S Alloy Orange-Black Model | 1 |
| 1 | 219704451 | Was 293250240 Neoprene Seal | 1 |
| 1 | 269501482 | FRONT ARM | 1 |
| 230060060 | Hex. Screw M6 X 100 | ||
| 1 | 269501481 | REAR ARM | 1 |
| 1 | 230065060 | Hex. Screw M6 X 150 | 1 |
| 4 | 207065544 | Hex. Screw M6 X 55 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 2 | 414436900 | BLACK SNAP CAP | 2 |
| 4 | 269500706 | Sleeve | 4 |
| 1 | 269501387 | Nut Housing Ass'y | 1 |
| 1 | 705002223 | Lug | 1 |
| 2 | 232180600 | Hex. Jam Nut M8 | 2 |
| 1 | 234081410 | Flat Washer 8 mm | 1 |
| 1 | 705002224 | Latch | 1 |
| 1 | 705003911 | Spring | 1 |
| 2 | 207663544 | Hex. Flange Screw M6 X 35 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 1 | 517303484 | Hood Cable | 1 |
| 1 | 705004816 | Front Storage Compartment | 1 |
| 2 | 293740028 | Dual Lock Velcro Washer 3/4" | 2 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 4 | 210262080 | Hex. Forming Screw M6 X 20 | 4 |
| 2 | 705005156 | Oval Washer | 2 |
| 4 | 269501387 | Nut Housing Ass'y Europe | 4 |
| 1 | 705004596 | LH Front Panel, Metallic Magnesium Magnesium-Black Model | 1 |
| 1 | 705004600 | LH Front Panel, Alloy Orange RS-S Alloy Orange-Black Model | 1 |
| 1 | 705001541 | LH Air Duct North America | 1 |
| 1 | 705001469 | LH HEADLAMP BEZEL Europe | 1 |
| 1 | 705004796 | BLACK LH HEADLAMP SUPPORT Europe | 1 |
| 1 | 518325515 | LH FRONT PANEL FOAM | 1 |
| 1 | 705004597 | RH Front Panel, Metallic Magnesium Magnesium-Black Model | 1 |
| 1 | 705004601 | RH Front Panel, Alloy Orange RS-S Alloy Orange-Black Model | 1 |
| 2 | 250000350 | Torx Truss Screw M6 X 20 | 2 |
| 2 | 705003207 | Plastic Washer | 2 |
| 6 | 293150089 | Tuflok Plastic Rivet | 6 |
| 1 | 705001543 | RH Air Duct North America | 1 |
| 1 | 705001470 | RH Headlamp Bezel Europe | 1 |
| 1 | 705004797 | BLACK RH HEADLAMP SUPPORT Europe | 1 |
| 12 | 414479100 | Clip | 12 |
| 4 | 207682544 | Hex. Flange Screw M8 X 25 Europe | 4 |
| 1 | 518325516 | RH FRONT PANEL FOAM | 1 |
| 1 | 705002837 | Skid Plate | 1 |
| 6 | 250000081 | Torx Screw M6 X 25 | 6 |
| 1 | 705003456 | LH Fender Front Support | 1 |
| 1 | 705003457 | RH Fender Front Support | 1 |
| 1 | 705003462 | LH Fender Rear Support | 1 |
| 1 | 705003463 | RH Fender Rear Support | 1 |
| 2 | 705002389 | Central Front Fender Support | 2 |
| 1 | 705004613 | LH Front Fender, Metallic Magnesium RS Magnesium-Black Model | 1 |
| 1 | 705004615 | LH Front Fender, Steel Black RS-S Magnesium-Black Model | 1 |
| 1 | 705004617 | LH Front Fender, Matte Black RS-S Alloy Orange-Black Model | 1 |
| 1 | 705004614 | RH Front Fender, Metallic Magnesium RS Magnesium-Black Model | 1 |
| 1 | 705004616 | RH Front Fender, Steel Black RS-S Magnesium-Black Model | 1 |
| 705004618 | RH FRONT FENDER, MATTE BLACK RS-S Alloy Orange-Black Model | ||
| 1 | 705001767 | LH Mudguard | 1 |
| 1 | 705001768 | RH Mudguard | 1 |
| 8 | 207583534 | HEX. FLANGED SCREW S.GRIP M8 X 35 | 8 |
| 8 | 705600837 | BUSHING | 8 |
| 12 | 269500725 | M6 Nut Housing Ass'y | 12 |
| 12 | 207662084 | Hex. Flange Screw M6 X 20 | 12 |
| 4 | 250100113 | Panel Nut, M6 X 1.0 | 4 |
| 4 | 250000350 | Torx Truss Screw M6 X 20 | 4 |
| 705003025 | SERVICE CENTER | ||
| 2 | 705002423 | Amber, Lateral Reflector | 2 |
