Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705501406 | Rear Propeller Shaft Ass'y Includes 10 to 10e | 1 |
| 1 | 715900118 | Rubber Boot | 1 |
| 1 | 715900184 | Grease Fitting | 1 |
| 2 | 715900101 | Fixe Yoke | 2 |
| 2 | 715500371 | Universal Joint | 2 |
| 1 | 509000045 | Oetiker Gear Clamp 36.1MM | 1 |
| 1 | 293650138 | Oetiker Gear Clamp 44.0MM | 1 |
| 1 | 705501123 | Protector | 1 |
| 1 | 705400036 | Wear Ring | 1 |
| 705501419 | Rear Differential Ass'y Includes 30 to 30v | ||
| 1 | 705400027 | Oil Seal | 1 |
| 1 | 705500987 | Nut | 1 |
| 1 | 705500260 | Ball Bearing | 1 |
| 705500075 | Pinion Gear Shim .022" | ||
| 1 | 703500049 | Pinion Shim Kit | 1 |
| 1 | 705501162 | Pinion Gear Shim | 1 |
| 1 | 703500548 | Differential Shim Kit | 1 |
| 1 | 705501570 | 10 Teeth Pinion | 1 |
| 1 | 705501408 | Needle Bearing | 1 |
| 1 | 705500749 | Ball Bearing | 1 |
| 1 | 705501389 | Ball Bearing | 1 |
| 1 | 705501403 | 36 Teeth Pinion | 1 |
| 4 | 705500892 | SCREW | 4 |
| 1 | 705501507 | REAR DIFFERENTIAL COVER | 1 |
| 1 | 705500265 | Seal | 1 |
| 1 | 705501420 | PINION REAR COVER | 1 |
| 1 | 705500893 | VENT VALVE | 1 |
| 1 | 705500894 | Drain Plug | 1 |
| 1 | 705500267 | O-Ring | 1 |
| 2 | 705501196 | Oil Seal | 2 |
| 1 | 705500504 | Fill Level Plug | 1 |
| 1 | 705500506 | Copper Washer | 1 |
| 2 | 705501716 | Wheel Hub Ass'y 703501191 won't fit this unit - please order 705501716 or 705501900 | 2 |
| 8 | 250300048 | Wheel Stud Tightening Torque: See Bulletin ATV 2020-4 | 8 |
| 250000378 | HEX FLANGED SCREW M12 X 16, SCOTCH GRIP | ||
| 1 | 250200102 | Flat Washer M12 | 1 |
| 1 | 250000359 | Hex Flange Screw M12 x 16 | 1 |
| 2 | 250100047 | Hex. Castellated Nut M18 | 2 |
| 2 | 250400036 | Cotter Pin | 2 |
| 1 | 705501485 | Rear - Premium CV Axle Includes 230 to 230f | 1 |
| 705501776 | JOINT_CV EXT | ||
| 2 | 705501777 | Rubber Boot Kit Includes 230b to 230d | 2 |
| 1 | 715900241 | Oetiker Clamp, 82.1 mm | 1 |
| 1 | 715900242 | Oetiker Clamp, 27.3 mm | 1 |
| 705501780 | PLUNGING JOINT | ||
| 1 | 705501781 | Circlip | 1 |
| 2 | 705501842 | Joint Protector | 2 |
| 1 | 705501486 | Rear - Premium CV Axle Includes 240 to 240f | 1 |
| 2 | 705501777 | Rubber Boot Kit Includes 240b to 240d | 2 |
| 1 | 705501842 | Joint Protector | 1 |
| 2 | 705501124 | Wear Ring | 2 |
| 5 | 250000508 | Hex. Flange Screw M10 x 135 | 5 |
| 5 | 233201436 | Hex. Flange Elastic Nut M10 | 5 |
| 2 | 293350040 | Cone Bearing | 2 |
| 2 | 293370019 | Circlip | 2 |
| 2 | 250200049 | Spring Washer | 2 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
