Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 710001499 | HARNESS SUPPORT | 2 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 710001626 | LH FRONT LIGHT Includes 3 to 5 | ||
| 1 | 710000871 | Bulb, 12V 35/35W | 1 |
| 715900060 | BULB, 12V W5W | ||
| 1 | 710001763 | LH FRONT SUPPORT | 1 |
| 1 | 710001627 | RH FRONT LIGHT Includes 7 to 9 | 1 |
| 710001764 | RH FRONT SUPPORT | ||
| 2 | 250000128 | Torx Truss Screw M6 X 20 | 2 |
| 4 | 207563034 | Hex. Flange Screw M6 X 30, Scotch Grip | 4 |
| 4 | 250000048 | Panel Nut M6 X 1.0 | 4 |
| 2 | 233261434 | Flange Elastic Nut M6 | 2 |
| 293450274 | Insert | ||
| 2 | 207662034 | Hex. Flange Screw M6 X 20 | 2 |
| 1 | 710001079 | FLASHING LIGHT ASS'Y Includes 17 to 18 | 1 |
| 415129258 | BULB | ||
| 710001080 | FLASHING LIGHT ASS'Y Includes 19 to 20 | ||
| 1 | 710001302 | LH SUPPORT | 1 |
| 1 | 710001303 | RH SUPPORT | 1 |
| 205062034 | Socket Head Screw M6 X 20 | ||
| 4 | 293720053 | Grommet | 4 |
| 4 | 293900045 | Bushing | 4 |
| 4 | 224061201 | Flat Washer | 4 |
| 710001306 | MULTI FUNCTION SWITCH | ||
| 1 | 710000803 | Rectifier | 1 |
| 3 | 207551634 | Hex. Flange Screw, Scotch Grip | 3 |
| 1 | 710001207 | Ingnition Switch | 1 |
| 1 | 219704414 | Was 415110000 Polyurethane Hose 5.2 mm | 1 |
| 1 | 710001259 | Pilot Lamp, Low Fuel | 1 |
| 1 | 710001012 | PILOT LAMP, NEUTRAL | 1 |
| 1 | 710000760 | Tail Light Ass'y Includes 35 to 36 | 1 |
| 1 | 410504100 | Bulb | 1 |
| 2 | 293900089 | SPACER | 2 |
| 4 | 250200099 | FLAT WASHER | 4 |
| 2 | 293720053 | Grommet | 2 |
| 2 | 232561434 | Elastic Stop Nut M6 | 2 |
| 1 | 515175944 | HOUSING SUPPORT | 1 |
| 1 | 710001310 | PROTECTOR | 1 |
| 1 | 710001311 | PROTECTOR | 1 |
| 1 | 715500305 | Battery YUASA YT7B-BS | 1 |
| 710000963 | BATTERY SUPPORT | ||
| 4 | 708000506 | Rubber Stopper | 4 |
| 5 | 293830129 | RUBBER PAD | 5 |
| 1 | 710001364 | Starter Relay | 1 |
| 2 | 232061600 | Hex. Nut M6 | 2 |
| 2 | 234161601 | Lock Washer Helical M6 | 2 |
| 1 | 250000223 | Torx Screw M6 X 16 | 1 |
| 1 | 250200097 | Flat Washer | 1 |
| 1 | 233261434 | Flange Elastic Nut M6 | 1 |
| 710001074 | Housing Support | ||
| 2 | 414479100 | Clip | 2 |
| 2 | 515175283 | Housing Support | 2 |
| 2 | 207551634 | Hex. Flange Screw, Scotch Grip | 2 |
| 1 | 219704364 | Neoprene Seal (1PAC=3M) | 1 |
| 1 | 207551634 | Hex. Flange Screw, Scotch Grip | 1 |
| 207551034 | SCREW-HEX.FLANGE DIN.6921 S.GRIP | ||
| 1 | 234051430 | Flat Washer | 1 |
| 1 | 270000141 | Clip | 1 |
| 1 | 390909200 | Avex Rivet | 1 |
| 1 | 278002148 | Diagnostic Connector Cap | 1 |
| 1 | 293730018 | Mount Dart | 1 |
| 1 | 710000983 | Horn | 1 |
| 1 | 207682034 | Hex. Flange Screw | 1 |
| 1 | 233281434 | Hex. Flange Elastic Nut M8 | 1 |
| 710001080 | FLASHING LIGHT ASS'Y Includes 69 to 70 | ||
| 1 | 710001304 | LH FLASHING LIGHT SUPPORT | 1 |
| 1 | 710001079 | FLASHING LIGHT ASS'Y Includes 72 to 73 | 1 |
| 710001305 | RH FLASHING LIGHT SUPPORT | ||
| 1 | 205082534 | SOCKET HEAD SCREW M8 X 25 | 1 |
| 1 | 710001447 | FLASHER UNIT | 1 |
| 1 | 293650082 | Clamp | 1 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 1 | 710001526 | Calibrated Speedometer Includes 84 to 86 | 1 |
| 1 | 710001183 | Trim Ring Ass'y Includes 85 to 86 | 1 |
| 1 | 704901270 | BRP Logo 13 mm | 1 |
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 2 | 278000216 | Wire Seal | 2 |
