Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 703500770 | Rear Propeller Shaft Kit Includes 1 to 9 | 1 |
| 1 | 705500371 | Fix Joint | 1 |
| 2 | 703000022 | Unit Pack Kit | 2 |
| 705501072 | SLIDING JOINT | ||
| 703500255 | Rubber Boot Kit | ||
| 1 | 293650138 | Oetiker Gear Clamp 44.0MM | 1 |
| 705400148 | Collar | ||
| 705500526 | DISC JOINT | ||
| 1 | 705500841 | GREASE FITTING | 1 |
| 1 | 705501123 | Protector | 1 |
| 1 | 705400036 | Wear Ring | 1 |
| 1 | 705501412 | Rear Differential Ass'y Includes 12 to 31 | 1 |
| 1 | 705400027 | Oil Seal | 1 |
| 1 | 705500987 | Nut | 1 |
| 1 | 705500260 | Ball Bearing | 1 |
| 705500075 | Pinion Gear Shim .022" | ||
| 1 | 703500049 | Pinion Shim Kit | 1 |
| 705501163 | Pinion Gear Shim 2.12mm | ||
| 1 | 703500548 | Differential Shim Kit | 1 |
| 1 | 705501570 | 10 Teeth Pinion | 1 |
| 1 | 705500749 | Ball Bearing | 1 |
| 1 | 705501389 | Ball Bearing | 1 |
| 1 | 705501403 | 36 Teeth Pinion | 1 |
| 4 | 705500892 | SCREW | 4 |
| 1 | 705501393 | Rear Cover | 1 |
| 1 | 705500265 | Seal | 1 |
| 1 | 705501395 | PINION REAR COVER | 1 |
| 1 | 705500893 | VENT VALVE | 1 |
| 1 | 705500894 | Drain Plug | 1 |
| 1 | 705500267 | O-Ring | 1 |
| 2 | 705501196 | Oil Seal | 2 |
| 1 | 250400041 | Screw Plug | 1 |
| 1 | 705500506 | Copper Washer | 1 |
| 705501199 | WHEEL HUB ASS'Y Includes 34 to 35 | ||
| 4 | 250300045 | Wheel Stud | 4 |
| 1 | 703500722 | Protector Kit | 1 |
| 4 | 207662544 | Hex. Flange Screw M6 X 25 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 4 | 250200082 | Flat Washer | 4 |
| 1 | 250000359 | Hex Flange Screw M12 x 16 | 1 |
| 1 | 250200102 | Flat Washer M12 | 1 |
| 1 | 705400352 | Rubber Bellow | 1 |
| 1 | 293650042 | Oetiker Clamp | 1 |
| 2 | 705400963 | Wheel Cap | 2 |
| 705400962 | TIRE_30X9R14 | ||
| 2 | 705400877 | Rim | 2 |
| 2 | 705400193 | Rim Valve With Cap | 2 |
| 1 | 219704465 | 1/2 Oz Weight | 1 |
| 2 | 293000110 | Valve Cap | 2 |
| 8 | 250100100 | Black Wheel Nut M10 X 1.25 | 8 |
| 2 | 250100047 | Hex. Castellated Nut M18 | 2 |
| 2 | 250400036 | Cotter Pin | 2 |
| 1 | 705500979 | LH CV Joint Ass'y Includes 61 to 64 | 1 |
| 705500980 | CV JOINT | ||
| 2 | 705500870 | Boot Kit Includes 63 to 63b | 2 |
| 1 | 293650203 | Oetiker Clamp (27,5mm) | 1 |
| 1 | 293650204 | OETIKER CLAMP | 1 |
| 1 | 705500845 | CIRCLIP | 1 |
| 1 | 705500983 | RH CV Joint Ass'y Includes 65 to 68 | 1 |
| 2 | 705500870 | Boot Kit Includes 67 to 67b | 2 |
| 3 | 230603036 | HEX. FLANGED SCREW M10 X 130 | 3 |
| 230603536 | HEX. FLANGED SCREW M10 X 135 | ||
| 4 | 233201436 | Hex. Flange Elastic Nut M10 | 4 |
| 2 | 293350040 | Cone Bearing | 2 |
| 2 | 705501124 | Wear Ring | 2 |
| 2 | 705501121 | Wear Sleeve | 2 |
| 2 | 293370019 | Circlip | 2 |
| 2 | 250200049 | Spring Washer | 2 |
