Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 5EB-Y2410-30-09 | Fuel Tank Comp DPBMC/BWC1 (5MT9) | ||
| 5MT-24244-00-00 | . Graphic, Fuel Tank 1 (5MT9) | ||
| 5MT-24161-00-00 | . Emblem 1 (5MT9) | ||
| 4TV-2153A-40-00 | . .Emblem, Yamaha (5MT9) | ||
| 5MT-24191-00-00 | Bracket, Fuel Tank 1 (5MT9) | ||
| 5EB-24181-00-00 | Damper, Locating 1 (5MT9) | ||
| 1 | 2GH-24183-00-00 | Damper, Locating 3 (5MT9) | 1 |
| 1 | 2GH-24186-00-00 | Washer, Special (5MT9) | 1 |
| 2 | 90387-06027-00 | Collar (5MT9) | 2 |
| 2 | 97007-06030-00 | Bolt (5MT9) | 2 |
| 2 | 92907-06600-00 | Washer, Plate (5MT9) | 2 |
| 2 | 90159-06005-00 | Screw, With Washer (5MT9) | 2 |
| 2 | 5EB-24183-00-00 | Damper, Locating 3 (5MT9) | 2 |
| 1 | 90387-061W6-00 | Collar (5MT9) | 1 |
| 1 | 91317-06090-00 | Bolt (5MT9) | 1 |
| 90201-06050-00 | Washer, Plate (5MT9) | ||
| 2 | 5EB-24182-00-00 | Damper, Locating 2 (5MT9) | 2 |
| 1 | 4TV-24500-00-00 | Fuel Cock Assy 1 (5MT9) | 1 |
| 1 | 3XV-24523-00-00 | . Valve (5MT9) | 1 |
| 1 | 3XV-24534-00-00 | . Seal, Cock (5MT9) | 1 |
| 1 | 4X8-24512-00-00 | . O-Ring (5MT9) | 1 |
| 2 | 90149-06008-00 | Screw, Special Shape (5MT9) | 2 |
| 2 | 90202-05193-00 | Washer, Plate (5MT9) | 2 |
| 1 | 5EB-24311-00-00 | Pipe, Fuel 1 (5MT9) | 1 |
| 1 | 5EB-24312-00-00 | Pipe 2 (5MT9) | 1 |
| 4 | 90467-14057-00 | Clip (5MT9) | 4 |
| 5EB-2417H-00-00 | Clamp 1 (5MT9) | ||
| 1 | 95027-06012-00 | Bolt, Flange (5MT9) | 1 |
| 1 | 5JJ-24602-00-00 | Cap Assy (5MT9) | 1 |
| 3 | 90110-05112-00 | Bolt, Hexagon Socket Head (5MT9) | 3 |
| 1 | 91317-05010-00 | Bolt (5MT9) | 1 |
| 1 | 4TV-24560-00-00 | Filter Assy (5MT9) | 1 |
| 1 | 1AE-24366-00-00 | Clamp, Fuel Pipe 1 (5MT9) | 1 |
| 1 | 98507-06012-00 | Screw, Pan Head (5MT9) | 1 |
| 1 | 92907-06600-00 | Washer, Plate (5MT9) | 1 |
| 5EB-24491-00-00 | Bracket, Fuel Pump (5MT9) | ||
| 1 | 98507-05010-00 | Screw, Pan Head (5MT9) | 1 |
| 2 | 90480-13163-00 | Grommet (5MT9) | 2 |
| 2 | 90387-060G7-00 | Collar (5MT9) | 2 |
| 2 | 90119-06096-00 | Bolt, With Washer (5MT9) | 2 |
| 1 | 90445-102G9-00 | Hose (L650) (5MT9) | 1 |
| 1 | 90464-12089-00 | Clamp (5MT9) | 1 |
| 5EB-2414K-00-00 | Damper, Plate 3 (5MT9) | ||
| 5EB-2414H-00-00 | Damper, Plate 1 (5MT9) | ||
| 5EB-2411J-00-00 | Damper, Side Cover (5MT9) | ||
| 5EB-2414J-00-00 | Damper, Plate 2 (5MT9) | ||
| 5 | 90467-10008-00 | Clip (5MT9) | 5 |
| 4DU-24321-00-00 | Pipe 10 (5MT9) | ||
| 1 | 3UH-24180-00-00 | Roll Over Valve Assy (5MT9) | 1 |
| 5GV-24314-00-00 | Pipe 4 (5MT9) | ||
| 5GV-24170-00-00 | Canister Assy (5MT9) | ||
| 5GV-2419F-00-00 | Bracket, Canistor (5MT9) | ||
| 2 | 90480-13018-00 | Grommet (5MT9) | 2 |
| 2 | 90387-062L2-00 | Collar (5MT9) | 2 |
| 2 | 90110-06200-00 | Bolt, Hexagon Socket Head (5MT9) | 2 |
| 2 | 95027-06014-00 | Bolt, Flange (5MT9) | 2 |
| 1 | 5GV-14149-00-00 | Pipe (5MT9) | 1 |
| 1 | 3H3-24376-00-00 | Pipe, Joint 1 (5MT9) | 1 |
| 5GV-14465-00-00 | Pipe (5MT9) | ||
| 6 | 90467-10008-00 | Clip (5MT9) | 6 |
| 1 | 5EB-13907-00-00 | Fuel Pump Comp (5MT9) | 1 |
| 1 | 5EB-14294-00-00 | Hose (5MT9) | 1 |
| 2 | 90467-11044-00 | Clip (5MT9) | 2 |
