Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 3JP-21711-00-00 | COVER, SIDE 1 | |
| 2 | 1UT-21783-00-00 | EMBLEM 3 | |
| 3 | 3JP-21721-00-00 | COVER, SIDE 2 | |
| 4 | 1UT-21784-00-00 | EMBLEM 4 | 1 |
| 5 | 90110-06102-00 | BOLT, HEXAGON SOCKET HEAD | 4 |
| 6 | 92907-06200-00 | WASHER | 4 |
| 7 | 2N4-21717-00-00 | DAMPER | 2 |
| 8 | 3JP-21731-00-00 | COVER, SIDE 3 | 1 |
| 9 | 3JP-21741-00-00 | COVER, SIDE 4 | |
| 10 | 1FK-21778-00-00 | DAMPER, LOCATING 1 | 4 |
| 11 | 90183-06008-00 | NUT, SPRING | 8 |
| 12 | 1FK-21747-00-00 | DAMPER | 2 |
| 13 | 92014-06012-00 | BOLT, BUTTON HEAD | 2 |
| 14 | 92014-06025-00 | BOLT, BUTTON HEAD | 2 |
| 15 | 1FK-2172G-00-00 | PANEL 3 | 1 |
| 16 | 1FK-2837N-00-00 | GRILL, AIR INTAKE 1 | |
| 17 | 1FK-2172H-00-00 | PANEL 4 | 1 |
| 18 | 1FK-2837R-00-00 | GRILL, AIR INTAKE 2 | 1 |
| 19 | 90111-05012-00 | BOLT, HEX. SOCKET BUTTON | 6 |
| 20 | 1FK-2172W-00-00 | COVER | 1 |
| 21 | 90468-03178-00 | CLIP | |
| 22 | 1FK-2172A-01-00 | PANEL 1 | 1 |
| 23 | 1FK-2172F-00-00 | PANEL 2 | 1 |
| 24 | 98507-06020-00 | SCREW, PAN HEAD | 3 |
| 25 | 92907-06600-00 | WASHER, PLATE | 3 |
| 26 | 98507-06016-00 | SCREW,PAN HEAD | 3 |
| 27 | 92907-06600-00 | WASHER, PLATE | 3 |
| 28 | 1FK-2171E-00-00 | COVER, SIDE 5 | 1 |
| 29 | 1FK-2171T-00-00 | MOLE, SIDE COVER 5 | |
| 30 | 97707-40512-00 | SCREW, TAPPING | 1 |
| 31 | 92907-04200-00 | WASHER | 1 |
| 32 | 90183-04027-00 | NUT, SPRING | 1 |
| 33 | 1FK-2171X-00-00 | COVER, SIDE 6 | 1 |
| 34 | 1FK-2171U-00-00 | MOLE, SIDE COVER 6 | |
| 35 | 90480-12296-00 | GROMMET | 1 |
| 36 | 1FK-Y217F-00-P5 | COVER, TOP (FUEL TANK) MBL2 | |
| 37 | 5GK-2173L-00-00 | GRAPHIC SET 1 | |
| 38 | 1FK-2175J-00-00 | LEVER LOCK COMP. | |
| 39 | 95807-06010-00 | BOLT, FLANGE | 2 |
| 40 | 1FK-21746-00-00 | DAMPER | 2 |
| 41 | 1FK-28345-00-00 | MOLE 1 | 1 |
| 42 | 1FK-2171H-00-00 | GUIDE | 6 |
| 43 | 1FK-2171L-00-00 | MOLE, SIDE COVER 1 | 1 |
| 44 | 1FK-21732-00-00 | SEAL 1 | |
| 45 | 1FK-21781-00-00 | EMBLEM 1 | 1 |
| 46 | 1FK-21782-00-00 | EMBLEM 2 | 1 |
| 47 | 1FK-21779-00-00 | DAMPER, LOCATING 2 | 2 |
| 48 | 1FK-2172M-00-00 | BRACKET 3 | 1 |
| 49 | 18A-24724-00-00 | DAMPER, SEAT | 1 |
| 50 | 97007-06012-00 | 97017-06012-00 | 4 |
| 51 | 92907-06600-00 | WASHER, PLATE | 4 |
| 52 | 1FK-21708-00-00 | LOCK ASSY 2 | |
| 53 | 1FK-24796-00-00 | COVER | |
| 54 | 95707-06500-00 | NUT, FLANGE | 2 |
| 55 | 1FK-2176U-00-00 | SHAFT, LOCK | 1 |
| 56 | 1FK-2175K-00-00 | LEVER, LOCK | |
| 57 | 99001-05600-00 | CIRCLIP | 2 |
| 58 | 1FK-2176V-00-00 | SPRING, LOCK 2 | 1 |
| 59 | 1FK-21243-01-00 | PLATE, BRIDGE | |
| 60 | 97007-06012-00 | 97017-06012-00 | 4 |
| 61 | 92907-06600-00 | WASHER, PLATE | 4 |
| 62 | 1FK-2172K-01-00 | BRACKET 1 | 1 |
| 63 | 98507-06040-00 | SCREW, PAN HEAD | 2 |
| 64 | 92907-06600-00 | WASHER, PLATE | 2 |
| 65 | 90480-15235-00 | GROMMET | 2 |
| 66 | 90387-060A7-00 | COLLAR | 2 |
| 67 | 90201-06380-00 | WASHER, PLATE | 2 |
| 68 | 95707-06500-00 | NUT, FLANGE | 2 |
| 69 | 3UF-21359-00-00 | BRACKET, COIL | 1 |
| 70 | 1FK-2171M-00-00 | MOLE, SIDE COVER 2 | 2 |
| 71 | 97007-06012-00 | 97017-06012-00 | 2 |
| 72 | 92907-06600-00 | WASHER, PLATE | 2 |
| 73 | 2N4-21717-00-00 | DAMPER | 1 |
| 74 | 214-84153-60-00 | GROMMET, WIRE HARNESS | 1 |
| 75 | 1FK-2177G-00-00 | BOX, BATTERY | |
| 76 | 90119-06056-00 | BOLT, WITH WASHER | 2 |
| 77 | 1FK-21871-00-00 | TANK, RECOVERY | 1 |
| 78 | 1FK-21816-00-00 | PIPE 1 | 1 |
| 79 | 26H-21875-00-00 | CAP | 1 |
| 80 | 26H-21874-00-00 | GASKET | 1 |
| 81 | 26H-21816-01-00 | PIPE 1 | |
| 82 | 26H-21828-00-00 | ELBOW | 1 |
| 83 | 90467-11019-00 | CLIP | 1 |
| 84 | 1FK-21826-00-00 | PIPE, BREATHER | |
| 85 | 90467-09006-00 | CLIP, SCISSOR | 1 |
| 86 | 1FK-2177M-00-00 | DAMPER, LOCATING 3 | |
| 87 | 5Y9-12491-00-00 | CLAMP 1 | 1 |
| 88 | 4KB-21268-00-00 | SEAL | 1 |
| 89 | 3TU-28344-00-00 | TAPE | 1 |
| 90 | 3JP-2179V-F0-00 | PLATE, EPA 2 (NON CALIFORNIA) | |
| 90 | 3JP-2179R-F0-00 | PLATE, EPA 2 (CALIFORNIA) |
