Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2J2-14101-00-00 | Carburetor Assembly 1 | ||
| 1 | 193-14142-25-A0 | . Jet, Pilot 25 | 1 |
| 2H0-14141-48-00 | . Nozzle, Main | ||
| 1 | 583-14148-00-00 | . Pipe | 1 |
| 137-14143-58-A1 | . Jet, Main (#290) U.R. | ||
| 1 | 137-14143-60-A0 | . Jet, Main (#300) U.R.STD | 1 |
| 137-14143-62-A1 | . Jet, Main (#310) U.R. | ||
| 1 | 2H0-14190-28-00 | . Needle Valve Assembly | 1 |
| 1 | 8F2-14147-00-00 | . O-Ring | 1 |
| 1 | 98511-04006-00 | . Screw, Pan Head | 1 |
| 1 | 2H0-14146-00-00 | . .Plate | 1 |
| 2H0-14185-00-00 | . Float | ||
| 1 | 537-14186-00-00 | . Pin, Float | 1 |
| 1 | 2H0-14184-00-00 | . Gasket, Float Chmbr | 1 |
| 99999-01150-00 | Body, Float Chamber | ||
| 4 | 92990-05100-00 | . .Washer, Spring | 4 |
| 4 | 98580-05016-00 | . Screw, Pan Head | 4 |
| 2H0-14191-00-00 | . Plug, Drain | ||
| 2 | 583-14561-00-00 | . .O-Ring | 2 |
| 1 | 2J2-14940-00-00 | . Diaphragm Assembly | 1 |
| 2J2-14933-00-00 | . Spring, Diaphragm | ||
| 2J2-14958-00-00 | Cover, Diaphragm | ||
| 3 | 92901-04100-00 | . Washer, Spring | 3 |
| 3 | 98580-05016-00 | . Screw, Pan Head | 3 |
| 2H0-14589-00-00 | Spring | ||
| 1 | 2H0-14940-00-00 | . Diaphragm Assembly | 1 |
| 2H0-14905-00-00 | . Lever, Starter | ||
| 4 | 92901-04100-00 | . Washer, Spring | 4 |
| 98511-04012-00 | . Screw, Pan Head | ||
| 2H0-14112-35-00 | Valve, Throttle 1 | ||
| 239-14116-25-00 | . Needle | ||
| 2H0-14131-00-00 | . Spring, Thrtl Valve | ||
| 2H0-14235-00-00 | . Washer, Needle | ||
| 1 | 164-14137-00-00 | . Clip | 1 |
| 2H0-14194-00-00 | . Ring | ||
| 2H0-14936-00-00 | Seat, Spring | ||
| 2H0-14291-00-00 | Bracket 1 | ||
| 583-14292-00-00 | Lever, Throttl.Valv | ||
| 583-14592-00-00 | . Screw | ||
| 583-14597-00-00 | Washer | ||
| 583-14274-00-00 | Connector | ||
| 1T2-14933-00-00 | Spring, Diaphragm | ||
| 583-14558-00-00 | Washer | ||
| 583-14386-00-00 | Pin, Float | ||
| 583-14951-00-00 | Washer | ||
| 583-14216-00-00 | Screw | ||
| 1 | 583-14536-00-00 | . Gasket | 1 |
| 583-14158-00-00 | Top, Mixing Chamber | ||
| 2 | 98503-04014-00 | . Screw, Pan Head | 2 |
| 2H0-14171-00-00 | . Plunger, Starter | ||
| 256-14135-00-00 | . Spring, Plunger | ||
| 583-14562-00-00 | . O-Ring | ||
| 2H0-14174-00-00 | . Cap, Plunger | ||
| 802-14173-00-00 | . Cover, Plunger Cap | ||
| 583-14918-00-00 | . Ring | ||
| 737-14137-00-00 | . .Clip | ||
| 2H0-14175-00-00 | . Lever, Starter 1 | ||
| 2H0-14218-00-00 | . Spring, Choke Lever | ||
| 2J2-14178-00-00 | Plate, Starter Lvr | ||
| 2J2-14962-00-00 | . Washer | ||
| 2J2-14194-00-00 | . Ring | ||
| 1 | 98503-06014-00 | . Screw, Pan Head (92502-06016- | 1 |
| 2H0-14198-00-00 | . Gasket | ||
| 1 | 2H0-14217-00-00 | . Pump Body Assembly | 1 |
| 2H0-14933-00-00 | Spring, Diaphragm | ||
| 2H0-14958-00-00 | Cover, Diaphragm | ||
| 3 | 98511-04025-00 | . Screw, Pan Head | 3 |
| 2H0-14212-00-00 | . Spring, Pilot Adjusting | ||
| 1 | 2H0-14147-00-00 | . .O-Ring | 1 |
| 2H0-14211-00-00 | . Screw, Pilot Adjusting | ||
| 2J2-14571-00-00 | Bracket, Throttle | ||
| 2 | 98580-05012-00 | . .Screw, Pan Head | 2 |
| 583-14245-00-00 | . Screw, Guide | ||
| 583-14133-00-00 | . Spring, Thrtl Stop | ||
| 2J2-14121-00-00 | Screw, Thrtl Stop | ||
| 583-14131-01-00 | . Spring, Thrtl Valve | ||
| 583-14239-01-00 | . Seal | ||
| 583-14265-00-00 | . Collar | ||
| 2H0-14215-00-00 | Shaft, Thrtl Lever | ||
| 2J2-14573-00-00 | . Bracket | ||
| 1 | 92990-08100-00 | . Washer, Spring | 1 |
| 1 | 812-14594-00-00 | . Nut | 1 |
| 583-14264-00-00 | . Spacer | ||
| 2J2-14992-00-00 | . Rod | ||
| 2H0-14992-00-00 | . Rod | ||
| 91401-10015-00 | . Pin, Cotter | ||
| 2J2-14589-00-00 | . Spring | ||
| 2H0-14227-00-00 | . Washer | ||
| 2H0-14534-00-00 | . Collar | ||
| 1 | 90445-081F2-00 | . Hose (L200) | 1 |
| 1 | 2J2-14196-00-00 | . Pipe | 1 |
| 1 | 2J2-14133-00-00 | . ..Spring, Throttle Stop | 1 |
