Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 06911-HL4-A01 | BRG SET,NEEDLE | ||
| 1 | 12361-035-000 | CAP, TAPPET ADJUSTING HOLE | 1 |
| 12361-300-000 | CAP, VALVE ADJ. | ||
| 12361-371-980 | CAP, VALVE ADJ. | ||
| 1 | 30535-HL6-A00 | STAY, HARNESS CLIP | 1 |
| 1 | 38510-HL6-A01 | SENSOR, RR. WHEEL SPEED | 1 |
| 1 | 41300-HL6-AA0 | GEAR, RR. FINAL | 1 |
| 1 | 41305-HL4-A00 | RING, STOPPER | 1 |
| 1 | 41311-HL6-A02 | CASE SUB-ASSY., RR. | 1 |
| 1 | 41312-HL6-A02 | COVER SUB-ASSY., RR. | 1 |
| 1 | 41330-HL6-A01 | JOINT, RR. PINION | 1 |
| 1 | 41421-HL6-A01 | GEAR, RR. PINION (13T) | 1 |
| 1 | 41430-HL6-A01 | GEAR, RR. RING (46T) | 1 |
| 1 | 41436-MB0-310 | PIN, RING GEAR STOPPER | 1 |
| 1 | 41437-MB0-310 | SHIM A, STOPPER PIN (0.10) | 1 |
| 1 | 41438-MB0-310 | SHIM B, STOPPER PIN (0.15) | 1 |
| 2 | 41447-HL4-A00 | SHIM A, FINAL GEAR (0.64) | 2 |
| 2 | 41448-HL4-A00 | SHIM B, FINAL GEAR (0.70) | 2 |
| 2 | 41449-HL4-A00 | SHIM C, FINAL GEAR (0.76) | 2 |
| 2 | 41450-HL4-A00 | SHIM D, FINAL GEAR (0.82) | 2 |
| 2 | 41451-HL4-A00 | SHIM E, FINAL GEAR (0.88) | 2 |
| 2 | 41452-HL4-A00 | SHIM F, FINAL GEAR (0.94) | 2 |
| 2 | 41453-HL4-A00 | SHIM G, FINAL GEAR (1.00) | 2 |
| 2 | 41454-HL4-A00 | SHIM H, FINAL GEAR (1.06) | 2 |
| 2 | 41455-HL4-A00 | SHIM I, FINAL GEAR (1.12) | 2 |
| 2 | 41456-HL4-A00 | SHIM J, FINAL GEAR (1.18) | 2 |
| 2 | 41457-HL4-A00 | SHIM K, FINAL GEAR (1.24) | 2 |
| 2 | 41458-HL4-A00 | SHIM L, FINAL GEAR (1.30) | 2 |
| 2 | 41459-HL4-A00 | SHIM M, FINAL GEAR (1.36) | 2 |
| 2 | 41460-HL4-A00 | SHIM N, FINAL GEAR (1.42) | 2 |
| 2 | 41461-HL4-A00 | SHIM O, FINAL GEAR (1.48) | 2 |
| 2 | 41462-HL4-A00 | SHIM P, FINAL GEAR (1.54) | 2 |
| 2 | 41463-HL4-A00 | SHIM Q, FINAL GEAR (1.60) | 2 |
| 1 | 41450-MEC-000 | SHIM A, PINION GEAR (1.32) | 1 |
| 1 | 41451-MEC-000 | SHIM B, PINION GEAR (1.38) | 1 |
| 1 | 41452-MEC-000 | SHIM C, PINION GEAR (1.44) | 1 |
| 1 | 41453-MEC-000 | SHIM D, PINION GEAR (1.50) | 1 |
| 1 | 41454-MEC-000 | SHIM E, PINION GEAR (1.56) | 1 |
| 1 | 41455-MEC-000 | SHIM F, PINION GEAR (1.62) | 1 |
| 1 | 41456-MEC-000 | SHIM G, PINION GEAR (1.68) | 1 |
| 1 | 41531-HL6-A00 | SPACER, RR. FINAL | 1 |
| 2 | 90109-371-000 | BOLT, SEALING (8MM) | 2 |
| 1 | 90119-HL6-A00 | BOLT, FLANGE (10X161) | 1 |
| 1 | 90120-HL6-A00 | BOLT, FLANGE (10X142) | 1 |
| 6 | 90133-HP5-600 | BOLT, FLANGE (8X27) | 6 |
| 2 | 90134-HP5-600 | BOLT, FLANGE (10X35) | 2 |
| 1 | 90138-MFR-670 | BOLT, PINION JOINT | 1 |
| 2 | 90161-T2F-A01 | BOLT, FLANGE (10X30) | 2 |
| 1 | 90242-MCH-000 | NUT, LOCK (75MM) | 1 |
| 2 | 90305-HC0-770 | NUT, SELF-LOCK (10MM) | 2 |
| 2 | 90471-580-000 | WASHER (8MM) | 2 |
| 1 | 90501-K87-A00 | WASHER, PLAIN (16.4X32X2) | 1 |
| 1 | 90512-HL6-A00 | WASHER (31X40X2.6) | 1 |
| 1 | 90652-HF7-003 | JOINT, BREATHER TUBE | 1 |
| 2 | 90682-MGS-D41 | CLIP, CABLE | 2 |
| 2 | 91003-RY0-003 | BEARING, BALL (40X75X16) | 2 |
| 1 | 91051-HL6-A41 | BEARING, RADIAL BALL (30X72X19) | 1 |
| 2 | 91258-HL6-A01 | OIL SEAL (37.1X57X7) | 2 |
| 1 | 91259-HL6-A02 | OIL SEAL (40.5X79X10) | 1 |
| 1 | 91302-001-020 | O-RING (30.8MM) (Honda Code 0001065) | 1 |
| 1 | 91306-MG3-000 | O-RING (1.5X9.5) | 1 |
| 1 | 91312-KM9-003 | O-RING (24X3) | 1 |
| 1 | 94301-06100 | PIN A, DOWEL (6X10) (YAMADA) | 1 |
| 1 | 95002-02650 | CLIP, TUBE (B6.5) | 1 |
| 1 | 95005-35008-10M | BULK HOSE, VACUUM (3.5X8000) (3.5X1000) | 1 |
| 3 | 96001-06014-00 | BOLT, FLANGE (6X14) | 3 |
