Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 47110-37H00-019 | COVER, FRAME RH (BLACK) FOR 019 | 1 |
| 47110-37H00-YPA | COVER, FRAME RH (WHITE) FOR YPA | ||
| 47110-37H00-YKV | COVER, FRAME RH (BLACK) FOR ECE | ||
| 47110-37H00-YBD | COVER, FRAME RH (BLUE) FOR GLR | ||
| 1 | 47210-37H00-019 | COVER, FRAME LH (BLACK) FOR 019 | 1 |
| 47210-37H00-YPA | COVER, FRAME LH (WHITE) FOR YPA | ||
| 47210-37H00-YKV | COVER, FRAME LH (BLACK) FOR ECE | ||
| 47210-37H00-YBD | COVER, FRAME LH (BLUE) FOR GLR; Includes Item(s) 3 - 7 | ||
| 4 | 09321-06026 | CUSHION | 4 |
| 1 | 47112-37H00 | TAPE, RH | 1 |
| 1 | 47212-37H00 | TAPE, LH | 1 |
| 2 | 47114-37H00 | CUSHION | 2 |
| 2 | 47115-37H00 | CUSHION | 2 |
| 2 | 47113-37H00 | CUSHION, FRONT | 2 |
| 4 | 09409-06328 | CLIP | 4 |
| 6 | 09409-06314-5PK | CLIP (BLACK) | 6 |
| 47310-37HA0-YKV | COVER, FRAME CENTER (BLACK) FOR 019; Includes Item(s) 12 - 14 | ||
| 68131-37HA0-GTT | EMBLEM | ||
| 2 | 09321-10002 | CUSHION | 2 |
| 1 | 44572-13G10 | .FASTENER (33X25) | 1 |
| 47310-37H00-5WX | COVER, FRAME CENTER (WHITE) FOR YPA | ||
| 1 | 47310-37H00-YME | COVER, FRAME CENTER (ORANGE) FOR ECE | 1 |
| 1 | 47310-37H00-YSF | COVER, FRAME CENTER (BLUE) FOR GLR; Includes Item(s) 16 - 18 | 1 |
| 68131-21H00-YLC | EMBLEM (GOLD) FOR 5WX | ||
| 1 | 68131-21H00-019 | EMBLEM (BLACK) FOR YME | 1 |
| 1 | 68131-21H00-YBD | EMBLEM (WHITE) FOR YSF | 1 |
| 3 | 09136-06056 | BOLT, CENTER | 3 |
| 3 | 47312-37H00 | CUSHION, CENTER | 3 |
| 3 | 09180-06283 | SPACER | 3 |
| 1 | 47910-37H00-YKV | COVER, FRAME REAR (BLACK) FOR 019 | 1 |
| 1 | 47910-37H00-YPA | COVER, FRAME REAR (WHITE) FOR YPA | 1 |
| 47910-37H00-YME | COVER, FRAME REAR (ORANGE) FOR ECE | ||
| 1 | 47910-37H00-YSF | COVER, FRAME REAR (BLUE) FOR GLR; Includes Item(s) 23 - 24 | 1 |
| 1 | 47913-37H00 | CUSHION | 1 |
| 5 | 47912-37H00 | FASTENER,FRAME COVER (15X25) | 5 |
| 47710-37HA0-019 | COVER, FRAME REAR RH (BLACK) FOR 019 | ||
| 47710-37HA0-YPA | COVER, FRAME REAR RH (WHITE) FOR YPA | ||
| 1 | 47810-37HA0-019 | COVER, FRAME REAR LH (BLACK) FOR 019 | 1 |
| 47810-37HA0-YPA | COVER, FRAME REAR LH (WHITE) FOR YPA; Includes Item(s) 27 - 32 | ||
| 1 | 68135-37HA0-GTR | TAPE, RH FOR 019 | 1 |
| 68135-37HA0-GTS | TAPE, RH FOR YPA | ||
| 1 | 68145-37HA0-GTR | TAPE, LH FOR 019 | 1 |
| 68145-37HA0-GTS | TAPE, LH FOR YPA | ||
| 2 | 47712-37H00 | CUSHION, COVER UPPER | 2 |
| 2 | 47713-37H00 | CUSHION, SIDE | 2 |
| 2 | 45516-01H00 | CUSHION | 2 |
| 2 | 45517-16G00 | TAPE | 2 |
| 47710-37H00-019 | COVER, FRAME REAR RH (BLACK) FOR ECE | ||
| 1 | 47710-37H00-YSF | COVER, FRAME REAR RH (BLUE) FOR GLR | 1 |
| 47810-37H00-019 | COVER, FRAME REAR LH (BLACK) FOR ECE | ||
| 1 | 47810-37H00-YSF | COVER, FRAME REAR LH (BLUE) FOR GLR; Includes Item(s) 35 - 39 | 1 |
| 68131-37H00-GTW | EMBLEM FOR 019 | ||
| 68131-37H00-LV8 | EMBLEM FOR YSF | ||
| 2 | 09409-06328 | CLIP | 2 |
| 6 | 03541-0512A | SCREW | 6 |
