Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 4WM-YK241-31-P7 | FUEL TANK COMP. Use for Color Black Metallic X ( SMX / 0903 ) | |
| 2 | 2YK-24181-10-00 | DAMPER, LOCATING 1 | 2 |
| 3 | 5MB-24191-00-00 | BRACKET, FUEL TANK 1 | 1 |
| 4 | 5MB-24192-00-00 | BRACKET, FUEL TANK 2 | 1 |
| 5 | 5MB-24181-00-00 | DAMPER, LOCATING 1 | 2 |
| 6 | 5MB-24182-00-00 | DAMPER, LOCATING 2 | 2 |
| 7 | 5MB-24183-00-00 | DAMPER, LOCATING 3 | 2 |
| 8 | 5MB-24186-00-00 | WASHER, SPECIAL | 1 |
| 9 | 2GH-24186-00-00 | WASHER, SPECIAL | 1 |
| 10 | 90387-06062-00 | COLLAR | 4 |
| 11 | 92017-06035-00 | BOLT, BUTTON HEAD | 4 |
| 12 | 95827-06140-00 | BOLT, FLANGE | |
| 13 | 90201-064R0-00 | WASHER, PLATE | 2 |
| 14 | 90176-06055-00 | NUT, CROWN | 1 |
| 15 | 90387-06061-00 | COLLAR | 1 |
| 16 | 4WM-24291-00-00 | BRACKET, FUEL TANK 1 | 2 |
| 17 | 4WM-24339-00-00 | GROMMET | 4 |
| 18 | 90387-050T5-00 | COLLAR | 4 |
| 19 | 95707-05500-00 | NUT, FLANGE | 4 |
| 20 | 4WM-24500-02-00 | FUEL COCK ASSY 1 | 1 |
| 21 | 3AC-24523-00-00 | VALVE PACKING | 1 |
| 22 | 3AJ-24534-01-00 | SEAL, COCK | 1 |
| 23 | 97801-03008-00 | SCREW, PAN HEAD | 2 |
| 24 | 4X8-24512-00-00 | O-RING | 1 |
| 25 | 90202-05193-00 | WASHER, PLATE | 2 |
| 26 | 90149-06011-00 | SCREW | 2 |
| 27 | 5VN-24311-00-00 | PIPE, FUEL 1 | 1 |
| 28 | 4WM-24393-00-00 | SPRING | |
| 29 | 90467-11044-00 | CLIP | 2 |
| 30 | 90467-13083-00 | CLIP | 2 |
| 31 | 1FK-24560-10-00 | FILTER ASSY | 1 |
| 32 | 4WM-24312-00-00 | PIPE 2 | 1 |
| 33 | 4WM-24394-00-00 | SPRING | |
| 34 | 4WM-24398-00-00 | BAND 1 | 1 |
| 35 | 4WM-24217-00-00 | COVER | 1 |
| 36 | 4NK-24602-11-00 | CAP ASSY | 1 |
| 37 | 5VN-24321-00-00 | PIPE 10 U49 (2D99) | |
| 5VN-24321-10-00 | PIPE 10 CA (2D9A) | 1 | |
| 38 | 90467-09002-00 | CLIP | 1 |
| 39 | 90467-09006-00 | CLIP | 1 |
| 40 | 90464-25217-00 | CLAMP | 1 |
| 41 | 90464-15192-00 | CLAMP | 1 |
| 42 | 5PX-24180-00-00 | ROLL OVER VALVE ASSY U49 (2D99) | 1 |
| 5RB-24180-00-00 | ROLL OVER VALVE ASSY CA (2D9A) | 1 | |
| 43 | 90461-15100-00 | CLAMP U49 (2D99) | 1 |
| 90461-15139-00 | CLAMP CA (2D9A) | 1 | |
| 44 | 4WM-2148X-00-00 | BRACKET 4 | 1 |
| 45 | 98507-05008-00 | SCREW, PAN HEAD CA (2D9A) | 2 |
| 46 | 98907-05012-00 | SCREW, BIND U49 (2D99) | 1 |
| 90176-05054-00 | NUT, CROWN | 1 | |
| 47 | 5VN-24662-00-00 | STAY | |
| 48 | 90445-112K5-00 | HOSE (L355) U49 (2D99) | 1 |
| 5VN-24322-00-00 | PIPE 11 CA (2D9A) | 1 | |
| 49 | 90467-10041-00 | CLIP | 1 |
| 50 | 90464-09M31-00 | CLAMP | 5 |
| 51 | 4WM-24170-00-00 | CANISTER ASSY | 1 |
| 52 | 4WM-2419E-00-00 | COVER, CANISTER | 1 |
| 53 | 90105-06597-00 | BOLT, FLANGE | |
| 54 | 90464-10233-00 | CLAMP | 1 |
| 55 | 90464-20191-00 | CLAMP | 1 |
| 56 | 90467-09103-00 | CLIP | 3 |
| 57 | 5VN-24323-00-00 | PIPE 12 | |
| 58 | 90467-09103-00 | CLIP | 2 |
| 59 | 90413-07007-00 | WAY 3 | 1 |
| 60 | 5VN-24318-00-00 | PIPE, OVERFLOW | |
| 61 | 90467-09103-00 | CLIP | 2 |
| 62 | 5VN-24335-00-00 | PIPE, SUCTION 1 | |
| 63 | 90467-09103-00 | CLIP | 2 |
| 64 | 90464-11201-00 | CLAMP | 2 |
| 65 | 4GY-24188-00-00 | MOLD, FUEL TANK | 1 |
| 66 | 5VN-24491-00-00 | BRACKET, FUEL PUMP | |
| 67 | 90179-05271-00 | NUT | 2 |
| 68 | 95807-06016-00 | BOLT, FLANGE | 2 |
| 69 | 5Y9-12491-00-00 | CLAMP 1 | 1 |
| 70 | 5VN-24188-00-00 | MOLD, FUEL TANK | 1 |
| 71 | 5VN-2416B-30-00 | EMBLEM | 1 |
| 72 | 5VN-2417B-30-00 | EMBLEM | 1 |
| 73 | 5GK-2118K-00-00 | LABEL, CAUTION | 1 |
| 74 | 5VN-24145-00-00 | DAMPER, SIDE COVER CA (2D9A) | 1 |
| 5VR-24145-00-00 | DAMPER, SIDE COVER U49 (2D99) | 1 | |
| 75 | 5VN-24145-10-00 | DAMPER, SIDE COVER CA (2D9A) | 1 |
| 5VR-24145-10-00 | DAMPER, SIDE COVER U49 (2D99) | 1 | |
| 76 | 5VN-24145-20-00 | DAMPER, SIDE COVER CA (2D9A) | 1 |
| 5VR-24145-20-00 | DAMPER, SIDE COVER U49 (2D99) | 1 | |
| 77 | 5VN-24145-30-00 | DAMPER, SIDE COVER CA (2D9A) | |
| 5VR-24145-30-00 | DAMPER, SIDE COVER U49 (2D99) | 1 | |
| 78 | 5VN-24145-40-00 | DAMPER, SIDE COVER CA (2D9A) | 1 |
| 5VR-24145-40-00 | DAMPER, SIDE COVER U49 (2D99) | 1 | |
| 79 | 5VN-24145-50-00 | DAMPER, SIDE COVER CA (2D9A) | |
| 5VR-24145-50-00 | DAMPER, SIDE COVER U49 (2D99) | 1 | |
| 80 | 5VN-13907-00-00 | FUEL PUMP COMP. | 1 |
| 81 | 90464-13249-00 | CLAMP | 1 |
