Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 710000259 | Battery Ground Cable Includes 1 To 2 | ||
| 1 | 219704447 | Was 710000483 Heat Shrink Tubing | 1 |
| XXXX | Not Available As Spare Part - Engine Ground Cable | ||
| 278001680 | Ground Cable Battery, no 6, meter) | ||
| 278001690 | Cable Battery, no 6, meter) | ||
| 278001682 | Terminal 45°, Small Hole | ||
| 278001683 | TERMINAL 45, SMALL HOLE | ||
| 278001684 | TERMINAL 90, SMALL HOLE | ||
| 278001685 | FLAT TERMINAL, BIG HOLE | ||
| 278001686 | TERMINAL 45, BIG HOLE | ||
| 278001687 | TERMINAL 90, BIG HOLE | ||
| 278001688 | FLAT TERMINAL | ||
| 278001776 | Terminal 30°, 2 Holes | ||
| 529035730 | Crimp Plier | ||
| 1 | 207162544 | Hex. Screw M6 X 25 | 1 |
| 1 | 234461608 | External Serrated Lock Washer 6 mm | 1 |
| 1 | 232061414 | Hex. Nut M6 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 710000520 | Positive Cable, Battery/Solenoid STD Models, Includes 13 To 19 | ||
| 1 | 710000475 | TERMINAL_FEMALE STD Models | 1 |
| 1 | 219704447 | Was 710000483 Heat Shrink Tubing STD Models | 1 |
| 710000497 | PROTECTOR TUBE, 9 MM STD Models | ||
| 1 | 710000516 | Protector Cap STD Models | 1 |
| 710000523 | Protector Cap STD Models | ||
| 1 | 710000518 | Open Barrel STD Models | 1 |
| XXXX | Not Available As Spare Part - Positive Cable Includes 20 To 25 | ||
| 1 | 710000496 | PROTECTOR CAP | 1 |
| 710000497 | PROTECTOR TUBE, 9 MM | ||
| 710000530 | Open Barrel | ||
| 1 | 710000526 | Protector Cap | 1 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
| XXXX | Not Available As Spare Part - Positive Cable XT Models, Includes 27 To 36 | ||
| 1 | 710000475 | TERMINAL_FEMALE XT Models | 1 |
| 710000476 | OPEN BARREL, 6.6 MM XT Models | ||
| 1 | 219704447 | Was 710000483 Heat Shrink Tubing XT Models | 1 |
| 275500578 | Shrink Tubing XT Models | ||
| 710000497 | PROTECTOR TUBE, 9 MM XT Models | ||
| 1 | 710000516 | Protector Cap XT Models | 1 |
| 710000522 | PROTECTOR CAP XT Models | ||
| 710000523 | Protector Cap XT Models | ||
| 1 | 710000519 | Open Barrel XT Models | 1 |
| 710000455 | NEGATIVE CABLE ASS'Y XT Models, Includes 37 To 41 | ||
| 710000530 | Open Barrel XT Models | ||
| 1 | 705600311 | CLAMP XT Models | 1 |
| 1 | 207162044 | Hex. Screw M6 X 20 XT Models | 1 |
| 1 | 234461608 | External Serrated Lock Washer 6 mm XT Models | 1 |
| 2 | 232061414 | Hex. Nut M6 XT Models | 2 |
| 710000451 | Winch Positive Cable, Blue XT Models, Includes 46 To 51 | ||
| 710000494 | Protector Cap XT Models | ||
| 1 | 710000454 | WINCH POSITIVE CABLE, YELLOW XT Models, Includes 53 To 57 | 1 |
| 3 | 414227300 | Clip | 3 |
| 1 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 1 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 515176011 | Starter Relay | 1 |
| 2 | 234161601 | Lock Washer Helical M6 | 2 |
| 1 | 234161601 | Lock Washer Helical M6 XT Models | 1 |
| 2 | 232061600 | Hex. Nut M6 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 2 | 207661644 | Hex. Flange Screw M6 X 16 | 2 |
| 1 | 710000826 | Winch Solenoïd XT Models | 1 |
| 4 | 232561414 | Elastic Stop Nut M6 XT Models | 4 |
| 4 | 250000081 | Torx Screw M6 X 25 XT Models | 4 |
| 705200773 | Winch Relay Bracket XT Models | ||
| 2 | 390406500 | Pop Rivet 3/16" XT Models | 2 |
| 710000283 | BATTERY_12 VOLT 13AH STD Models, Includes 72 To 73 | ||
| 1 | 410301203 | Battery YUASA YTX20L XT Models, Includes 72 To 73 | 1 |
| 2 | 295500849 | Battery Fastener Kit | 2 |
| 1 | 710000279 | INSULATOR PAD | 1 |
| 1 | 293850080 | Rubber Strap | 1 |
