Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705500760 | Drive Axle Ass'y Includes 1 to 9 | 1 |
| 1 | 705500348 | Fix Joint | 1 |
| 2 | 703500607 | Unit Pack Kit | 2 |
| XXXX | Not Available As Spare Part - Slip Joint | ||
| 703500255 | Rubber Boot Kit Includes 5 to 7 | ||
| 705400148 | Collar | ||
| 1 | 293650138 | Oetiker Gear Clamp 44.0MM | 1 |
| 705500351 | DISC JOINT | ||
| XXXX | Not Available As Spare Part - Axle | ||
| 2 | 705400036 | Wear Ring | 2 |
| 705500503 | Rear Differential Ass'y Includes 11 to 33 | ||
| 1 | 705400027 | Oil Seal | 1 |
| 2 | 293250139 | Oil Seal | 2 |
| 1 | 705500266 | Nut | 1 |
| 1 | 705500260 | Ball Bearing | 1 |
| 705500075 | Pinion Gear Shim .022" | ||
| 1 | 703500049 | Pinion Shim Kit | 1 |
| 1 | 705500079 | Differential Shim .022" | 1 |
| 1 | 703500050 | Differential Shim Spool Kit | 1 |
| 705500268 | GEAR, 10 TEETH | ||
| 1 | 705500261 | Needle Bearing | 1 |
| 2 | 705500259 | Ball Bearing | 2 |
| 2 | 293350044 | Ball Bearing | 2 |
| 1 | 705500416 | GEAR, 36 TEETH | 1 |
| 4 | 705500264 | Screw | 4 |
| 705500326 | REAR COVER | ||
| 1 | 705500265 | Seal | 1 |
| 1 | 705500507 | PINION REAR COVER | 1 |
| 1 | 705500262 | Vent Valve | 1 |
| 1 | 705500245 | Drain Plug | 1 |
| 1 | 705500269 | RETAINING RING | 1 |
| 1 | 705500267 | O-Ring | 1 |
| 2 | 705500255 | Oil Seal | 2 |
| 1 | 705500504 | Fill Level Plug | 1 |
| 1 | 705500506 | Copper Washer | 1 |
| 705500596 | WHEEL HUB ASS'Y Includes 36 to 37 | ||
| 4 | 250300020 | Wheel Stud | 4 |
| 1 | 703500289 | Protector Kit Includes 38 to 39 | 1 |
| 704900009 | WARNING DECAL, TRAILER | ||
| 4 | 207662544 | Hex. Flange Screw M6 X 25 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 4 | 391302000 | Flat Washer | 4 |
| 1 | 250000060 | Flange Screw M10 X 16, Scotch Grip | 1 |
| 1 | 250200014 | Flat Washer M10 | 1 |
| 1 | 705400066 | Rubber Bellow | 1 |
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 1 | 207581646 | Hex. Flange Screw M8 X 16, Scotch Grip | 1 |
| 705400012 | WHEEL CAP | ||
| 705500441 | Rear Tire STD | ||
| 2 | 705500598 | TIRE_25X11R12 REAR XT | 2 |
| 2 | 705500622 | REAR RIM, GREY STD | 2 |
| 2 | 705500622 | REAR RIM, GREY XT | 2 |
| 2 | 705400193 | Rim Valve With Cap STD | 2 |
| 2 | 705400193 | Rim Valve With Cap XT | 2 |
| 8 | 250100042 | Steel Wheel Nut | 8 |
| 1 | 211200041 | Washer | 1 |
| 2 | 250100047 | Hex. Castellated Nut M18 | 2 |
| 2 | 250400016 | Cotter Pin | 2 |
| 1 | 293600011 | Redline Pump Oil, 75W90, 12 x 6 oz | 1 |
| 293550010 | Synthetic Grease, 400 G | ||
| 705500629 | LH CV JOINT ASS'Y Includes 58 to 67 | ||
| 1 | 705500701 | CV JOINT | 1 |
| 705500469 | BOOT WHEEL KIT Includes 60 to 62 | ||
| XXXX | Not Available As Spare Part - Clamp | ||
| 1 | 705500428 | Boot Kit Includes 63 to 65 | 1 |
| 1 | 705400409 | CLAMP | 1 |
| 705400180 | Clamp | ||
| 705500427 | PLUNGING JOINT | ||
| 1 | 705400042 | CIRCLIP | 1 |
| 705500630 | RH CV Joint Ass'y Includes 68 to 77 | ||
| 705500469 | BOOT WHEEL KIT Includes 70 to 72 | ||
| 1 | 705500428 | Boot Kit Includes 73 to 75 | 1 |
| 1 | 705400408 | CLAMP | 1 |
| 1 | 230602546 | Hex. Flange Screw M10 X 125 | 1 |
| 3 | 230603546 | Hex. Flange Screw M10 X 135 | 3 |
| 4 | 233201416 | Hex. Flange Elastic Nut M10 | 4 |
| 2 | 293350040 | Cone Bearing | 2 |
| 2 | 705500382 | Wear Sleeve | 2 |
| 2 | 705500564 | Wear Sleeve | 2 |
| 2 | 293370019 | Circlip | 2 |
| 2 | 250200049 | Spring Washer | 2 |
