Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 707000289 | Rotax 4 strokes engine "514" Includes 1 - 4. 2 X 4 Quest STD 500. | ||
| 707000100 | Rotax 4 strokes engine "610" Quest STD 650. Quest XT 650. | ||
| 707000216 | Rotax 4 strokes engine "514" 4 X 4 Quest STD 500. | ||
| 1 | 707000246 | Spark Plug NGK DCPR8E | 1 |
| 711265820 | Amplifier box | ||
| 707000094 | Anti-Vibration Mount | ||
| 707000019 | ENGINE SUPPORT BUSHING | ||
| 707000174 | RUBBER MOUNT | ||
| 707000159 | Engine Support, Black | ||
| 2 | 207581646 | Hex. Flange Screw M8 X 16, Scotch Grip | 2 |
| 707000161 | Engine Bracket | ||
| 2 | 233201414 | Hex. Flange Elastic Nut M10 | 2 |
| 3 | 233281414 | Hex. Flange Elastic Nut M8 | 3 |
| 1 | 707000132 | LH FRONT ENGINE BRACKET, BLACK | 1 |
| 707000101 | RH Front Engine Bracket, Black | ||
| 707000207 | RH Rear Engine Bracket | ||
| 707000210 | LH Rear Engine Bracket | ||
| 2 | 230604044 | Hex. Flange Screw M10 X 140 | 2 |
| 4 | 207682044 | Hex. Flange Screw M8 X 20 | 4 |
| 8 | 233281414 | Hex. Flange Elastic Nut M8 | 8 |
| 1 | 709400016 | THROTTLE HANDLE | 1 |
| 250000017 | SCREW-SET SOCKET DIN.913 | ||
| 293800061 | Loctite BLACK/MAX Gel Tube, 20 g | ||
| 707000097 | THROTTLE CABLE | ||
| 293600041 | CABLE LUBRICANT, 400 G | ||
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 707200181 | CARBURETOR BSR42-7 Quest STD 500. | ||
| 707200186 | CARBURATOR BSR42-8 Quest STD 650. Quest XT 650. | ||
| 1 | 414420700 | Spring Clamp | 1 |
| 707000248 | Anti-vibration Mount | ||
| 1 | 707000250 | THREADED INSERT | 1 |
| 707000252 | CABURETOR SUPPORT | ||
| 1 | 212000006 | HEX. ELASTIC STOP NUT | 1 |
| 1 | 391301600 | Washer | 1 |
| 1 | 413708300 | Glue Tube, Loctite 454, 20 G | 1 |
| 1 | 207662044 | Hex. Flange Screw M6 X 20 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 512059062 | Clamp | ||
| 707000264 | CHOKE CABLE | ||
| 1 | 707000067 | D SHAPE WASHER | 1 |
| 1 | 707000087 | HOLDER CAP | 1 |
| 707000088 | Rubber Cap | ||
| 1 | 707000089 | BUTTON | 1 |
| 250000108 | PHILLIPS SCREW M3 X 5 | ||
| 1 | 293300075 | O-RING | 1 |
| 2 | 293300081 | O-RING | 2 |
| 705500282 | SHIFTER HANDLE Quest STD 650. Quest XT 650. . | ||
| 707000139 | Transmission Guide Quest STD 650. Quest XT 650. . | ||
| 707000205 | PIVOT SLEEVE | ||
| 1 | 705500283 | LEVER SPRING | 1 |
| 1 | 207665044 | Hex. Flange Screw M6 X 50 | 1 |
| 707000169 | LOWER LEVER | ||
| 1 | 207663044 | Hex. Flange Screw M6 X 30 | 1 |
| 2 | 210261080 | Hex. Flange Screw M6 X 10 | 2 |
| 2 | 210261680 | Hex. Flange Screw M6 X 16 | 2 |
| 250200000 | Serrated Lock Washer M6 | ||
| 2 | 224061121 | Flat Washer | 2 |
| 3 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 3 |
| 707000152 | AIR INTAKE | ||
| 1 | 293650023 | Tridon Clamp | 1 |
| 707000153 | Exhaust | ||
| 707000154 | FLEXIBLE ADAPTOR | ||
| 2 | 293650064 | Tridon Clamp | 2 |
| 205353060 | SCREW M5 X 30 | ||
| 707000297 | Guide Support, Black | ||
| 2 | 207662544 | Hex. Flange Screw M6 X 25 | 2 |
| 2 | 224061201 | Flat Washer | 2 |
| 293550010 | Synthetic Grease, 400 G |
