Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 703500235 | Front fender kit Includes 1 - 8. XT YELLOW Quest XT 650. | ||
| 703500239 | Front fender kit STD GREEN Quest STD 500. Quest STD 650. | ||
| 703500247 | Front fender kit BLUE Quest STD 500. Quest STD 650. | ||
| 703500229 | Front fender kit RED Quest STD 500. Quest STD 650. | ||
| 703500233 | Front fender kit STD CAMO Quest STD 500. Quest STD 650. | ||
| 703500231 | Front fender kit XT CAMO Quest XT 650. | ||
| 703500237 | Front fender kit STD YELLOW Quest STD 500. Quest STD 650. | ||
| 703500245 | Front fender kit XT GREEN Quest XT 650. | ||
| 704900034 | Warning Label Includes 2 - 4. DEATH AND INGURIES. UNDER 16 YEARS OLD | ||
| 704900002 | Warning Decal, Death And Injuries DEATH AND INGURIES (FRENCH) | ||
| 1 | 704900012 | Warning Decal, Under 16 Years Old UNDER 16 YEARS OLD (FRENCH) | 1 |
| 703500152 | Front fascia Includes 5 - 6. YELLOW, GREEN, BLUE, RED | ||
| 705000594 | Front fascia CAMO | ||
| 1 | 704900130 | Bombardier Logo 68 mm | 1 |
| 2 | 211000123 | Phillips Screw M6 X 20 | 2 |
| 4 | 211000123 | Phillips Screw M6 X 20 | 4 |
| 4 | 224060201 | Flat Washer | 4 |
| 6 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 6 |
| 703500182 | Dash-board ass'y Includes 11 - 14. BLUE Quest STD 500. Quest STD 650. | ||
| 703500183 | Dash-board ass'y GREEN | ||
| 703500184 | Dash-board ass'y RED Quest STD 500. Quest STD 650. | ||
| 703500185 | Dash-board ass'y YELLOW | ||
| 703500209 | Dash-board ass'y CAMO | ||
| 1 | 704900247 | CAUTION DECAL, CONSOLE LOAD CONSOLE CHARGE | 1 |
| 704900250 | Caution Decal, Console Load CONSOLE CHARGE (FRENCH) | ||
| 705000541 | Reflective Sheet | ||
| 705000369 | HOOK, BLACK | ||
| 705000203 | LH cover BLUE Quest STD 500. Quest STD 650. | ||
| 705000334 | LH cover GREEN | ||
| 705000405 | LH Panel, yellow YELLOW | ||
| 705000570 | LH Panel, red RED Quest STD 500. Quest STD 650. | ||
| 705000625 | LH cover CAMO | ||
| 703500155 | RH cover Includes 18 - 20. GREEN | ||
| 703500223 | RH Panel, Red RED Quest STD 500. Quest STD 650. | ||
| 703500156 | RH panel YELLOW | ||
| 703500225 | RH cover CAMO | ||
| 703500154 | RH cover BLUE Quest STD 500. Quest STD 650. | ||
| 1 | 704900007 | Caution Decal, Transmission Selector TRANSMISSION SELECTOR | 1 |
| 704900008 | Caution Decal, Transmission Selector TRANSMISSION SELECTOR (FRENCH) | ||
| 6 | 570023800 | Windshield Latch | 6 |
| 703500148 | LH front mudguard Includes 22 - 23. YELLOW, GREEN, BLUE, RED | ||
| 703500211 | LH front mudguard CAMO | ||
| 703500149 | RH front mudguard YELLOW, GREEN, BLUE, RED | ||
| 703500212 | RH front mudguard CAMO | ||
| 1 | 705000083 | LH FRONT REFLECTOR | 1 |
| 705000026 | RH FRONT REFLECTOR | ||
| 16 | 207162044 | Hex. Screw M6 X 20 | 16 |
| 16 | 224060201 | Flat Washer | 16 |
| 16 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 16 |
| 1 | 705000133 | LH TANK PROTECTOR 4 X 4 | 1 |
| 705000533 | LH protector 2 X 4 Quest STD 500. Quest STD 650. | ||
| 1 | 705000134 | RH TANK PROTECTOR 4 X 4 | 1 |
| 705000534 | RH protector 2 X 4 Quest STD 500. Quest STD 650. | ||
| 4 | 210261680 | Hex. Flange Screw M6 X 16 | 4 |
| 4 | 224061201 | Flat Washer | 4 |
| 705000340 | Protector plate YELLOW, GREEN, BLUE, RED | ||
| 705000601 | Protector plate CAMO | ||
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 2 | 207602544 | Hex. Flange Screw M10 X 25 STD Quest STD 500. Quest STD 650. | 2 |
| 250000042 | Socket Screw 5/16-18 X 1 1/2" XT Quest XT 650. | ||
| 2 | 233201414 | Hex. Flange Elastic Nut M10 STD Quest STD 500. Quest STD 650. | 2 |
| 1 | 705200536 | SKID PLATE | 1 |
| 4 | 705200533 | CUP | 4 |
| 4 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 4 |
| 2 | 414745900 | Tuflock Phillips Plastic Screw | 2 |
| 570041600 | Rubber Cover | ||
| 705000184 | Mouting plate XT Quest XT 650. | ||
| 705000185 | WINCH XT Quest XT 650. | ||
| 1 | 705000194 | CABLE GUIDE XT Quest XT 650. | 1 |
| 1 | 705000618 | Hook XT Quest XT 650. | 1 |
| 1 | 250400022 | Cotter Pin XT Quest XT 650. | 1 |
| 2 | 250000041 | SOCKET SCREW 5/16-18 X 1 XT Quest XT 650. | 2 |
| 4 | 234081410 | Flat Washer 8 mm XT Quest XT 650. | 4 |
| 4 | 234181401 | Lock Washer 8 mm XT Quest XT 650. | 4 |
| 1 | 250400021 | Clevis Pin XT Quest XT 650. | 1 |
| 705000311 | Bracket, Black | ||
| 2 | 210261080 | Hex. Flange Screw M6 X 10 | 2 |
| 705000367 | LH Rear Grill, Black | ||
| 705000366 | RH Rear Grill, Black | ||
| 705000368 | LH Front Grill | ||
| 1 | 517302785 | Edge Clip | 1 |
| 705000408 | Protector 2 X 4 Quest STD 500. Quest STD 650. | ||
| 4 | 293150089 | Tuflok Plastic Rivet 2 X 4 Quest STD 500. Quest STD 650. | 4 |
