Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4718-312 | Panel, Side - w/Decals - Right - White (inc. 2-11) | ||
| 1 | 3718-438 | Panel, Side - w/o Decals - Right - White (inc. 3-7) | 1 |
| 1 | 0617-626 | Foam, Side Panel - Upper Front - Right | 1 |
| 1 | 6606-414 | Foil, Protective | 1 |
| 1 | 0617-628 | Foam, Side Panel - Upper Rear - Right | 1 |
| 1 | 0617-632 | Foam, Side Panel - Lower Front - Right | 1 |
| 1 | 0617-634 | Foam, Side Panel - Lower Rear - Right | 1 |
| 1 | 1621-658 | Decal, Side Panel - Upper - Right | 1 |
| 1 | 1621-672 | Decal, Side Panel - Lower Rear - Right | 1 |
| 1621-670 | Decal, Side Panel - Center - Right | ||
| 1621-674 | Decal, Side Panel - Lower Front - Right | ||
| 4718-313 | Panel, Side - w/Decals - Left - White (inc. 13-21) | ||
| 1 | 4718-555 | Panel, Side - w/o Decals - Left - White (inc. 14-16) | 1 |
| 1 | 0617-629 | Foam, Side Panel - Upper Rear - Left | 1 |
| 1 | 0617-635 | Foam, Side Panel - Lower Rear - Left | 1 |
| 1 | 0617-681 | Foam, Side Panel - Lower Front - Left | 1 |
| 1 | 1621-659 | Decal, Side Panel - Upper - Left | 1 |
| 1 | 1621-673 | Decal, Side Panel - Lower Rear - Left | 1 |
| 1621-675 | Decal, Side Panel - Lower Front - Left | ||
| 1 | 2621-291 | Decal, Side Panel - Center - Left | 1 |
| 2621-289 | Decal, Side Panel - Center Vent - Left | ||
| 1 | 1623-637 | Clip, U-Nut | 1 |
| 2 | 0607-447 | Cable | 2 |
| 2 | 0605-283 | Clip, Hairpin | 2 |
| 2 | 8060-486 | Rivet | 2 |
| 2 | 8050-127 | Washer | 2 |
| 2 | 1623-052 | Clip, U-Nut | 2 |
| 1 | 6606-925 | Screen, Intake | 1 |
| 1 | 2602-794 | Duct, Intake - Inner | 1 |
| 4 | 1623-030 | Clip, U-Nut | 4 |
| 2602-803 | Duct, Intake - Outer - White | ||
| 1 | 1702-369 | Duct, Belt Cooling (inc. 33) | 1 |
| 1 | 6606-694 | Foil, Protective | 1 |
| 1 | 4718-326 | Plate, Skid - w/Decals - Right - White (inc. 35-46) | 1 |
| 1 | 4718-536 | Plate, Skid - w/o Decals - Right - White (inc. 36-42) | 1 |
| 1 | 0617-640 | Foam, Skid Plate - Upper Rear - Right | 1 |
| 1 | 0617-638 | Foam, Skid Plate - Center Front - Right | 1 |
| 1 | 0617-636 | Foam, Skid Plate - Upper Front - Right | 1 |
| 1 | 2612-970 | Foil, Protective | 1 |
| 1 | 8061-708 | Rivet | 1 |
| 1 | 2612-754 | Deflector, Heat | 1 |
| 19 | 0123-802 | Washer | 19 |
| 1 | 1621-678 | Decal, Skid Plate - Front - Right | 1 |
| 1 | 1621-676 | Decal, Skid Plate - Upper - Right | 1 |
| 1 | 1621-680 | Decal, Skid Plate - Lower - Right | 1 |
| 1 | 1621-682 | Decal, Skid Plate - Rear - Right | 1 |
| 1 | 4718-207 | Plate, Skid - w/Decals - Left - White (inc. 48-57) | 1 |
| 1 | 4718-533 | Plate, Skid - w/o Decals - Left - White (inc. 49-53) | 1 |
| 1 | 0617-637 | Foam, Skid Plate - Upper Front - Left | 1 |
| 1 | 0617-639 | Foam, Skid Plate - Center Front - Left | 1 |
| 1 | 0617-641 | Foam, Skid Plate - Upper Rear - Left | 1 |
| 1 | 6606-613 | Panel, Reinforcement | 1 |
| 3 | 8061-688 | Rivet | 3 |
| 1 | 1621-679 | Decal, Skid Plate - Front - Left | 1 |
| 1 | 1621-677 | Decal, Skid Plate - Upper - Left | 1 |
| 1621-681 | Decal, Skid Plate - Lower - Left | ||
| 1 | 1621-683 | Decal, Skid Plate - Rear - Left | 1 |
| 2 | 2623-005 | Clip, Retaining | 2 |
| 2 | 6606-592 | Pin, Retaining | 2 |
| 1623-129 | Screw, Self-Tapping | ||
| 1 | 2612-972 | Plate, Exhaust Outlet | 1 |
| 1 | 2612-971 | Seal, Exhaust Outlet | 1 |
| 1 | 1712-963 | Deflector, Exhaust Outlet - Black | 1 |
| 6 | 8061-710 | Rivet | 6 |
| 1 | 6606-940 | Shield, Heat - ECM | 1 |
| 2 | 8408-620 | Screw, Cap | 2 |
| 1 | 0730-238 | ECM (PLEASE INCLUDE VIN WHEN ORDERING) | 1 |
| 2 | 0423-031 | Clip, U-Nut | 2 |
| 2 | 0623-784 | Screw, Self-Tapping | 2 |
| 1 | 6606-342 | Fascia, Front - Right - Black | 1 |
| 1 | 3718-303 | Fascia, Front - Left - Black (inc. 71) | 1 |
| 6606-405 | Foil, Protective | ||
| 1 | 2623-001 | RETAINER,PUSHNUT - 3/16" STUD Optional | 1 |
| 1 | 1623-999 | Screw, Thumb Optional | 1 |
