Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204611715 | Front Backrest, Bright Yellow Includes 1 to 2 | ||
| XXXX | Not Available As Spare Part - Backrest Cover, Bright Yellow | ||
| 269000388 | SEAT SUPPORT | ||
| 4 | 234061600 | Stainless Flat Washer M6 | 4 |
| 4 | 293150043 | Pop Rivet 3/16" | 4 |
| 204611717 | Front Seat Includes 6 to 7 | ||
| XXXX | Not Available As Spare Part - Front Seat Cover | ||
| 4 | 293730006 | Black, Dart | 4 |
| 204612886 | Rear Backrest Ass'y, Metallic Quartz Includes 9 to 13 | ||
| 204611720 | Backrest Cover, Bright Yellow | ||
| 204612887 | Center Backrest Cover, Metallic Quartz | ||
| 204612888 | Starboard Backrest Cover, Quartz Metal. | ||
| 204612889 | Port Side Backrest Cover, Quartz Metal. | ||
| 204901090 | Sea-doo Logo | ||
| 207364060 | Hex. Screw M6 X 40, Scotch Grip | ||
| 10 | 234062600 | Flat Washer M6, Stainless | 10 |
| 14 | 204100139 | WASHER-FENDER/S.S. | 14 |
| 204611724 | Armrest Ass'y, Port Side Includes 18 to 19 | ||
| 204611726 | Armrest Ass'y, Starboard Includes 18 to 19 | ||
| 204611727 | Armrest Cover | ||
| 204612618 | Rear Seat Ass'y Includes 20 to 25 | ||
| 204611729 | Rear Seat Cover, Bright Yellow | ||
| 204611730 | Cushion Ass'y | ||
| 204611732 | Rear Seat Strap, Bright Yellow | ||
| 4 | 207161660 | Hex. Screw M6 X 16 | 4 |
| 4 | 234062600 | Flat Washer M6, Stainless | 4 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 4 | 293730021 | Dart | 4 |
| 204612688 | Cushion Ass'y | ||
| 204130048 | S-clip | ||
| 4 | 293150011 | Pop Rivet 3/16" | 4 |
| 1 | 293730021 | Dart | 1 |
| 204613172 | Keeper Seat Ass'y Includes 34 to 36 | ||
| 204610557 | Keeper Seat Base Cover | ||
| 204611734 | Keeper Seat Cover | ||
| XXXX | Not Available As Spare Part - Seat Float | ||
| 204611735 | Keeper Seat Ring Ass'y, Bright Yellow Includes 38 to 39 | ||
| 204611736 | Keeper Seat Ring Cover | ||
| 209663860 | Tapping Phillips Screw 6.3 X 38 | ||
| 4 | 234161601 | Lock Washer Helical M6 | 4 |
| 6 | 293150043 | Pop Rivet 3/16" | 6 |
| 6 | 234061600 | Stainless Flat Washer M6 | 6 |
| 204611652 | Keeper Seat Backrest Includes 46 to 47 | ||
| XXXX | Not Available As Spare Part - Keeper Seat Backrest Cover |
